Numerical Simulation on Cuttings Carrying Regularity for Horizontal Wells Drilled with Coiled Tubing
-
摘要: 连续油管钻水平井过程中,井底岩屑在重力作用下容易沉积在井壁下侧,形成岩屑床;连续油管又受到排量小、钻柱无法旋转等因素限制,造成井眼净化效率较低。针对这一问题,在欧拉坐标系下考虑相间滑移速度和颗粒流的影响,建立了微小井眼水平井岩屑运移的混合物漂移模型,采用Realize κ-ε湍流模式及SIMPLEC算法进行数值计算,研究了钻井液排量、环空偏心度、岩屑直径、井斜角和钻井液黏度等参数对偏心环空岩屑运移的影响,得到了各种条件下环空岩屑速度和浓度的分布规律。研究表明:随着钻井液排量增大、环空偏心度减小、岩屑直径减小、井斜角减小及钻井液黏度提高,连续油管水平井岩屑运移效率提高。Abstract: During the course of drilling horizontal well with coiled tubing,cuttings easily settle on the low side of borehole to form cuttings bed due to action of gravity.The features in the coiled tubing drilling,such as small pumping rate and no rotation in drill string etc,have made hole cleaning efficiency very low.In view of this problem,considering the interphase slip velocity and particle flow influence based on the Eulerian coordinate system,a mixture drift model of cuttings carrying in a horizontal slim-hole was established,which uses Realize κ-ε turbulence model and the SIMPLEC algorithm for numerical calculation, and studied the effects on eccentric annular cuttings migration by flow rate,annular eccentricity,cuttings size,mud viscosity and hole angle,to determine distribution pattern of cuttings velocity and concentration in annular space under all conditions.The study shows that cuttings carrying efficiency will increase in coiled tubing drilling horizontal wells with the change of several factors,i.e.the increase of flow rate of drilling fluid,the decrease of annular eccentricity,decrease of cuttings size and well inclination,and the increase of mud viscosity.
-
-
[1] Loveland M J,Pedota J L.Case history:efficient coiled-tubing sand cleanout in a high-angle well using a complete integrated cleaning system[R].SPE 94179,2005.
[2] Zhou W,Amaravadi S,Roedsjoe M.Valhall field coiled-tubing proppant cleanout process optimization[R].SPE 94131,2005.
[3] 李增强,邵宣涛,李希亮.油田冲砂清洁生产工艺的研究应用[J].油气田环境保护,2002,12(1):28-30. Li Zengqiang,Shao Xuantao,Li Xiliang.Research and application on clean production process of sand-washing in oilfield[J].Environmental Protection of Oil Gas Fields,2002,12(1):28-30. [4] Li J,Walker S.Sensitivity analysis of hole cleaning parameters in directional wells[J].SPE 54498,1999.
[5] Engel S P,Rae P.New mothods for sand cleanout in deviated wellbores using small diameter coiled tubing[R].SPE 77204,2002.
[6] Kelessidis V C,Bandelis G E.Flow patterns and minimum suspension velocity for efficient cuttings transport in horizontal and deviated wells in coiled-tubing drilling[J].SPE Drilling Completion,2004,19(4):213-227.
[7] Ramadan A,Skalle P,Saasen A.Application of a three-layer modeling approach for solids transport in horizontal and inclined channels[J].Chemical Engineering Science,2005,60(10):2557-2570.
[8] 郭晓乐,汪志明,龙芝辉.大位移钻井全井段岩屑动态运移规律[J].中国石油大学学报:自然科学版,2011,35(1):72-76. Guo Xiaole,Wang Zhiming,Long Zhihui.Transient cuttings transport laws through all sections of extended reach well[J].Journal of China University of Petroleum,2011,35(1):72-76. [9] 王治中,邓金根,孙福街,等.井筒砂粒运移规律室内模拟实验研究[J].石油学报, 2006,27(4):130-132,138. Wang Zhizhong,Deng Jingen,Sun Fujie,et al.Experimental study on sand grain migration in wellbore[J].Acta Petrolei Sinica,2006,27(4):30-132,138. [10] 沈忠厚,王海柱,李根生.超临界CO2钻井水平井段携岩能力数值模拟[J].石油勘探与开发,2011,38(2):233-236. Shen Zhonghou,Wang Haizhu,Li Gensheng.Numerical simulation of the cutting-carrying ability of supercritical carbon dioxide drilling at horizontal section[J].Petroleum Exploration and Development,2011,38(2):233-236. [11] 马东军,李根生,郭瑞昌,等.管内转向径向水平井携岩规律数值模拟[J].石油机械,2013,41(11):6-10. Ma Dongjun,Li Gensheng,Guo Ruichang,et al.Numerical simulation of the cuttings-carrying law in radical horizontal well[J].China Petroleum Machinery,2013,41(11):6-10. -
