桥古1井快速钻进PDC钻头优化设计与效果分析

张建平

doi:10.3969/j.issn.1001-0890.2012.06.025

桥古1井快速钻进PDC钻头优化设计与效果分析

张建平

武汉亿斯达工具有限公司, 湖北武汉 430205

详细信息

作者简介:
张建平(1974-),男,江苏如皋人,1997年毕业于武汉理工大学机械设计专业,工程师,主要从事金刚石钻头的研究开发工作。联系方式15927664510,179869915@qq.com。

中图分类号: TE921⁺.1
计量
- 文章访问数: 3108
- HTML全文浏览量: 73
- PDF下载量: 3396
出版历程
- 收稿日期: 2012-07-09
- 修回日期: 2012-10-07
- 刊出日期: 1899-12-31

Design Optimization and Effect Analysis of Fast Drilling PDC Bit for Well QG-1

Zhang Jianping

Wuhan Eastar Tool Company Limited, Wuhan, Hubei, 430205, China

摘要

摘要: 为了提高桥古1井山前构造地层中的钻进速度,对拟用于该井的PDC钻头进行了优化设计。在详细分析该井的地层特点以及邻近区块相似层位井段钻头使用资料的基础上,提出了针对性的优化方案,采用了力平衡布齿设计、等切削轮廓、CFD优化水力结构等现代PDC钻头设计技术,对常规PDC钻头在山前构造中易磨损、易泥包、机械钻速慢等缺陷进行了设计改进。所设计的钻头在桥古1井共使用了2只,使用井段为2 075.12~4 959.00 m,总进尺2 883.88 m,纯钻时间519.2 h,平均钻速5.55 m/h,比设计预期的3.50 m/h提高了58.57%,比预计的工期缩短了30 d。桥古1井的钻井实践表明,提出的钻头选型和优化设计方案可行,同时为山前构造地层优快钻井积累了宝贵经验。
- PDC钻头 /
- 山前构造 /
- 钻头设计 /
- 水力参数设计 /
- 切削结构 /
- 桥古1井
Abstract: In order to improve the drilling speed of Well QG-1 in the piedmont structural formation,the design of PDC bits was optimized.Based on careful analysis of the formation characteristics and bit data of similar layers in adjacent blocks,pertinent optimization scheme was put forward,which used modern PDC bit design methods such as force balance of cutters arrangement design,equal cutting profile,and CFD optimization of hydraulic structure,Defects of conventional PDC bit in piedmont structure such as easy abrasion,easy balling,slow drilling speed were modified.Two such designed bits altogether were used in Well QG-1,to drill from 2 075.12 m to 4 959.00 m.With a total footage of 2 883.88 m,the net drilling time of 519.2 h,the average drilling speed was 5.55 m/h,which is 58.57% faster than the expected design of 3.50 m/h,resulting in a reduction of drilling time of 30 d.Drilling in Well QG-1 showed the methods of bit selection and design optimization were feasible,at the same time precious experience for piedmont formation drilling was accumulated.
- PDC bit /
- piedmont structure /
- bit design /
- hydraulics design /
- cutting structure /
- Well QG-1

HTML全文

参考文献(11)

[1]	熊继有,蒲克勇,周健.库车坳陷山前构造超深井岩石可钻性研究[J].天然气工业,2009,29(11):59-61. Xiong Jiyou,Pu Keyong,Zhou Jian.Rock drillability investigation for ultra-deep well drilling at thrust structure of Kuqa depression[J].Natural Gas Industry,2009,29(11):59-61.
[2]	刘佑云.塔里木轮南地区PDC钻头泥包原因分析及对策[J].西部探矿工程,2011,23(10):59-61. Liu Youyun.Tarim Lunnan PDC bit balling cause analysis and countermeasures[J].West-China Exploration Engineering,2011,23(10):59-61.
[3]	关绍曾,关世桥.新疆库车盆地吉迪克组的地层时代和沉积环境[J].化工矿产地质,2002,24(1):1-6,22. Guan Shaozeng,Guan Shiqiao.Stratigraphic age and depositional environment of Jidike Formation in Kuche basin of Xinjiang[J].Geology of Chemical Minerals,2002,24(1):1-6,22.
[4]	詹姆斯·福德·布雷特,汤米·梅尔文·沃伦.不平衡力补偿钻头:CN,90100960.1.1990-09-05. Bret F J,Warren T M.Imbalance compensated drill bit:CN,90100960.1.1990-09-05.
[5]	杨延征,王镇全.刮刀式PDC钻头布齿方法探讨[J].西部探矿工程,2009,21(5):41-42. Yang Yanzheng,Wang Zhenquan.Blade type PDC bit cutters arrangement method[J].West-China Exploration Engineering,2009,21(5):41-42.
[6]	李树盛,马德坤,侯季康.PDC钻头运动学研究[J].石油矿场机械,1996,25(4):26-29. Li Shusheng,Ma Dekun,Hou Jikang.Study on kinematics of PDC bit[J].Oil Field Equipment,1996,25(4):26-29.
[7]	王镇全,周悦辉.PDC钻头切削齿切削角度对破岩效果影响规律的研究[J].煤矿机械,2009,30(8):49-51. Wang Zhenquan,Zhou Yuehui.Study on rock breaking regulation in optimizing cutting angle of PDC bit[J].Coal Mine Machinery,2009,30(8):49-51.
[8]	邹德永,曹继飞,袁军,等.硬地层PDC钻头切削齿尺寸及后倾角优化设计[J].石油钻探技术,2011,39(6):91-94. Zou Deyong,Cao Jifei,Yuan Jun,et al.Optimization design of the cutter size and back rake for PDC bit in hard formation[J].Petroleum Drilling Techniques,2011,39(6):91-94.
[9]	刘向东,屈钧利.PDC钻头布齿参数对其强度影响的研究[J].石油机械,2009,37(12):59-62. Liu Xiangdong,Qu Junli.Study on impact on the strength of PDC bit cutter parameters[J].China Petroleum Machinery,2009,37(12):59-62.
[10]	黄英勇,李根生,宋先知,等.PDC钻头定向喷嘴井底流场数值模拟[J].石油钻探技术,2011,39(6):99-103. Huang Yingyong,Li Gensheng,Song Xianzhi,et al.Numerical simulation of bottomhole flow field of PDC bit with orientation nozzle[J].Petroleum Drilling Techniques,2011,39(6):99-103.
[11]	胡军,杨作峰.PDC钻头井底流场数值模拟研究[J].长江大学学报:自然科学版,2011,8(11):41-43. Hu Jun,Yang Zuofeng.Study on numerical simulation of bottomhole flow field of PDC bit[J].Journal of Yangtze University:Natural Science Edition,2011,8(11):41-43.
