Drilling Technologies for Horizontal Wells of Gulong Shale Oil in Daqing
-
摘要:
大庆油田古龙页岩油区块水平井存在井壁易失稳、井眼轨迹控制难度大、井眼清洁困难和固井质量得不到保证等钻井技术难点。为克服上述技术难点，进行了井台井组和井身结构优化、钻井参数优选、井眼轨迹控制、钻井液优选和固井施工优化等技术研究，形成了适用于大庆古龙页岩油水平井的钻井技术。古龙页岩油区块的10口井应用了该技术，钻井过程中未出现井壁失稳的情况，固井质量得到提高，与该区块未应用该技术的水平井相比，平均机械钻速提高了 79.91%，在平均水平段长度增加265.13 m 的前提下，平均钻井周期缩短了 40 d。现场应用结果表明，该技术可以解决古龙页岩油水平井存在的钻井技术难点，为古龙页岩油的高效勘探开发提供技术支持。
Abstract:Some technical challenges were encountered while drilling horizontal wells in the Gulong shale oil block of Daqing Oilfield, such as wellbore instability, difficulties of wellbore trajectory control and wellbore cleaning, and uncertain cementing quality, etc. Therefore, the research on technologies such as the optimization of well platform, well group, and casing program, selection of drilling parameters, wellbore trajectory control, drilling fluid optimization, and cementing optimization were carried out. The drilling technologies suitable for horizontal wells of Gulong shale oil were formed. The technologies have been applied to 10 wells in Gulong shale oil block. No wellbore instability was observed during drilling, and the cementing quality was improved. Compared with horizontal wells in the block without these technologies applied, the average rate of penetration was increased by 79.91%, and the average drilling duration was shortened by 40 days while the average length of the horizontal section was increased by 265.13 m. The field application results show that the technologies can solve the technical difficulties of drilling in horizontal wells of the Gulong shale oil, and provide technical support for its efficient exploration and development.
-
Keywords:
- shale oil /
- horizontal well /
- wellbore trajectory /
- casing program /
- Gulong Block /
- Daqing Oilfield
-
-
表 1 钻井参数推荐
Table 1 Recommended drilling parameters
仪器类型 钻压/kN 转速/（r·min−1） 排量/（L·s−1） LWD 60~100 50~80 >35 旋转导向 60~100 100~120 >35
下载: 导出CSV
-
[1] U. S. Energy Information Administration. Technically recoverable shale oil and shale gas resources: an assessment of 137 shale formations in 41 countries outside the United States[R]. Washington, D. C. : U. S. Department of Energy, 2013.
[2] 金之钧,白振瑞,高波,等. 中国迎来页岩油气革命了吗?[J]. 石油与天然气地质,2019,40(3):451–458. doi: 10.11743/ogg20190301 JIN Zhijun, BAI Zhenrui, GAO Bo, et al. Has China ushered in the shale oil and gas revolution?[J]. Oil & Gas Geology, 2019, 40(3): 451–458. doi: 10.11743/ogg20190301
[3] 冉启华,赵晗. 威远页岩气水平井钻井关键技术及发展方向[J]. 钻采工艺,2020,43(4):12–15. doi: 10.3969/J.ISSN.1006-768X.2020.04.04 RAN Qihua, ZHAO Han. Key technology and development direction of horizontal well drilling in Weiyuan shale gas reservoir[J]. Drilling & Production Technology, 2020, 43(4): 12–15. doi: 10.3969/J.ISSN.1006-768X.2020.04.04
[4] 柳伟荣,倪华峰,王学枫,等. 长庆油田陇东地区页岩油超长水平段水平井钻井技术[J]. 石油钻探技术,2020,48(1):9–14. doi: 10.11911/syztjs.2020029 LIU Weirong, NI Huafeng, WANG Xuefeng, et al. Shale oil horizontal drilling technology with super-long horizontal laterals in the Longdong region of the Changqing Oilfield[J]. Petroleum Drilling Techniques, 2020, 48(1): 9–14. doi: 10.11911/syztjs.2020029
[5] 孙永兴,贾利春. 国内3 000 m长水平段水平井钻井实例与认识[J]. 石油钻采工艺,2020,42(4):393–401. SUN Yongxing, JIA Lichun. Cases and understandings on the drilling of horizontal well with horizontal section of 3 000 m long in China[J]. Oil Drilling & Production Technology, 2020, 42(4): 393–401.
[6] 杨睿,张拓铭. 吉木萨尔凹陷芦草沟组页岩油水平井钻井技术[J]. 新疆石油天然气,2019,15(3):36–40. doi: 10.3969/j.issn.1673-2677.2019.03.007 YANG Rui, ZHANG Tuoming. Horizontal well drilling technology of shale oil in Jimusar’s concave Lucaogou Formation[J]. Xinjiang Oil & Gas, 2019, 15(3): 36–40. doi: 10.3969/j.issn.1673-2677.2019.03.007
[7] 袁建强. 济阳坳陷页岩油多层立体开发关键工程技术[J]. 石油钻探技术,2023,51(1):1–8. YUAN Jianqiang. Key engineering technologies for three-dimensional development of multiple formations of shale oil in Jiyang Depression[J]. Petroleum Drilling Techniques, 2023, 51(1): 1–8.
[8] 孙欢,朱明明,王伟良,等. 长庆页岩油水平井华H90-3井超长水平段防漏堵漏技术[J]. 石油钻探技术,2022,50(2):16–21. SUN Huan, ZHU Mingming, WANG Weiliang, et al. Lost circulation prevention and plugging technologies for the ultra-long horizontal section of the horizontal shale oil well Hua H90-3 in Changqing Oilfield[J]. Petroleum Drilling Techniques, 2022, 50(2): 16–21.
[9] 席传明,史玉才,张楠,等. 吉木萨尔页岩油水平井JHW00421井钻完井关键技术[J]. 石油钻采工艺,2020,42(6):673–678. XI Chuanming, SHI Yucai, ZHANG Nan, et al. Key technologies for the drilling and completion of shale oil horizontal well JHW00421 in Jimusaer[J]. Oil Drilling & Production Technology, 2020, 42(6): 673–678.
[10] 倪华峰,杨光,张延兵. 长庆油田页岩油大井丛水平井钻井提速技术[J]. 石油钻探技术,2021,49(4):29–33. doi: 10.11911/syztjs.2021076 NI Huafeng, YANG Guang, ZHANG Yanbing. ROP improvement technologies for large-cluster horizontal shale oil wells in the Changqing Oilfield[J]. Petroleum Drilling Techniques, 2021, 49(4): 29–33. doi: 10.11911/syztjs.2021076
[11] 仝继昌,秦雪峰,张娜,等. 河南油田陆相页岩油水平井钻井配套技术[J]. 内蒙古石油化工,2012,38(24):109–111. doi: 10.3969/j.issn.1006-7981.2012.24.050 TONG Jichang, QIN Xuefeng, ZHANG Na, et al. Matching technology of horizontal well drilling in continental shale of Henan Oilfield[J]. Inner Mongolia Petrochemical Industry, 2012, 38(24): 109–111. doi: 10.3969/j.issn.1006-7981.2012.24.050
[12] 李玉海,李博,柳长鹏,等. 大庆油田页岩油水平井钻井提速技术[J]. 石油钻探技术,2022,50(5):9–13. LI Yuhai, LI Bo, LIU Changpeng, et al. ROP improvement technology for horizontal shale oil wells in Daqing Oilfield [J]. Petroleum Drilling Techniques, 2022, 50(5): 9–13.
[13] 田逢军,王运功,唐斌,等. 长庆油田陇东地区页岩油大偏移距三维水平井钻井技术[J]. 石油钻探技术,2021,49(4):34–38. TIAN Fengjun, WANG Yungong, TANG Bin, et al. Drilling technology for long-offset 3D horizontal shale oil wells in the Longdong Area of the Changqing Oilfield [J]. Petroleum Drilling Techniques, 2021, 49(4): 34–38.
[14] 田平,薛建国,蒋建宁,等. 河南油田泌页HF1水平井钻井技术[J]. 石油地质与工程,2012,26(3):88–90. doi: 10.3969/j.issn.1673-8217.2012.03.026 TIAN Ping, XUE Jianguo, JIANG Jianning, et al. Drilling technology of BY-HF1 horizontal well in Henan Oilfield[J]. Petroleum Geology and Engineering, 2012, 26(3): 88–90. doi: 10.3969/j.issn.1673-8217.2012.03.026
[15] 田增艳,杨贺卫,李晓涵,等. 大港油田页岩油水平井钻井液技术[J]. 石油钻探技术,2021,49(4):59–65. TIAN Zengyan, YANG Hewei, LI Xiaohan, et al. Drilling fluid technology for horizontal shale oil wells in the Dagang Oilfield[J]. Petroleum Drilling Techniques, 2021, 49(4): 59–65.
[16] 常海军,李祥群,张娜,等. 河南油田页岩油长水平段水平井钻井实践[J]. 复杂油气藏,2013,6(2):66–70. doi: 10.3969/j.issn.1674-4667.2013.02.021 CHANG Haijun, LI Xiangqun, ZHANG Na, et al. Drilling practice of long horizontal section well in shale oil reservoir in Henan Oilfield[J]. Complex Hydrocarbon Reservoirs, 2013, 6(2): 66–70. doi: 10.3969/j.issn.1674-4667.2013.02.021
[17] 王显光,李雄,林永学. 页岩水平井用高性能油基钻井液研究与应用[J]. 石油钻探技术,2013,41(2):17–22. doi: 10.3969/j.issn.1001-0890.2013.02.004 WANG Xianguang, LI Xiong, LIN Yongxue. Research and application of high performance oil base drilling fluid for shale horizontal wells[J]. Petroleum Drilling Techniques, 2013, 41(2): 17–22. doi: 10.3969/j.issn.1001-0890.2013.02.004
[18] 金军斌,高书阳,陈晓飞. 帅页3-7HF页岩油小井眼水平井水基钻井液技术[J]. 钻井液与完井液,2023,40(3):349–355. JIN Junbin, GAO Shuyang, CHEN Xiaofei. Drilling fluid technology for drilling the slim hole horizontal shale oil well Shuye3-7HF[J]. Drilling Fluid & Completion Fluid, 2023, 40(3): 349–355.
[19] 万绪新. 渤南区块页岩油地层油基钻井液技术[J]. 石油钻探技术,2013,41(6):44–50. doi: 10.3969/j.issn.1001-0890.2013.06.009 WAN Xuxin. Oil-based drilling fluid applied in drilling shale oil reservoirs in Bonan Block[J]. Petroleum Drilling Techniques, 2013, 41(6): 44–50. doi: 10.3969/j.issn.1001-0890.2013.06.009
[20] 沈丽,王宝田,宫新军,等. 气制油合成基钻井液流变性能影响评价[J]. 石油与天然气化工,2013,42(1):53–57. doi: 10.3969/j.issn.1007-3426.2013.01.012 SHEN Li, WANG Baotian, GONG Xinjun, et al. Evaluation on rheological properties of GTL based drilling fluids[J]. Chemical Engineering of Oil and Gas, 2013, 42(1): 53–57. doi: 10.3969/j.issn.1007-3426.2013.01.012
[21] 樊好福,臧艳彬,张金成,等. 深层页岩气钻井技术难点与对策[J]. 钻采工艺,2019,42(3):20–23. doi: 10.3969/J.ISSN.1006-768X.2019.03.06 FAN Haofu, ZANG Yanbin, ZHANG Jincheng, et al. Technical difficulties and countermeasures of deep shale gas drilling[J]. Drilling & Production Technology, 2019, 42(3): 20–23. doi: 10.3969/J.ISSN.1006-768X.2019.03.06
[22] 王建龙,冯冠雄,刘学松,等. 长宁页岩气超长水平段水平井钻井完井关键技术[J]. 石油钻探技术,2020,48(5):9–14. doi: 10.11911/syztjs.2020086 WANG Jianlong, FENG Guanxiong, LIU Xuesong, et al. Key technology for drilling and completion of shale gas horizontal wells with ultra-long horizontal sections in Changning Block[J]. Petroleum Drilling Techniques, 2020, 48(5): 9–14. doi: 10.11911/syztjs.2020086
[23] 刘茂森,付建红,白璟. 页岩气双二维水平井轨迹优化设计与应用[J]. 特种油气藏,2016,23(2):147–150. doi: 10.3969/j.issn.1006-6535.2016.02.036 LIU Maosen, FU Jianhong, BAI Jing. Optimization of shale gas dual-2D horizontal-well trajectories and its application[J]. Special Oil & Gas Reservoirs, 2016, 23(2): 147–150. doi: 10.3969/j.issn.1006-6535.2016.02.036
[24] 杨灿,王鹏,饶开波,等. 大港油田页岩油水平井钻井关键技术[J]. 石油钻探技术,2020,48(2):34–41. doi: 10.11911/syztjs.2020036 YANG Can, WANG Peng, RAO Kaibo, et al. Key technologies for drilling horizontal shale oil wells in the Dagang Oilfield[J]. Petroleum Drilling Techniques, 2020, 48(2): 34–41. doi: 10.11911/syztjs.2020036
[25] 王敏生,光新军,耿黎东. 页岩油高效开发钻井完井关键技术及发展方向[J]. 石油钻探技术,2019,47(5):1–10. WANG Minsheng, GUANG Xinjun, GENG Lidong. Key drilling/completion technologies and development trends in the efficient development of shale oil[J]. Petroleum Drilling Techniques, 2019, 47(5): 1–10.
[26] 刘毅. 渤海湾盆地济阳坳陷沙河街组页岩油储层特征研究[D]. 成都: 成都理工大学, 2018: 1−10. LIU Yi. Study on shale oil reservoir characteristics of Shahejie Formation in Jiyang Depression, Bohai Bay Basin[D]. Chengdu: Chengdu University of Technology, 2018: 1−10.
[27] 何立成. 胜利油田沙河街组页岩油水平井固井技术[J]. 石油钻探技术,2022,50(2):45–50. HE Licheng. A cementing technology for horizontal shaleoil wells in Shahejie Formation of Shengli Oilfield[J]. Petroleum Drilling Techniques, 2022, 50(2): 45–50.
-
