The Micro-Vibration Equation of Rock and Its Analysis Basing on the Principle of Least Action
-
摘要: 为了研究冲击钻井中钻具冲击频率、岩石固有频率等对破岩效率的影响，基于最小作用量原理，建立了岩石在压头冲击作用下的微振动方程，并以此为基础，分析了岩石的质量和固有频率、压头的冲击力和冲击频率以及时间等因素与岩石振动位移的关系。分析研究发现，岩石振动位移在平衡位置处上下变化，当压头冲击力为30 kN、岩石密度为2.39 g/cm3时，岩石的振动位移最大，分别为1.3和8 mm；固有频率为1000，1500和2000 Hz的岩石，分别在1000，1500和2000 Hz左右冲击频率下产生16，13和6 mm的最大振动位移。研究结果表明：岩石的振动位移曲线类似余弦曲线，振动位移与压头的冲击力成正比，与岩石的密度（质量）成反比；当压头的冲击频率与岩石的固有频率共振时，振动位移最大。Abstract: In order to study the effect of impact frequency of percussion drilling tools,natural frequency of rock and other factors on rock breaking effect in percussion drilling,the research on vibration mechanism of rock under harmonic excitation was carried out.In this paper,the micro-vibration equation of rock under the impact of indenter is established based on the principle of least action.Then the effect of mass and natural frequency of rock,impact force,impact time and impact frequency of indenter on vibration displacement were analyzed.The vibration displacement of rock fluctuates up and down at the equilibrium position.When the impact force of indenter is 30 kN or the density of rock is 2.39 g/cm3,the vibration displacement of rock will be the largest,1.3 mm and 2.8 mm respectively.Rocks with natural frequency of 1 000 Hz,1 500 Hz and 2 000 Hz generate maximum vibration displacement of 16 mm,13 mm and 6 mm at impact frequency of 1 000 Hz,1 500 Hz and 2 000 Hz respectively.The results show that the curve of vibration displacement of rock is a kind of cosine curve.The vibration displacement of rock is proportional to the impact force of indenter and is inversely proportional to the density(quality)of rock.When the impact frequency of indenter is equal to the natural frequency of rock,the maximum vibration displacement would be reached.
-
-
[1] 蒋宏伟, 刘永胜, 翟应虎, 等.旋冲钻井破岩力学模型的研究[J].石油钻探技术, 2006, 31(1):10-16. Jiang Hongwei, Liu Yongsheng, Zhai Yinghu, et al.Research on rock-crushing mechanics model in rotary and percussive drilling[J].Petroleum Drilling Techniques, 2006, 31(1):10-16. [2] Li Wei, Yan Tie, Li Siqi, et al.Rock fragmentation mechanisms and an experimental study of drilling tools during high-frequency harmonic vibration[J].Petroleum Science, 2013, 10(2):205-211.
[3] 许京国, 尤军, 陶瑞东, 等.自激振荡式冲击钻井工具在大港油田的应用[J].石油钻探技术, 2013, 41(4):116-119. Xu Jingguo, You Jun, Tao Ruidong, et al.Application of self-oscillating impact drilling tool in Dagang Oilfield[J].Petroleum Drilling Techniques, 2013, 41(4):116-119. [4] 周祥林, 张金成, 张东清.TorkBuster扭力冲击器在元坝地区的试验应用[J].钻采工艺, 2012, 35(2):15-17. Zhou Xianglin, Zhang Jincheng, Zhang Dongqing.Experimental application of TorkBuster torsional impactor in Yuanba Region[J].Drilling Production Technology, 2012, 35(2):15-17. [5] 吕晓平, 李国兴, 王震宇, 等.扭力冲击器在鸭深1井志留系地层的试验应用[J].石油钻采工艺, 2012, 34(2):99-101. Lv Xiaoping, Li Guoxing, Wang Zhenyu, et al.Experiment of torkbuster on Well YS1 in Silurian Formation[J].Oil Drilling Production Technology, 2012, 34(2):99-101. [6] 闫铁, 韩春杰, 毕雪亮.斜井眼内钻柱轴向振动的有限元分析[J].石油钻探技术, 2006, 34(4):5-8. Yan Tie, Han Chunjie, Bi Xueliang.The finite element analysis on axial vibration of drill string in deviated wells[J].Petroleum Drilling Techniques, 2006, 34(4):5-8. [7] 李子丰, 张永贵, 侯绪田, 等.钻柱纵向和扭转振动分析[J].工程力学, 2004, 21(6):203-210. Li Zifeng, Zhang Yonggui, Hou Xutian, et al.Analysis of longitudinal and torsion vibration of drillstring[J].Engineering Mechanics, 2004, 21(6):203-210. [8] 刘清友, 马德坤, 钟青.钻柱扭转振动模型的建立及求解[J].石油学报, 2000, 21(2):78-82. Liu Qingyou, Ma Dekun, Zhong Qing.A drilling string torsional vibration model and its solution[J].Acta Petrolei Sinica, 2000, 21(2):78-82. [9] 李夕兵, 左宇军, 马春德.动静组合加载下岩石破坏的应变能密度准则及突变理论分析[J].岩石力学与工程学报, 2005, 24(16):2814-2824. Li Xibing, Zuo Yujun, Ma Chunde.Failure criterion of strain energy density and catastrophe theory analysis of rock subjected to static-dynamic coupling loading[J].Chinese Journal of Rock Mechanics and Engineering, 2005, 24(16):2814-2824. [10] 周小平, 哈秋聆, 张永兴, 等.峰前围压卸荷条件下岩石的应力-应变全过程分析和变形局部化研究[J].岩石力学与工程学报, 2005, 24(18):3236-3245. Zhou Xiaoping, Ha Qiuling, Zhang Yongxing, et al.Analysis of localization of deformation and complete stress-strain relation for mesoscopic heterogenous brittle rock materials when axial stress is held constant while lateral confinement is reduced[J].Chinese Journal of Rock Mechanics and Engineering, 2005, 24(18):3236-3245. [11] 刘建锋, 徐进, 李青松, 等.循环荷载下岩石阻尼参数测试的试验研究[J].岩石力学与工程学报, 2010, 29(5):1036-1041. Liu Jianfeng, Xu Jin, Li Qingsong, et al.Experimental research on damping parameters of rock under cyclic loading[J].Chinese Journal of Rock Mechanics and Engineering, 2010, 29(5):1036-1041. [12] 伊鹏, 刘衍聪, 高凯, 等.基于有限元法的单根钻杆动力学仿真模拟分析[J].石油钻采工艺, 2009, 31(4):12-15, 20. Yi Peng, Liu Yancong, Gao Kai, et al.Study on dynamic simulation research of single drill pipe based on finite element method[J].Oil Drilling Production Technology, 2009, 31(4):12-15, 20. [13] 况雨春, 马德坤, 刘清友, 等.钻柱-钻头-岩石系统动态行为仿真[J].石油学报, 2001, 22(3):81-85. Kuang Yuchun, Ma Dekun, Liu Qingyou, et al.Computer simulation on dynamic action of drillstring-bit-rock system[J].Acta Petrolei Sinica, 2001, 22(3):81-85. -
