3D Fracturing Network Optimization Techniques for Horizontal Wells in Sandstone-Conglomerate Formations
-
摘要: 深层致密砂砾岩储层盐227区块为厚层特低渗常压油藏，常规直井压裂效果差、建产难，单一水平井开发难以实现纵向厚层有效动用。借鉴国外页岩气工厂化开发理念，发展了"三层楼"工厂化整体压裂开发模式，即1套层系、3层开发，8口水平井组作为一个整体进行压裂，第一层为3口井，第二层为3口井，第三层为2口井，水平段长900~1 400 m，三层之间纵向跨度为80 m。综合考虑平面上同层井间、纵向上层间裂缝参数匹配，建立层间立体体积缝网，提高储量控制程度。通过优化施工参数，应用新型实时混配压裂液技术，配套泵送桥塞分段压裂工艺、裂缝实时监测技术，完成4个井组8口井87段的集中压裂，裂缝监测显示立体缝网基本形成。工厂化整体压裂平均施工周期比单一水平井压裂缩短50%，单井投产费用减少395.5万元。压裂后单井平均产油量11.8 t/d，为同区块直井的4倍以上，取得了良好的改造效果，为今后同类致密油储层的经济开发积累了经验。Abstract: Block Yan 227 is a thick tight sandstone-conglomerate reservoir with ultra low permeability.The result of fracturing in a conventional vertical well was too poor to obtain a satisfactory yield,to the point that it is even not desirable to develop such a thick reservoir with a single horizontal well.Based on the concept of factory production from numerous countries for shale gas,a three-layer development model was developed.The model included a group of eight horizontal wells for fracturing:three wells were included in the first layer,another three wells in the second layer,and remaining two wells in the third layer.The length of the horizontal section ranged from 900 to 1 400 m,the vertical span in the three layers was 80 m.Fracture parameter matching was done with wells within the same layer as well as between layers to establish a 3-D fracture network to improve the controlling degree of reserves.Operating parameters were optimized,with a new type of real-time mixing technology for fracture fluids,which included pumping a bridge plug for staged fracturing,and monitoring fractures in real time,which allowed eight wells in four well groups with 87 sections to be fractured.The fracture monitoring results showed that a 3D fracture network was formed.The centralized multi-well fracturing technology has many advantages compared with single horizontal well fracturing,including the fact that average operation cycle time was shortened by 50%,and the production cost of a single well was reduced by 3.955 million RMB.After treatment,average daily oil production of single well was 11.8 t/d,which was four times higher than that in the vertical well in the same block.It is a good experiment for economic recovery in similar tight oil reservoirs.
-
Keywords:
- sandstone /
- horizontal well group /
- network fracturing /
- Block Yan 227
-
-
[1] 张金成,孙连忠,王甲昌,等."井工厂"技术在我国非常规油气开发中的应用[J].石油钻探技术,2014,42(1):20-25. Zhang Jincheng,Sun Lianzhong,Wang Jiachang,et al.Application of multi-well pad in unconventional oil and gas development in China[J].Petroleum Drilling Techniques,2014,42(1):20-25. [2] 曾保全,程林松,齐梅,等.特低渗透油藏水平井新型布井方式研究[J].西南石油大学学报:自然科学版,2013,35(2):115-120. Zeng Baoquan,Cheng Linsong,Qi Mei,et al.Novel well pattern for fractured horizontal well in ultra-low permeability reservior[J].Journal of Southwest Petroleum University:Science Technology Edition,2013,35(2):115-120. [3] 赵文彬.大牛地气田DP43水平井组的井工厂钻井实践[J].天然气工业,2013,33(6):60-65. Zhao Wenbin.Drilling practice of a well plant in the cluster horizontal wells of DP43 in the Daniudi Gas Field,Ordos Basin[J].Natural Gas Industry,2013,33(6):60-65. [4] 路保平.中国石化页岩气工程技术进步及展望[J].石油钻探技术,2013,41(5):1-8. Lu Baoping.Sinopec engineering technical advance and its developing tendency in shale gas[J].Petroleum Drilling Techniques,2013,41(5):1-8. [5] 邵尚奇,田守嶒,李根生,等.泥页岩地层水力裂缝延伸方位研究[J].石油钻探技术,2014,42(3):27-31. Shao Shangqi,Tian Shouceng,Li Gensheng,et al.Propagating orientation of hydraulic fractures in muddy shale formation[J].Petroleum Drilling Techniques,2014,42(3):27-31. [6] Abass H H,Hedayati Saeed,Meadows D L.Nonplanar fracture propagation from a horizontal wellbore:experimental study[R].SPE 24823,1996.
[7] El Rabaa W.Experimental study of hydraulic fracturegeometry initiation[R].SPE 19720,1989.
[8] Abass H H, Soliman M Y,Tahini A M,et al.Oriented fracturing:a new technique to hydraulically fracture openhole horizontal well[R].SPE 124483,2011.
[9] Hossain M M,Rahman M K,Rahman Sheik S.A comprehensive monograph for hydraulic fracture initiation from deviated wellbores under arbitrary stress regimes[R].SPE 54360,1999.
[10] 李杭州,廖红建,孔令伟,等.膨胀性泥岩应力-应变关系的试验研究[J].岩土力学,2007, 28(1):107-110. Li Hangzhou,Liao Hongjian,Kong Lingwei,et al.Experimental study on stress-strain relationship of expansive mud-stone[J].Rock and Soil Mechanics,2007,28(1):107-110. [11] 蒋廷学,卞晓冰,袁凯,等.页岩气水平井分段压裂优化设计新方法[J].石油钻探技术,2014,42(2):1-6. Jiang Tingxue,Bian Xiaobing,Yuan Kai,et al.A new method in staged fracturing design optimization for shale gas horizontal wells[J].Petroleum Drilling Techniques,2014,42(2):1-6. [12] 蒋廷学,贾长贵,王海涛,等.页岩气网络压裂设计方法研究[J].石油钻探技术,2011,39(3):36-40. Jiang Tingxue,Jia Changgui,Wang Haitao,et al.Study on network fracturing design method in shale gas[J].Petroleum Drilling Techniques,2011,39(3):36-40. [13] 赵金洲,王松,李勇明.页岩气藏压裂改造难点与技术关键[J].天然气工业,2012,32(4):46-49. Zhao Jinzhou,Wang Song,Li Yongming.Difficulties and techniques in the fracturing treatment of shale gas reservoirs[J].Natural Gas Industry,2012,32(4):46-49. [14] 吴奇,胥云,王腾飞,等.增产改造理念的重大变革:体积改造技术概论[J].天然气工业,2011,31(4):7-12. Wu Qi,Xu Yun,Wang Tengfei,et al.The revolution of reservoir stimulation:an introduction of volume fracturing[J].Natural Gas Industry,2011,31(4):7-12. [15] Soliman M Y,East L,Augustine J.Fracturing design aimed at enhancing fracture complexity[R].SPE 130043,2010.
[16] 蒋廷学.页岩油气水平井压裂裂缝复杂性指数研究及应用展望[J].石油钻探技术,2013,41(2):7-12. Jiang Tingxue.The fracture complexity index of horizontal wells in shale oil and gas reservoirs[J].Petroleum Drilling Techniques,2013,41(2):7-12. [17] 张旭,蒋廷学,贾长贵,等.页岩气储层水力压裂物理模拟试验研究[J].石油钻探技术,2013,41(2):70-74. Zhang Xu,Jiang Tingxue,Jia Changgui,et al.Physical simulation of hydraulic fracturing of shale gas reservoir[J].Petroleum Drilling Techniques,2013,41(2):70-74. -
