Analysis and Experimental Research on Erosion of Cementing Sliding Sleeve
-
摘要: 为准确分析套管固井滑套长时间在固液两相流中冲蚀后的磨损情况及可靠性，在进行冲蚀理论分析和数值模拟的基础上，利用研制的冲蚀磨损试验装置，研究了特定工况下固井滑套带孔短节的冲蚀磨损情况，分析了滑套孔眼冲蚀磨损速率与孔眼数量、砂比及排量的关系，建立了冲蚀磨损速率新模型，研究了滑套带孔短节孔眼过流能力与冲蚀磨损速率的关系；同时，结合数值分析结果和试验数据，得到了A型材质滑套短节的冲蚀磨损系数。研究结果表明，当滑套孔眼为2个时，含砂流体对滑套孔眼周边的冲蚀磨损较为明显，且滑套孔眼冲蚀磨损速率与砂比呈线性关系，与排量呈指数关系。该研究结果可为套管固井滑套可靠性评估提供理论依据，且能够指导滑套压裂工具的现场应用。Abstract: In order to analyze the wear rate and reliability of cementing sliding sleeve after high discharge,high sand-fluid ratio and long-term erosion of solid-liquid flow,downhole tools’ erosion and wear were researched based on the erosion theory and numerical simulation.The effects of the number of ports,sand concentration and displacement on the wear rate were analyzed.New test equipment was designed and built to test the erosion wear of port collar of cementing sliding sleeve under certain working conditions.A new model of erosion rate was established and more research was conducted about the flow capacity of port collar of cementing sliding sleeve and its effect on the rate of erosion wear.By combining numerical analysis and test data,the erosion coefficient of cementing sliding sleeve made by type A material was obtained.Results showed that the hole erosion was more severe when the cementing sliding sleeve contains two holes.The erosion rate had a linear relationship with sand concentration and an exponential relationship with fluid displacement.This research provided theoretical basis and foundation for cementing sliding sleeve reliability evaluation and guide for sliding sleeve application in oilfield.
-
-
[1] 董云龙, 唐世忠, 牛艳花, 等.水平井套管固井滑套分段压裂完井存在问题及对策[J].石油钻采工艺, 2013, 35(1):28-30. Dong Yunlong, Tang Shizhong, Niu Yanhua, et al.Problems and measurements of sliding sleeve staged fracturing completion in casing cementing horizontal wells[J].Oil Drilling Production Technology, 2013, 35(1):28-30. [2] 郭朝辉, 魏辽, 马兰荣.新型无级差套管滑套及其应用[J].石油机械, 2012, 40(10):91-99. Guo Zhaohui, Wei Liao, Ma Lanrong.New type stepless casing sliding sleeve and its application[J].China Petroleum Machinery, 2012, 40(10):91-99. [3] 贾长贵, 路保平, 蒋廷学, 等.DY2HF深层页岩气水平井分段压裂技术[J].石油钻探技术, 2014, 42(2):85-90. Jia Changgui, Lu Baoping, Jiang Tingxue, et al.Multi-stage horizontal well fracturing technology in deep shale gas well DY2HF[J].Petroleum Drilling Techniques, 2014, 42(2):85-90. [4] 莫里斯·杜索尔特, 约翰·麦克力兰, 蒋恕.大规模多级水力压裂技术在页岩油气藏开发中的应用[J].石油钻探技术, 2011, 39(3):6-16. Dusseault Maurice, McLennan John, Jiang Shu.Massive multi-stage hydraulic fracturing for oil and gas recovery from low mobility reservoirs in China[J].Petroleum Drilling Techniques, 2011, 39(3):6-16. [5] 艾志久, 王琴, 李永革, 等.水平井分段压裂投球滑套球座冲蚀分析[J].石油机械, 2011, 39(10):61-63. Ai Zhijiu, Wang Qin, Li Yongge, et al.The horizontal well fracturing the sliding sleeve seat erosion analysis[J].China Petroleum Machinery, 2011, 39(10):61-63. [6] 张恒, 刘洋, 李强, 等.水平井裸眼分段压裂完井技术在苏里格气田的应用[J].石油钻探技术, 2011, 39(4):77-80. Zhang Heng, Liu Yang, Li Qiang, et al.Application of staged fracturing completion technology in horizontal openhole wells in Sulige Gas Field[J].Petroleum Drilling Techniques, 2011, 39(4):77-80. [7] 王尊策, 王森, 徐艳, 等.基于Fluent软件的喷砂器磨损规律数值模拟[J].石油矿场机械, 2012, 41(8):11-14. Wang Zunce, Wang Sen, Xu Yan, et al.Wear rule of the bypass crossover based on Fluent[J].Oil Field Equipment, 2012, 41(8):11-14. [8] 王尊策, 徐德奎, 徐艳, 等.水平井压裂喷砂器内流场的LDA试验研究[J].流体机械, 2012, 40(10):6-9. Wang Zunce, Xu Dekui, Xu Yan, et al.Experiment study of flow around bypass crossover sub in fracturing process of horizontal wells LDA[J].Fluid Machinery, 2012, 40(10):6-9. [9] 吴波.渣浆泵固液两相三维湍流及冲蚀磨损特性研究[D].长沙:中南大学, 2010:17-24. Wu Bo.Research on solid-liquid two-phase three-dimensional turbulence and erosion characteristics of slurry pump[D].Changsha:Central South University, 2010:17-24. [10] 赵丹妮.水平井压裂喷砂器喷射冲蚀数值模拟.大庆:东北石油大学, 2013:22-37. Zhao Danni.The numerical simulation of injection and erosion of horizontal well fractured sand blower.Daqing:Northeast Petroleum University, 2013:22-37. [11] Rytlewski G L, Cook J M.A study of fracture initiation pressures in cemented cased-hole wells without perforations[R].SPE 100572, 2008.
[12] Stegent Neil Alan, Howell Matt.Continuous multistage fracture-stimulation completion process in a cemented wellbore[R].SPE 125365, 2009.
-
