Sectional Design for Anti-Gas Channeling Cementing
-
摘要: 为指导防气窜固井压稳设计,避免过压稳或欠压稳,研究了防气窜固井分段设计方法。基于环空水泥浆液柱中不同深度的水泥浆因温度不同导致静胶凝强度增长速度不同,以及不同深度的压力损失也不同的实际情况,对环空水泥浆的液柱压力损失进行分段计算。设定水泥浆液柱静胶凝强度的增长自上而下是线性增长,通过调整水泥浆性能控制分段水泥浆静胶凝强度的发展,使尾浆静胶凝强度达到240 Pa时,领浆平均静胶凝强度小于48 Pa,建立了水泥浆液柱压力损失精确计算模型,提出了分段设计方法和压稳判定方法。在川东北地区100多口气井固井施工设计中应用该方法,固井防气窜成功率达到100%。该方法为防气窜固井环空设计提供了理论计算模型。Abstract: To guide anti-gas channeling cementing design,and avoid circulation loss or underbalanced gas channeling,sectional design method for anti-gas channeling cementing was developed.Since the slurry temperature in annulus varies with depth,the build-up of gel strength and pressure drop are different at different depths,the hydraulic pressure loss of slurry column is calculated in sections.By adjusting slurry performance and setting the growth of gel strength to be linear from top to bottom of slurry column,and making gel strength of tail slurry up to 240 Pa,the average gel strength of lead slurry is less than 48 Pa.An accurate calculation model of hydraulic pressure loss of slurry was established,and sectional design and balanced cementing methods were developed.The methods have been used to cementing design in more than 200 gas wells in northeastern Sichuan province,the success rate of anti-gas channeling has been 100%.The method provides an effective calculation model for anti-gas channeling cementing design.
-
Keywords:
- well cementing /
- cement slurry /
- gel strength /
- gas channeling /
- section
-
-
[1] Bonett A,汪海阁.探索固井时气侵的根源[J].国外钻井技术,1999,14(4):52-62. Bonett A,Wang Haige.Exploring the source of gas migration during cementing job[J].Foreign Drilling Technology,1999,14(4):52-62. [2] Sutton D L,Ravi K M.New methods for determining downhole properties that affect gas migration and annular sealing[R].SPE 19520,1989.
[3] 周仕明,丁士东,曲中启.利用修正SPN值预测环空气窜[J].石油钻探技术,2001,29(5):31-32. Zhou Shiming,Ding Shidong,Qu Zhongqi.Predicting gas cut in annulus with modified coefficient-SPN[J].Petroleum Drilling Techniques,2001,29(5):31-32. [4] 孙展利.水泥浆的沉降失重研究[J].石油钻采工艺,1997,19(2):31-36. Sun Zhanli.Study on weight loss of cement slurry due to precipitation[J].Oil Drilling Production Technology,1997,19(2):31-36. [5] 牛新明,张克坚,丁士东,等.川东北地区高压防气窜固井技术[J].石油钻探技术,2008,36(3):10-15. Niu Xinming,Zhang Kejian,Ding Shidong,et al,Gas migration prevention cementing technologies in northeast Sichuan Area[J].Petroleum Drilling Techniques,2008,36(3):10-15. [6] Sabins F L,Tinsley J M,Sutton D L.Transition time of cement slurries between the fluid and set state[R].SPE 9285,1982.
[7] 刘乃震,王廷瑞,刘孝良,等.水泥浆防气窜性能设计及合理的浆体组成研究[J].天然气工业,2002,22(3):49-52. Liu Naizhen,Wang Tingrui,Liu Xiaoliang,et al.Gas-channeling prevention performance design of cement slurry and reasonable slurry composition[J].Natural Gas Industry,2002,22(3):49-52. [8] Shipley S E,Mitchell B J.The effect of hole inclination on gas migration[R].SPE 20432,1990.
[9] 张兴才.水泥浆网架结构胶凝悬挂失重机理研究[D].南充:西南石油学院石油工程学院,2002. Zhang Xingcai.Research of mechanism of pressure loss caused by grid structure in cementing slurry[D].Nanchong:School of Petroleum Engineering,South Petroleum Institute,2002. [10] 李铁成,周仕明.普光气田整体固井工艺[J].石油钻探技术,2011,39(1):78-82. Li Tiecheng,Zhou Shiming.Overall cementing technology for Puguang Gas Field[J].Petroleum Drilling Techniques,2011,39(1):78-82. [11] 王春江,杨玉坤,翟建明.普光"三高"气田安全钻井技术[J]. 石油钻探技术,2011,39(1):12-17. Wang Chunjiang,Yang Yukun,Zhai Jianming.Safe drilling techniques applied in Puguang HPHT sour gas field[J].Petroleum Drilling Techniques,2011,39(1):12-17. [12] 隋梅.胜利油田深探井固井技术难点与对策[J].石油钻探技术,2013,41(3):73-79. Sui Mei.Technical difficulties and countermeasures in cementing of deep exploration well in Shengli Oilfield[J].Petroleum Drilling Techniques,2013,41(3):73-79.
