Development and Application of Downhole Dynamic Corrosion Test Device
-
摘要: 为了解江苏油田CO2腐蚀套管的机理及其影响因素，制定合理的套管防腐技术措施，自主研制了新型井下动态腐蚀试验装置，并利用该试验装置进行了井下动态腐蚀模拟试验。选择1/4圆弧N80钢挂片试样，模拟实际工况条件下流体对套管的腐蚀情况，对腐蚀速率及腐蚀形态进行测试评价，并对腐蚀产物的微观形貌进行了分析。试验结果显示，在试验研究的参数范围内，N80套管钢腐蚀速率较高，不同部位的平均腐蚀速率为0.168 9~0.571 8 mm/a，并随CO2分压、温度、流速增大而增大，表现出较严重的CO2局部腐蚀形态特征。微观形貌分析表明，流速是导致抽油泵吸入口附近套管腐蚀速率最大的主控因素，其腐蚀速率达到0.5718 mm/a，这与现场腐蚀套管穿孔情况相符。研究结果表明，该试验装置具有较好的模拟性和适用性，可为油套腐蚀机理试验研究提供新的测试手段。Abstract: In order to determine the influencing factors and mechanism of carbon dioxide corrosion in Jiangsu Oilfield and find a solution for casing corrosion,we independently developed dynamic corrosion experiment device,and carried out downhole dynamic corrosion experiments 1/4 arc steel sheet of Φ139.7 mm×Φ124.3 mm×16 was used to simulate carbon dioxide corrosion on casing at partial pressure of 0-2.5 MPa,temperature of 60-80 ℃,flow rate of 0.02-0.04 m/s,to evaluate the corrosion rate and corrosion morphology and analyze the micro-morphology of the corrosion products.Based on the experiment,casing corrosion mechanism was studied.Experimental results show that API N80 casing steel exhibits higher corrosion rate.The average corrosion rate is 0.168 9-0.571 8 mm/a,and would increases with the increase of the partial pressure of CO2,temperature and flow rate,resulting in serious carbon dioxide local corrosion morphology.The microstructure analysis shows that flow velocity is the main effect factor which causes corrosion of oil pump suction port near the casing,and its corrosion rate is 0.571 8 mm/a,which is consistent with the corrosion casing leakage situation on site.The research results show that the new experimental device can simulate the carbon dioxide corrosion accurately,providing a new test method for related experimental study on casing corrosion mechanism.
-
Keywords:
- casing /
- carbon dioxide corrosion /
- dynamic simulation /
- corrosion rate /
- Jiangsu Oilfield
-
-
[1] 张辉, 曲桂亮, 韩红霞, 等.临南油田油水井套损分析及防治对策[J].石油钻探技术, 2004, 32(6):22-24. Zhang Hui, Qu Guiliang, Han Hongxia, et al.Casing damages and preventions in the Linnan Oilfield[J].Petroleum Drilling Techniques, 2004, 32(6):22-24. [2] 侯立中, 吴俊霞.腐蚀引起钻柱刺漏的机理分析及预防措施[J].石油钻探技术, 2006, 34(2):26-28. Hou Lizhong, Wu Junxia.Mechanism analysis and preventive measures of drill string washout caused by corrosion[J].Petroleum Drilling Techniques, 2006, 34(2):26-28. [3] 毛克伟, 史茂成.油气井套管腐蚀原因与防腐措施[J].石油钻探技术, 1996, 24(1):31-36. Mao Kewei, Shi Maocheng.Cause and prevention of casing corrosion in oil wells[J].Petroleum Drilling Techniques, 1996, 24(1):31-36. [4] 林永学, 陈雷, 王立志.CO2腐蚀环境下油管防腐技术方法初探[J].石油钻探技术, 1999, 27(3):34-36. Lin Yongxue, Chen Lei, Wang Lizhi.Discussion on technology of anti-corrosion of tubing in the CO2 corrosive environment[J].Petroleum Drilling Techniques, 1999, 27(3):34-36. [5] 姜胜利, 郑玉贵, 乔岩欣, 等.高速喷射式冲刷腐蚀实验装置的研制及其实时动态电化学测试[J].腐蚀科学与防护, 2009, 21(5):489-491. Jiang Shengli, Zheng Yugui, Qiao Yanxin, et al.Design of a high-speed jet impingement erosion corrosion apparatus and in-situ electrochemical measurement[J].Corrosion Science and Protection Technology, 2009, 21(5):489-491. [6] 林玉珍, 雍兴跃, 徐瑞芬.动态腐蚀模拟实验装置的研制[J].全面腐蚀控制, 1995, 9(2):7-10. Lin Yuzhen, Yong Xingyue, Xu Ruifen.Development of an experimental device for dynamic simulation of corrosion[J].Total Corrosion Control, 1995, 9(2):7-10. [7] 田光.流速对二氧化碳腐蚀速率影响的研究[D].西安:西安石油大学石油工程学院, 2010. Tian Guang.A study of influence on carbon dioxide corrosion rate by velocity[D].Xi’an:Xi’an Shiyou University, College of Petroleum Engineering, 2010. [8] 万里平, 孟英峰, 梁发书.油气田开发中的二氧化碳腐蚀及其影响因素[J].全面腐蚀控制, 2003, 17(2):14-17. Wan Liping, Meng Yingfeng, Liang Fashu.Carbon dioxide corrosion and its influence factors in oil/gas field exploitation[J].Total Corrosion Control, 2003, 17(2):14-17. [9] 赵景茂, 顾明广, 左禹.碳钢在二氧化碳溶液中腐蚀影响因素的研究[J].北京化工大学学报, 2005, 32(5):71-74. Zhao Jingmao, Gu Mingguang, Zuo Yu.Influencing factors on corrosion of mild steel in carbon dioxide environment[J].Journal of Beijing University of Chemical Technology, 2005, 32(5):71-74. [10] 符中欣.含CO2段塞流对X60钢的腐蚀[J].油气田地面工程, 2009, 28(7):27-28. Fu Zhongxin.The corrosion of slug flow with dissolved CO2 on X60 steel[J].Oil-Gasfield Surface Engineering, 2009, 28(7):27-28. [11] 赵国仙, 严密林, 路民旭, 等.石油天然气工业中CO2腐蚀的研究进展[J].腐蚀与防护, 1998, 19(2):51-54. Zhao Guoxian, Yan Milin, Lu Minxu, et al.Advances in research of CO2 corrosion in oil and gas industry[J].Corrosion Protection, 1998, 19(2):51-54. [12] 赵章明.油气井腐蚀防护与材质选择指南[M].北京:石油工业出版社, 2011:71-73. Zhao Zhangming.Corrosion protection of oil and gas wells and material selection guide[M].Beijing:Petroleum Industry Press, 2011:71-73. [13] 林冠发, 白真权, 赵新伟, 等.CO2腐蚀产物膜形态结构与温度和压力的关系[J].石油机械, 2005, 33(2):1-4. Lin Guanfa, Bai Zhenquan, Zhao Xinwei, et al.Effect of temperature and pressure on profile of CO2 corrosion scales on oil well steels[J].China Petroleum Machinery, 2005, 33(2):1-4. [14] Waard C De, Milliams D E.Carbonic acid corrosion of steel[J].Corrosion, 1975, 31(5):177-181.
[15] 朱世东, 林冠发, 白真权, 等.油田套管P110钢腐蚀的影响因素[J].材料保护, 2009, 42(1):48-51. Zhu Shidong, Lin Guanfa, Bai Zhenquan, et al.Corrosion behavior of P110 steel CO2 atmosphere[J].Materials Protection, 2009, 42(1):48-51. [16] 龙凤乐, 郑文军, 陈长风, 等.温度、CO2分压、流速、pH值对X65管线钢CO2均匀腐蚀速率的影响规律[J].腐蚀与防护, 2005, 26(7):290-293. Long Fengle, Zheng Wenjun, Chen Changfeng, et al.Influence of temperature, CO2 partial pressure, flow rate and pH value on uniform corrosion rate of X65 pipeline steel[J].Corrosion Protection, 2005, 26(7):290-293. [17] 赵国仙, 严密林, 陈长风, 等.影响碳钢 CO2腐蚀速率因素的研究[J].石油矿场机械, 2001, 30(增刊1):72-73. Zhao Guoxian, Yan Milin, Chen Changfeng, et al.Studies on influence factors of CO2 corrosion rate[J].Oil Field Equipment, 2001, 30(supplement 1):72-73. [18] 赵国仙, 吕祥鸿, 韩勇, 等.流速对P110钢腐蚀行为的影响[J].材料工程, 2008(8):5-8. Zhao Guoxian, L Xianghong, Han Yong, et al.Effect of flow rate on CO2 corrosion behavior of P110 steel[J].Materials Engineering, 2008(8):5-8.
