Anti-Collapse Drilling Fluid Technology for Broken Carbonate Formation in Shunbei Oil and Gas Field
-
摘要:
为了解决顺北油气田奥陶系碳酸盐岩破碎性地层易发生井壁坍塌的问题，从地质构造特征、地层裂缝发育及充填程度和井壁岩块受力等方面分析了井壁坍塌的原因，发现造成井壁坍塌掉块的主要原因是强挤压段应力集中、地层微裂缝发育和定向井段受重力影响。虽然地层破碎、应力集中无法改变，但可以提高钻井液的封堵性能，通过有效充填、封堵微裂缝阻止压力传递，同时钻井液保持较高的密度支撑井壁，从而解决井壁坍塌问题。为此，综合考虑强化钻井液封堵能力、控制钻井液高温高压滤失量和优化钻井液动塑比等，优选了防塌钻井液配方，并保持较高的钻井液密度以支撑井壁，形成了防塌钻井液技术。该技术在顺北X井进行了现场试验，钻进中扭矩稳定，机械钻速较高，井径扩大率较小，防塌效果良好，可为其他油气田破碎性地层的高效、安全钻井提供借鉴。
Abstract:In order to solve the problem of wellbore collapse in broken carbonate formation of Ordovician in Shunbei Oil and Gas Field, this paper analyzed the cause of wellbore collapse from the characteristics of geological structure, the development and filling of fractures in the formation, and the stress on the wellbore block. It was found that the stress concentration in the strong compression section, the development of micro fractures in the formation and the influence of gravity on the directional interval were the main causes of wellbore collapse. According to the analysis, since the formation fragmentation and stress concentration could not be changed, the problem of wellbore collapse could only be solved by improving the plugging performance of the drilling fluid through effective filling and plugging of micro fractures, preventing the transmission of pressure and maintaining a high density for stress support. Therefore, the anti-collapse drilling fluid was prepared from the aspects of strengthening the plugging ability, controlling the filtration at high temperatures and pressures, optimizing the yield point and plastic viscosity ratio of the drilling fluid, etc., so as to improve its anti-collapse performance. The field test of Well Shunbei X showed that after adopting this anti-collapse drilling fluid technology, the drilling torque was stable, the ROP was high, the hole diameter enlargement ratio was small, and the anti-collapse effect was good, which could provide reference for efficient and safe drilling under the similar conditions.
-
-
![]()
图 1 顺北油气田5号断裂带北段挤压构造示意
Figure 1. Compressional structure in the north section of No. 5 fault zone of Shunbei Oil and Gas Field
![]()
图 7 顺北X井破碎带地层的钻时和扭矩
Figure 7. Drilling time and torque of broken formation in Well Shunbei X
表 1 顺北油气田3口井所取岩心的矿物组成
Table 1 Mineral composition of cores from 3 wells in Shunbei Oil and Gas Field
取心井 岩样中矿物含量，% 石英 斜长石 方解石 白云石 方沸石 赤铁矿 黏土 顺北A井 11.6 2.0 0 81.3 1.2 3.9 0 顺北B井 2.9 0 72.1 23.7 0 1.3 0 顺北C井 2.5 0.6 96.9 0 0 0 0
下载: 导出CSV
-
[1] 梁文利. 涪陵破碎性地层井壁失稳影响因素分析及技术对策[J]. 天然气勘探与开发, 2018, 41(2): 70–73, 82. LIANG Wenli. Borehole instability in broken formations of Fuling Block: influence factors and countermeasures[J]. Natural Gas Exploration and Development, 2018, 41(2): 70–73, 82.
[2] 张立刚．松辽盆地深层火成岩破碎机理及破岩效率评价[D]．大庆: 东北石油大学, 2014． ZHANG Ligang. Research on the igneous rock crushing mechanism and efficiency in deep reservoir of Songliao Basin[D]. Daqing: Northeast Petroleum University, 2014.
[3] 申瑞臣,屈平,杨恒林. 煤层井壁稳定技术研究进展与发展趋势[J]. 石油钻探技术, 2010, 38(3): 1–7. doi: 10.3969/j.issn.1001-0890.2010.03.001 SHEN Ruichen, QU Ping, YANG Henglin. Advancement and development of coal bed wellbore stability technology[J]. Petroleum Drilling Techiques, 2010, 38(3): 1–7. doi: 10.3969/j.issn.1001-0890.2010.03.001
[4] 蒋廷学, 周珺, 贾文峰, 等. 顺北油气田超深碳酸盐岩储层深穿透酸压技术[J]. 石油钻探技术, 2019, 47(3): 140–147. JIANG Tingxue, ZHOU Jun, JIA Wenfeng, et al. Deep penetration acid-fracturing technology for ultra-deep carbonate oil & gas reservoirs in the Shunbei Oil and Gas Field[J]. Petroleum Drilling Techniques, 2019, 47(3): 140–147.
[5] 赵锐,赵腾,李慧莉,等. 塔里木盆地顺北油气田断控缝洞型储层特征与主控因素[J]. 特种油气藏, 2019, 26(5): 8–13. ZHAO Rui, ZHAO Teng, LI Huili, et al. Fault-controlled fracture-cavity reservoir characterization and main-controlling factors in the Shunbei hydrocarbon field of Tarim Basin[J]. Special oil & Gas Reservoirs, 2019, 26(5): 8–13.
[6] CORNIELIS J, BRACHO L, MELENDEZ L, et al. Drilling through highly faulted/fractured zones: case study, an integral approach with successful results[R]. ARMA-2015-665, 2015.
[7] 朱金智,邹盛礼,王书琪. 塔参1井破碎性白云岩地层防塌技术[J]. 石油钻探技术, 1999, 27(2): 35–37. doi: 10.3969/j.issn.1001-0890.1999.02.013 ZHU Jinzhi, ZOU Shengli, WANG Shuqi. Anti-collapse technique for broken dolomite formation in Tacan Well 1[J]. Petroleum Drilling Techiques, 1999, 27(2): 35–37. doi: 10.3969/j.issn.1001-0890.1999.02.013
[8] 李翔,李伟,侯承勋. 塔深2井破碎性地层钻井技术难点及对策[J]. 西部探矿工程, 2013, 25(12): 35–36. doi: 10.3969/j.issn.1004-5716.2013.12.011 LI Xiang, LI Wei, HOU Chengxun. Drilling technology difficulties and countermeasures in fractured formation in Well Tashen 2[J]. West-China Exploration Engineering, 2013, 25(12): 35–36. doi: 10.3969/j.issn.1004-5716.2013.12.011
[9] 金军斌. 塔里木盆地顺北地区长裸眼钻井液技术[J]. 探矿工程(岩土钻掘工程), 2017, 44(4): 5–9. JIN Junbin. Drilling fluid technology of long open hole section in Shunbei Area of Tarim Basin[J]. Exploration Engineering (Rock & Soil Drilling and Tunneling), 2017, 44(4): 5–9.
[10] PATEL N, PENKAR S, BLYTH M. Managing drilling risk using an integrated approach to real-time pore pressure prediction[R]. SPE 192692, 2018.
[11] PAUL F, BRUNO L A, DOSUNMU A, et al. The effect of wellbore stability in naturally fractured reservoirs[R]. SPE 178267, 2015.
-
