Laboratory Study of a Novel Drilling Fluid Based on Emulsion Phase Diversion Technology
-
摘要: 为有效解决油基钻井液应用中存在的固井质量较差、环境污染严重等问题,采用有机胺质子化可逆原理,赋予油基钻井液以乳化相态的可逆性,研制了一套可逆乳化钻井液体系。该钻井液体系的配方为5#白油+25.0%CaCl2溶液+1.0%有机土+0.5%石灰+1.0%润湿剂RS+4.0%乳化剂ET,油水比为50:50,密度为1.2 kg/L。通过室内试验对该钻井液体系进行了全面的性能评价,结果表明,通过酸触相反转和碱触相回转,可实现W/O型与O/W型间自由转换;且转换前后的钻井液性能良好:破乳电压达500~900 V,抗温达180 ℃,高温高压滤失量小于15 mL,流变性与传统逆乳化钻井液相当,可抗10%硫酸钙、20%钻屑污染,渗透率恢复率和滚动回收率都达90%以上,泥饼和含油钻屑更易处理。这说明,研制的可逆乳化钻井液体系兼备油基钻井液和水基钻井液的优点,且各项性能均为优良,能解决常规油基钻井液应用中存在的问题。Abstract: A novel reversible emulsion drilling fluid which is useful in resolving the contradiction between drilling efficiency,cementing and environmental effect has been invented based on the protonation reversibility of amine.The new drilling fluid system has reversible emulsion-phase behavior.The formulation of the reversible emulsion drilling fluid was:5# white oil+25.0% CaCl2 brine+1.0% organoclay+0.5% lime+4.0% reversible emulsifier ET+1.0% wetting agent RS,oleaginous fluid to non-oleaginous fluid-ratio was 50/50,drilling fluid density was 1.2 kg/L.Comprehensive performance evaluation with laboratory test showed that the new drilling fluid could be readily and reversibly converted from a water-in-oil emulsion to an oil-in-water emulsion and back to a water-in-oil emulsion using an acid-base chemical switch.And before and after converting the emulsion mud maintains good performance,with emulsion-breaking voltage of 500-900 V,resistance to high temperature of 180 ℃,HTHP filter loss of less than 15 mL,rheology comparable with traditional invert emulsion drilling fluid,and resistance to 10% calcium sulfate and 20% cuttings pollution.Additionally,both permeability recovery value and rolling recovery ratio were above 90%,and the filter cake and oily cuttings could be treated easily.This suggests that the reversible invert emulsion drilling fluid has both merits of oil-based fluid and water-based fluid,and all properties are excellent.The reversible invert emulsion drilling fluid is capable of resolving the problems with the application of conventional oil-based drilling fluid.
-
Keywords:
- oil base drilling fluid /
- emulsion inverse /
- formation protection /
- oily cutting
-
-
[1] Arvind D P.Reversible invert emulsion frilling fluids:a quantum leap in technology[R].IADC/SPE 47772,1998.
[2] 何健,康毅力,高波.滤饼返排压力的实验研究[J].钻井液与完井液,2005,22(3):29-31. He Jian,Kang Yili,Gao Bo.Experimental study on filter cake pressure during flowback[J].Drilling Fluid Completion Fluid,2005,22(3):29-31. [3] 岳前升,向兴金,舒福昌,等.水平井裸眼完井条件下的油基钻井液滤饼解除技术[J].钻井液与完井液,2005,22(3):32-33. Yue Qiansheng,Xiang Xingjin,Shu Fuchang,et al.Removing technique of oil based mud cake in open hole completion of horizontal well[J].Drilling Fluid Completion Fluid,2005,22(3):32-33. [4] 彭志刚,冯茜,杨景辉,等.一种清除钻井液滤饼的新技术[J].钻井液与完井液,2009,26(5):22-23. Peng Zhigang,Feng Qian,Yang Jinghui,et al.A new technology for the removal of mud cake[J].Drilling Fluid Completion Fluid,2009,26(5):22-23. [5] 李颖颖,徐同台,王海良.水平井及多分支井钻井液滤饼的生物酶清除技术[J].钻井液与完井液,2010,27(2):74-77. Li Yingying,Xu Tongtai,Wang Hailiang.Remove mud cake in horizontal and multi-lateral wells using bio-enzyme[J].Drilling Fluid Completion Fluid,2010,27(2):74-77. [6] 袁萍,谢葵,马巍,等.复合缓释型钻井液滤饼清除剂的研究与应用[J].钻井液与完井液,2011,28(4):32-35. Yuan Ping,Xie Kui,Ma Wei,et al.Study and application of compound sustained-release mud cake scavenger[J].Drilling Fluid Completion Fluid,2011,28(4):32-35. [7] Street C G,Guigard S E.Treatment of oil-based drilling waste using supercritical carbon dioxide[J].Journal of Canadian Petroleum Technology,2009,48(6):26-29.
[8] Pierce D,Gaddis C,Wood B.Lessons learned from treating 500,000 tons of oil-based drill cuttings on five continents[R].IADC/SPE 99027,2006.
[9] Charles M,Sayle S.Offshore drill cuttings treatment technology evaluation[R].SPE 126333,2010.
[10] Robinson J P,kingman S W,Snape C E,et al.Remediation of oil-contaminated drill cuttings using continuous microwave heating[J].Chemical Engineering Journal,2009,152(2/3):458-463.
[11] 谢水祥,蒋官澄,陈勉,等.利用化学强化分离:无害化技术处理废弃油基钻井液[J].环境工程学报,2011,5(2):425-430. Xie Shuixiang,Jiang Guancheng,Chen Mian,et al.Using chemical strengthening separation:harmless technology for the treatment of waste oil-based drilling fluid[J].Chinese Journal of Environmental Engineering,2011,5(2):425-430. [12] Rojas-Avelizapa N G,Roldán-Carrullo T,Zegarra-Martínez H,et al.A field trial for an ex-situ bioremediation of a drilling mud-polluted site[J].Chemosphere,2007,66(9):1595-1600.
[13] 李怀科,王楠,田荣剑,等.气制油合成基钻井液低温高压条件下流变模式研究[J].石油钻探技术,2011,39(1):44-47. Li Huaike,Wang Nan,Tian Rongjian,et al.Rheological study of GTL based drilling fluids at low temperature and high pressure[J].Petroleum Drilling Techniques,2011,39(1):44-47. [14] 胡友林,乌效鸣,岳前升,等.深水钻井气制油合成基钻井液室内研究[J].石油钻探技术,2012,40(6):38-42. Hu Youlin,Wu Xiaoming,Yue Qiansheng,et al.Labratory reasearch on deep water GTL synthetic-based drilling fluid[J].Petroleum Drilling Techniques,2012,40(6):38-42. [15] 耿铁,张岩,吴彬,等.新型合成基钻井液体系的研制与应用[J].石油天然气学报,2009,31(2):299-300,321. Geng Tie,Zhang Yan,Wu Bin,et al.Research on a new synthetic drilling fluid and its application[J].Journal of Oil and Gas Technology,2009,31(2):299-300,321. [16] 李传宪,杨飞.乳状液的转相特性研究[J].化学进展,2009,21(6):1124-1133. Li Chuanxian,Yang Fei.Phase inversion characteristics of emulsions[J].Progress in Chemistry,2009,21(6):1124-1133. [17] 华桂友,舒福昌,向兴金,等.可逆转乳化钻井液乳化剂的研究[J].精细石油化工进展, 2009,10(10):5-8. Hua Guiyou,Shu Fuchang,Xiang Xingjin,et al.Research on emulsifier for reversible emulsion drilling fluid[J].Advances in Fine Petrochemicals,2009,10(10):5-8. [18] 华桂友,舒福昌,向兴金,等.可逆转油基钻井液体系配制及性能评价[J].精细石油化工进展, 2009,10(11):8-11. Hua Guiyou,Shu Fuchang,Xiang Xingjin,et al.Preparation and evaluation of the reversible oil based drilling fluid[J].Advances in Fine Petrochemicals,2009,10(11):8-11. [19] 鄢捷年.钻井液工艺学[M].东营:中国石油大学出版社,2006:240-241. Yan Jienian.Drilling fluid technology[M].Dongying:China University of Petroleum Precess,2006:240-241.
