深井小井眼定向随钻扩孔技术研究与应用

白彬珍, 臧艳彬, 周伟, 黄河淳, 孙吉凯

白彬珍, 臧艳彬, 周伟, 黄河淳, 孙吉凯. 深井小井眼定向随钻扩孔技术研究与应用[J]. 石油钻探技术, 2013, 41(4): 73-77. DOI: 10.3969/j.issn.1001-0890.2013.04.016
引用本文: 白彬珍, 臧艳彬, 周伟, 黄河淳, 孙吉凯. 深井小井眼定向随钻扩孔技术研究与应用[J]. 石油钻探技术, 2013, 41(4): 73-77. DOI: 10.3969/j.issn.1001-0890.2013.04.016
Bai Binzhen, Zang Yanbin, Zhou Wei, Huang Hechun, Sun Jikai. Study and Application of Reaming While Drilling in Deep Directional Wells[J]. Petroleum Drilling Techniques, 2013, 41(4): 73-77. DOI: 10.3969/j.issn.1001-0890.2013.04.016
Citation: Bai Binzhen, Zang Yanbin, Zhou Wei, Huang Hechun, Sun Jikai. Study and Application of Reaming While Drilling in Deep Directional Wells[J]. Petroleum Drilling Techniques, 2013, 41(4): 73-77. DOI: 10.3969/j.issn.1001-0890.2013.04.016

深井小井眼定向随钻扩孔技术研究与应用

基金项目:

国家科技重大专项课题"碳酸盐岩缝洞型油藏钻井技术完善与推广"(编号:2011ZX05049-002)资助。

详细信息
    作者简介:

    白彬珍(1981—),男,山东沂水人,2004年毕业于石油大学(华东)石油工程专业,中国石油大学(北京)在读硕士研究生,工程师,主要从事深井超深井、定向井钻井相关科研及技术支撑工作。

  • 中图分类号: TE247

Study and Application of Reaming While Drilling in Deep Directional Wells

  • 摘要: 深井小井眼斜井段钻后扩孔存在扭矩大、工具易折断、周期长、扩孔效果差等技术难题,为此,开展了定向随钻扩孔研究与试验。在分析国内外主要扩孔工具的特点和现场应用效果的基础上,优选CSDR型双心钻头作为扩孔工具,配套475K4570型可调式单弯螺杆钻具为其提供动力。根据水功率合理分配原则,优化了钻头喷嘴组合和水力参数,在THA井进行了现场试验。THA井一趟钻钻进153 m,成功实现了井斜14.13°~42.50°段内的定向随钻扩孔,作业段井眼轨迹平滑,平均全角变化率5.554°/30m,平均井径173.99 mm,作业周期较设计周期缩短50%。现场试验表明,双心钻头配合螺杆动力钻具可以实现深井小井眼大斜度段的定向随钻扩孔作业,扩孔效果好,作业周期短,是进行斜井段扩孔作业的有效技术手段。
    Abstract: In order to address technical difficulties in reaming after drilling in directional wells,such as high torque,ease in breakage of reaming tools,long reaming time and poor reaming result,study and test of reaming while directional drilling were carried out.Through analysis of features of reaming tools at home and abroad as well as field application,CSDR bi-center bit was selected as the reaming tool,matched with 475K4570 adjustable mud motor providing force.The nozzle combination and hydraulic parameters were optimized according to the principle of rational distribution of hydraulic power.In the Well THA,successful reaming while directional drilling was realized in China for the first time,at the curve section from an inclination of 14.13°to 42.50°,the reaming section is smooth,with an average rate of over-all angle change of 5.554°/30m and an average hole size as 173.99 mm,saving 50% of the reaming time.Field test shows bi-center bit,matched with PDM,can realize reaming while directional drilling in deep slim hole.Good reaming effect and short reaming time have made it become an effective means of reaming in directional well section.
  • [1] 郭元恒,张进双.元坝1-侧1井超深小井眼侧钻井技术[J].石油钻探技术,2010,38(6):113-115. Guo Yuanheng,Zhang Jinshuang.Sidetrack technology of Well Yuanba1-C1 with ultra deep slim hole[J].Drilling Petroleum Techniques,2010,38(6):113-115.
    [2]

    Barton S,Garcia A,Luther C,et al.Unique bi-center technology delivers in demanding directional applications[R].SPE 121950,2009.

    [3]

    Rodman Dave,Wong Thomas,Chong Adrian C.Steerable hole enlargement technology in complex 3D directional wells[R].SPE 80476,2003.

    [4] 石晓兵,刘鹏,吴应凯,等.RWD随钻扩眼下部钻具组合的强度分析[J].钻采工艺,2007,30(1):8-9. Shi Xiaobing,Liu Peng,Wu Yingkai,et al.A BHA strength analysis of reaming while drilling[J].Drilling Production Technology,2007,30(1):8-90.
    [5] 马清明,王瑞和.随钻扩孔工具及技术研究[J].天然气工业,2006,26(3):71-74. Ma Qingming,Wang Ruihe.Study on tools and techniques of teaming while drilling[J].Natural Gas Industry,2006,26(3):71-74.
    [6] 申守庆,周润才.美国十大钻头公司的十大钻头新技术[J].国外油田工程,2002,8(7):14-20. Shen Shouqing,Zhou Runcai.Bits help operators achieve objectives[J].Foreign Oil Field Engineering,2002,8(7):14-20.
    [7] 孙明光.PDC扩眼钻头的研制与试验[J].石油钻探技术,2006,34(3):62-63. Sun Mingguang.Development and test of a PDC reamer[J].Petroleum Drilling Techniques,2006,34(3):62-63.
    [8]

    Morrison W,Baggal Z,Baxendale B,et al.Optimizing wellbore design using solid expandable tubular and bi-center bit technologies[R].SPE 92886,2005.

    [9] 刘匡晓,魏士军,郭金爱,等.川东北超深水平井轨迹控制方法优选[J].断块油气田,2011,18(2):254-255. Liu Kuangxiao,Wei Shijun,Guo jin’ai,et al.Optimization of trajectory control technique of ultra-deep horizontal well in Northeast Sichuan Area[J].Fault-Block Oil Gas Field,2011,18(2):254-255.
