基于DPPM编码的EM-MWD节电技术研究

王家进

王家进. 基于DPPM编码的EM-MWD节电技术研究[J]. 石油钻探技术, 2013, 41(6): 106-109. DOI: 10.3969/j.issn.1001-0890.2013.06.021
引用本文: 王家进. 基于DPPM编码的EM-MWD节电技术研究[J]. 石油钻探技术, 2013, 41(6): 106-109. DOI: 10.3969/j.issn.1001-0890.2013.06.021
Wang Jiajin. EM-MWD Power Saving Technique Based on DPPM[J]. Petroleum Drilling Techniques, 2013, 41(6): 106-109. DOI: 10.3969/j.issn.1001-0890.2013.06.021
Citation: Wang Jiajin. EM-MWD Power Saving Technique Based on DPPM[J]. Petroleum Drilling Techniques, 2013, 41(6): 106-109. DOI: 10.3969/j.issn.1001-0890.2013.06.021

基于DPPM编码的EM-MWD节电技术研究

基金项目:

国家科技重大专项“电磁波地质导向工具及远距离穿针技术与装备”(2008ZX05036-004)和“旋转导向及随钻测录、酸性气层测试技术与装备”(2011ZX05021-005)部分研究内容。

详细信息
    作者简介:

    王家进(1972- ),男,河南民权人,1993年毕业于大庆石油学院钻井工程专业,1996年获中国石油勘探开发研究院油气井工程专业硕士学位,高级工程师,主要从事随钻测量、井下控制工程技术研究。

  • 中图分类号: TE927

EM-MWD Power Saving Technique Based on DPPM

  • 摘要: 为了延长EM-MWD电池的使用周期,研究了一种EM-MWD节电技术。利用差分脉冲位置调制(DPPM)编码占空期较长的特点,采用DPPM编码进行调制,在占空期关闭EM-MWD发射机和射频电路,仅在脉冲信号发生期发射无线电磁波载波,达到降低EM-MWD发射机能耗的目的。根据节电效率和编码效率的定义,指出DPPM编码码组位数和编码时隙是确定其节电效率和编码效率的2个关键参数。编码码组位数增加,节电效率增大,而编码效率降低,兼顾编码效率和节电效率的最优码组位数为3或4。缩短编码时隙,可以显著提高编码效率,而节电效率下降要缓慢些。几种常用时隙的分析表明,在保证适当误码率的情况下,较短的时隙,有利于在编码效率与节电效率之间做到平衡。研究结果表明,在DPPM编码占空期关闭发射机和射频电路,可以显著降低能耗,延长电池更换周期。
    Abstract: A kind of power saving technique has been developed in order to extend the battery replacement cycle of EM-MWD.With longer duty period,DPPM is employed for signal modulation of EM-MWD to save power.The transmitter and radio frequency circuit of EM-MWD are shut off power during the loner duty period and only powered on for radio emission in pulse phase,which can significantly reduce the EM-MWD transmitter power consumption.Coding block bits and time slot are two key parameters to determine energy saving efficiency and coding efficiency of DPPM.Energy saving efficiency increases with coding block bits,but coding efficiency decreases.Matching the coding efficiency and energy saving efficiency,the optimal block bits number is 3 or 4.Shortening coding time slot can significantly improve coding efficiency,while energy saving efficiency slowly decreases.On the premise of ensuring appropriate bit error rate,three kinds of common time slot were analyzed,which showed that the shorter time slots was favorable for the tradeoff between coding efficiency and energy saving efficiency.Analysis and examples showed that powering off transmitter and radio frequency circuit during DPPM code duty period could significantly reduce the energy consumption and prolong battery replacement cycle.
  • [1] 李林, 弓志谦, 王磊, 等.扩展EM-MWD传输深度及提高可靠性的方法与对策[J].钻采工艺, 2010, 33(4):25-27, 38. Li Lin, Gong Zhiqian, Wang Lei, et al.Method for extend telemetry depth of EM-MWD[J].Drilling Production Technology, 2010, 33(4):25-27, 38.
    [2] 彭烈新, 苏义脑, 盛利民, 等.基于电磁随钻测量系统的功率自适应分配方法研究[J].钻采工艺, 2010, 33(4):1-4. Peng Liexin, Su Yinao, Sheng Limin, et al.Research on self-adapting allocation technique based on the electromagnetic drilling while measurement system[J].Drilling Production Technology, 2010, 33(4):1-4.
    [3] 赵黎, 柯熙政, 刘健.OWC中DPPM调制解调技术研究[J].激光杂志, 2007, 28(2):63-64. Zhao Li, Ke Xizheng, Liu Jian.Research on differential pulse-position modulation in optical wireless communication[J].Laser Journal, 2007, 28(2):63-64.
    [4]

    Shiu Da-Shah, Kahn Jseph M.Differential pulse-position modulation for power-efficient optical communication[J].IEEE Transactions on Communications, 1999, 47(8):1201-1210.

    [5] 赵黎.大气激光通信DPPM调制解调技术研究[D].西安:西安理工大学, 2006:19-23, 29-35. Zhao Li.Research of DPPM for laser communication in atmosphere[D].Xi’an:Xi’an University of Technology, 2006:19-23, 29-35.
    [6] 宁武, 孟丽囡, 李雪, 等.输入浪涌电流抑制模块在AC/DC变换器的应用[J].电源技术应用, 2004, 7(1):20-24. Ning Wu, Meng Linan, Li Xue, et al.Input surge current restraining module in use for AC/DC converter[J].Power Supply Technologies and Applications, 2004, 7(1):20-24.
    [7] 潘启辉, 熊运远, 卢良飞.一种抑制上电脉冲电流的延迟开关电路:中国, 201110043397.9[P].2011-06-15. Pan Qihui, Xiong Yunyuan, Lu Liangfei.A delay switch circuit for restraining power-on surge current:China, 201110043397.9[P].2011-06-15.
    [8] 孔财, 谷俊杰, 吴福宽.一种抑制大功率风扇瞬间冲击电流的节能设计方法及装置: 中国, 201210219789.0[P].2012-11-21. Kong Cai, Gu Junjie, Wu Fukuan.An energy-saving design method and apparatus for restraining instant surge current of high-power fan:China, 201210219789.0[P].2012-11-21.
