Anti-Collision Prediction Model for Drill Bit Approaching Adjacent Well Based on Spherical Wave Propagation Theory
-
摘要: 为实现丛式井地面防碰监测预警系统有效预测正钻井与邻井间距离的功能,建立了钻头趋近邻井防碰预测模型。该模型依据弹性波的球面扩散和衰减吸收理论,通过分析实测数据的幅值衰减规律而建立。利用该模型,通过地面实时监测、分析、计算风险邻井套管的振动信号特征,可求取钻头与邻井套管的距离,识别钻头碰撞邻井井筒的可能性并及时预警。根据渤海某油田的防碰监测数据,用所建模型计算出了监测井段钻头与邻井套管的距离;对比测井数据计算的井眼扫描距离和模型计算结果发现,利用该预测模型求解的钻头与邻井间的距离与测井数据得到的井间距离有明确的对应关系,表明所建模型可以作为丛式井地面防碰监测预警系统预测井间距离的一种计算方式。Abstract: In order to improve the effectiveness of anti-collision system in offshore cluster well drilling anti-collision prediction model of drill bit approaching adjacent well was built based on the theory of elastic waves in spherical spreading and absorption attenuation,and amplitude attenuation pattern analysis of actual measured data.Through adjacent well casing vibration monitoring and data processing,the distance between the drill bit and adjacent well casing can be calculated by using the model,and the chance of well collision can be identified and warning provided.The model was used to analyze the casing vibration signals of adjacent wells in Bohai Sea,and gave the distance between dill bit and adjacent well casing.The distance between drill bit and adjacent well casing calculated from the model and well distance from log data matched well.It demonstrated that the model can be used to predict the distance between drilling and adjacent well,which could provide a new technical support for safe drilling of offshore cluster wells.
-
Keywords:
- cluster wells /
- anti-collision /
- spherical wave /
- bit /
- vibration wave /
- casing /
- mathematical model
-
-
[1] 何保生,刘刚,王平双,等.基于钻头运动诱发套管头振动信号检测的井眼防碰监测方法[J].中国工程科学,2011,13(5):74-77. He Baosheng,Liu Gang,Wang Pingshuang,et al.Anti-collision monitoring based on detecting casing head vibration induced by drill movements[J].Engineering Sciences,2011,13(5):74-77. [2] 吴宏均,令文学,初永涛.吉林油田浅层丛式水平井井眼轨迹控制技术[J].石油钻探技术,2011,39(5):31-34. Wu Hongjun,Ling Wenxue,Chu Yongtao.Trajectory control technology for shallow cluster horizontal wells in Jilin Oilfield[J].Petroleum Drilling Techniques,2011,39(5):31-34. [3] 刘永旺,管志川,史玉才,等.井眼防碰技术存在的问题及主动防碰方法探讨[J].石油钻采工艺,2011,33(6):14-18. Liu Yongwang,Guan Zhichuang,Shi Yucai,et al.Discussion on problems of wellbore anti-collision technology and active anti-collision methods[J].Oil Drilling Production Technology,2011,33(6):14-18. [4] 鲁港,常汉章,邢玉德,等.邻井间最近距离扫描的快速算法[J].石油钻探技术,2007,35(3):23-26. Lu Gang,Chang Hanzhang,Xing Yude,et al.Fast algorithm for scanning the nearest distance among adjacent wells[J].Petroleum Drilling Techniques,2007,35(3):23-26. [5] Nitin Sharma,Mike McDonald,Jeffrey Mohammed,et al.Optimizing directional drilling while minimizing the risk of well collision in offshore drilling.SPE 124246,2009.
[6] Benny Poedjono,Chinh Phan Van,Guy J Lombardo,et al.Anti-collision risk management for real-world well placement.SPE 121094,2009.
[7] 刘刚,孙金,何宝生,等.定向井防碰地面监测系统设计及现场试验[J].石油钻探技术,2012,40(1):7-11. Liu Gang,Sun Jin,He Baosheng,et al.Design and field test of surface monitoring system for directional wells anti-collision[J].Petroleum Drilling Techniques,2012,40(1):7-11. [8] 刘刚,孔得臣,孙金,等.套管头振动信号特征应用于油井防碰监测的可行性分析[J].中国海上油气,2012,24(3):54-57. Liu Gang,Kong Dechen,Sun Jin,et al.Feasibility analysis on application of casing head vibration signal in wellbore anti-collision monitoring[J].China Offshore Oil and Gas,2012,24(3):54-57. [9] 刁斌斌,高德利.邻井定向分离系数计算方法[J].石油钻探技术,2012,40(1):22-27. Diao Binbin,Gao Deli.Calculation method of adjacent well oriented separation factors[J].Petroleum Drilling Techniques,2012,40(1):22-27. [10] 陈正翔,江松青,张维衡.圆柱壳中结构振动波的传播特性[J].振动工程学报,1998,11(4):450-456. Chen Zhengxiang,Jiang Songqing,Zhang Weiheng.Dispersion characteristics of structure vibration waves in cylindrical shells[J].Journal of Vibration Engineering,1998,11(4):450-456. [11] 张家田.丛式钻井防碰预警系统测量模型的建立[J].西北大学学报:自然科学版, 2001,31(5):418-420. Zhang Jiatian.Test model of group drilling defend touch yellow alert system[J].Journal of Northwest University:Natural Science Edition,2001,31(5):418-420. [12] 刘合,王秀喜.套损井整形冲击应力波的传播机理研究[J].工程力学,2005,22(4):206-210. Liu He,Wang Xiuxi.Mechanism of impact stress wave spread in reshaping of destroyed casing well[J].Engineering Mechanics,2005,22(4):206-210.
