Mechanism of Effect of Relative Humidity on Creep Behavior of Gypsum Rock
-
摘要: 为了弄清盐膏岩在井下环境下的蠕变规律,对盐膏岩蠕变规律影响机理进行了研究。采用调节盐溶液中含盐量的方法来控制岩样周围环境的相对湿度值,并在相对湿度为35%,65%,95%的条件下,进行围压分别为0,2,5 MPa的三轴短期压缩试验和单轴应力为10 MPa的蠕变试验。相对湿度从35%增加到95%,盐膏岩岩样强度由38.2 MPa降至35.2 MPa;弹性模量和泊松比变化量小。相对湿度为95%时,盐膏岩岩样产生负向的体积应变(膨胀);相对湿度为35%时,盐膏岩岩样产生正向体积应变(收缩)。研究结果表明,盐膏岩的强度对于相对湿度的变化不很敏感;结合Heard模型,利用蠕变激活能可以解释相对湿度对体应变速率的影响;晶体到毛细管空间的水分子相互运移的机械化学机制,可以解释相对湿度对体应变的影响。研究得到盐膏岩井下真实的蠕变规律,为盐膏层安全钻井提供了理论依据。Abstract: In order to find out the creep behavior of salt-gypsum under the down hole conditions,the mechanism affecting salt-gypsum creep was studied.By adjusting the concentration of salt in the salt solution to control the relative humidity around the rock samples,the uni-axial compression test was carried out at 10 MPa and tri-axial compression tests were carried out at confining pressures of 0,2 and 5 MPa under relative humidity of 35%,65% and 95% respectively.It was found that in a short-term test of salt-gypsum rock,the rock strength displays a downward trend from 38.2 MPa to 35.2 MPa with the increase of relative humidity from 30% to 90%,the change in Young’s modulus and Poisson’s ratio is small.When the relative humidity is 95%,the sample generates negative volumetric strain (expansion) and when the relative humidity is 35%,the sample generates positive volumetric strain (shrinkage).The study shows the strength of salt-gypsum is not highly sensitive to the change of relative humidity;and combined with the Heard model,the impact of relative humidity on the volumetric strain rate can be explained by the theory of creep activation energy;and the influence of relative humidity on the volumetric strain can be explained by the mechanical-chemical mechanisms of mutual migration of water molecules between the crystal and capillary spaces.The creep behavior of salt-gypsum rock underground revealed by the study can provide theoretical basis for safe drilling in this kind of formations.
-
-
[1] 金衍,陈勉.盐岩地层井眼缩径控制技术新方法研究[J].岩石力学与工程学报,2000,19(增刊1):1111-1114. Jin Yan,Chen Mian.A new approach for controlling tight hole in salt formation[J].Journal of Rock Mechanics and Engineering,2000,19(supplement 1):1111-1114. [2] Ge Weifeng,Chen Mian,Jin Yan,et al.Analysis of the external pressure on casings induced by salt-gypsum creep in build-up sections for horizontal wells[J].Rock Mechanics and Rock Engineering,2011,44(6):711-723.
[3] Cristescu N D.A general constitutive equation for transient and stationary creep of rock salt[J].International Journal of Rock Mechanics and Mining Science,1993,30(2):125-140.
[4] Hunsche Udo.Result and interpretation of creep experiments on rock salt:the first Conference on the Mechanical Behavior of Salt,State College,1981[C].Clausthal-Zellerfeld:Transactions of Technical Publishers.
[5] Hunsche Udo.Uniaxial and triaxial creep and failure tests on rock:experiment technique and interpretation[M].Verlag:Springer,1994.
[6] Badens E,Veesler S,Boistelle R,et al.Relation between Young’s modulus of set plaster and complete wetting of grain boundaries by water[J].Colloids and Surfaces A:Physiochemical and Engineering Aspects,1999,156(1/2/3):373-379.
[7] Coquard P,Boistelle R.Water and solvent effects on the strength of set plaster[J].International Journal of Rock Mechanics and Mining Sciences Geomechanics,1994,31(5):517-524.
[8] Kato Y,Matsui M,Umeya K,et al.Influence of surface energy on the mechanical properties of hardened gypsum[J].Gypsum Lime,1980,166:3-9.
[9] Sattler H.Elastic and plastic deformations of plaster units under uniaxial compressive stress[J].Matériaux et Construction,1974,7(3):159-168.
[10] Meille S.Correlation between mechanical behavior and microstructure of set plaster[D].INSA de Lyon,France,2001.
[11] Meille Sylvain,Sadaoui Malika,Reynaud Pascal,et al.Mechanisms of crack propagation in dry plaster[J].Journal of the European Ceramic Society,2003,23(16):3105-3112.
[12] Finot E,Lesniewska E,Mutin J C,et al.Reactivity of gypsum faces according to the relative humidity by scanning force microscopy[J].Surface Science,1997,384(1/2/3):201-217.
[13] Andrews H.The effect of water contents on the strength of calcium sulfate plaster products[J].Journal of the Society of Chemical Industry,1946,65(5):125-128.
[14] Sadaoui M,Meille S,Reynaud P,et al.Internal friction study of the influence of humidity on set plaster[J].Journal of the European Ceramic Society,2005,25(14):3281-3285.
[15] 陈勉,金衍,张广清.石油工程岩石力学[M].北京:科学出版社,2008:19-30. Chen Mian,Jin Yan,Zhang Guangqing.Petroleum engineering rock mechanics[M].Beijing:Science Press,2008:19-30. [16] Kolláth B,Zoltán Juhász A.Mechanochemical capillary reactions in partly dehydrated gypsum and aluminium hydroxide interground powder mixtures[J].Cement and Concrete Research,1996,26(12):1843-1857.
-
