Key Tools for Assuring a High Efficiency Heat Injection String for Multiple Thermal Fluids in Offshore Wells
-
摘要: 目前海上多元热流体热采使用的简易式注入管柱存在管柱整体隔热性较差和水平段多元热流体注入不均等问题。为此,研制了隔热关键工具和分段注热工具,并对注入水平段进行了分段设计,形成了海上多元热流体高效注入管柱。该管柱的隔热段主要由隔热油管、隔热接箍、隔热扶正器、隔热补偿器和隔热封隔器组成,具有良好的整体隔热性能,能减少注入热流体的热损失;水平段主要由均衡注入阀、分段封隔器和油管扶正器组成,能够实现水平段均匀注入。隔热关键工具和分段注热工具均能满足在330 ℃高温下长期工作的需求,隔热性能均达到D级,其中均衡注入阀已应用7井次,水平段均实现了均匀注入。研究表明,多元热流体高效注入管柱及其关键工具能够满足海上多元热流体热高效注入的要求。Abstract: At present, the simple heat injection string pipes used by multiple thermal fluids technology in offshore wells have poor whole-pipe thermal insulation, and are uneven in multiple thermal fluid injection of horizontal sections. In order to solve these problems, high-efficiency injection strings for offshore multiple thermal fluids were designed by developing key thermal insulation tools and step heat injection tools and by designing horizontal sections for heat injection by sections. The thermal insulation section of the string consists of insulated tubing, insulated coupling, insulated centralizer, insulated compensator and insulated packer. Due to its excellent insulation performance on the whole, the heat loss of injected thermal fluids dropped. Its horizontal section, which could implement even heat injection in horizontal sections, consisted of uniform fill-up valves, segmenting packers and tubing centralizers. All key insulated tools and step heat injection tools could meet the requirements for long-term operation at 330 degrees and with Grade D in heat insulation performance. The uniform heat allocation device had been applied 7 times to wells with implementation of uniform heat injection in horizontal sections. In summary, multiple thermal fluids could be injected efficiently offshore by using the high-efficiency multiple thermal fluid injection strings together with the corresponding key tools.
-
Keywords:
- multiple thermal fluids /
- thermal recovery /
- injection pipe string /
- packer /
- centralizer /
- compensator
-
-
[1] 唐晓旭,马跃,孙永涛.海上稠油多元热流体吞吐工艺研究及现场试验[J].中国海上油气,2011,23(3):185-188. Tang Xiaoxu,Ma Yue,Sun Yongtao.Research and field test of complex thermal fluid huff and puff technology for offshore viscous oil recovery[J].China Offshore Oil and Gas,2011,23(3):185-188. [2] 刘敏,高孝田,邹剑,等.海上特稠油热采SAGD技术方案设计[J].石油钻采工艺,2013,35(4):94-96. Liu Min,Gao Xiaotian,Zou Jian,et al.SAGD technology conceptual design of thermal recovery explore for offshore extra-heavy oil[J].Oil Drilling Production Technology,2013,35(4):94-96. [3] 林涛,孙永涛,孙玉豹,等.多元热流体返出气增产技术研究[J].断块油气田,2013,20(1):126-128. Lin Tao,Sun Yongtao,Sun Yubao,et al.Enhanced recovery technique of return gas from multiple thermal fluids[J].Fault-Block Oil Gas Field,2013,20(1):126-128. [4] 薛婷,檀朝东,孙永涛.多元热流体注入井筒的热力计算[J].石油钻采工艺,2012,34(5):61-64. Xue Ting,Tan Chaodong,Sun Yongtao.Thermodynamic calculation on multiple fluid in thermal recovery wellbore[J].Oil Drilling Production Technology,2012,34(5):61-64. [5] 梁丹,冯国智,曾祥林,等.海上稠油两种热采方式开发效果评价[J].石油钻探技术,2014,42(1):95-99. Liang Dan,Feng Guozhi,Zeng Xianglin,et al.Evaluation of two thermal methods in offshore heavy oilfields development[J].Petroleum Drilling Techniques,2014,42(1):95-99. [6] 房军,贾朋,薛世峰.水平井蒸汽均匀配注参数设计[J].石油机械,2010,38(3):31-33. Fang Jun,Jia Peng,Xue Shifeng.Uniform horizontal well steam injection allocation parameter design[J].China Petroleum Machinery,2010,38(3):31-33. [7] 韩允祉,盖平原,张紫军,等.深层稠油超临界压力注汽管柱设计[J].石油钻探技术,2005,33(3):64-65. Han Yunzhi,Ge Pingyuan,Zhang Zijun,et al.Design of steam injection pipe set for producing deep heavy oil under over critical pressure[J].Petroleum Drilling Techniques,2005,33(3):64-65. [8] 易勇刚,张传新,于会永,等.新疆油田水平井分段完井注汽技术[J].石油钻探技术,2012,40(6):79-83. Yi Yonggang,Zhang Chuanxin,Yu Huiyong,et al.Segregated completion and subsection steam injection for horizontal wells in Xinjiang Oilfield[J].Petroleum Drilling Techniques,2012,40(6):79-83. [9] 刘坤芳,张兆银,孙晓明,等.注蒸汽井套管热应力分析及管柱强度设计[J].石油钻探技术,1994,22(4):36-40,61. Liu Kunfang,Zhang Zhaoyin,Sun Xiaoming,et al.Analyses of steam-injected well casing thermal stress and casing string strength design[J].Petroleum Drilling Techniques,1994,22(4):36-40,61. [10] 刘花军,孙永涛,王新根,等.海上热采封隔器密封件的优选试验研究[J].钻采工艺,2015,38(3):80-83. Liu Huajun,Sun Yongtao,Wang Xingen,et al.Optimization test on seal elements of packers for offshore thermal recovery[J].Drilling Production Technology,2015,38(3):80-83. [11] GB/T 20970—2007/ISO 14310:2001 石油天然气工业井下工具:封隔器和桥塞[S]. GB/T 20970—2007/ISO 14310:2001 Petroleum and natural gas industries:downhole equipment:packers and bridge plugs[S]. [12] SY/T 6304—1997 注蒸汽封隔器及井下补偿器技术条件[S]. SY/T 6304—1997 Technical standard of thermal packer and expansion joint[S]. [13] SY/T 5324—2013 预应力隔热油管[S]. SY/T 5324—2013 Pre-stress insucated tubing[S]. -
