Development and Field Test of Shock Absorber in Gas Drilling Tool
-
摘要: 为有效缓解气体钻井钻具频繁振动带来的钻具疲劳损坏,根据可压缩性硅油体积变形减振为主,硅油流过阻尼缝隙的阻尼减振为辅的研制思路,研制出了适用于气体钻井的KPL229型减振器。对加入KPL229型减振器钻具组合的有限元分析表明,加入KPL229型减振器后,钻具受到相同轴向冲击力作用的应力水平降低。现场试验表明,在气体钻井时,与未应用KPL229型减振器的井相比,扭矩不但得到降低,而且波动幅度很小;钻时由5~40 min/m降至5~9 min/m;单只钻头的进尺得到提高,其磨损程度降低。由有限元分析及现场试验结果可知,气体钻井时应用KPL229型减振器,不但可以降低振动对钻具的损伤,延长钻具的使用寿命,而且可以增强气体钻井的提速效果。KPL229型减振器为预防气体钻井时因振动造成的钻具失效或断裂提供了一种新的解决途径,同时可以利用振动能量辅助破岩。Abstract: In order to effectively alleviate fatigue damage caused by frequent vibration in gas drilling,KPL229 type Drilling-Tool Absorber(DTA)has been developed according to the compressible and damping characteristics of silicone oil.The stress level caused by drilling tool shock has been reduced with the use of KPL229 type DTA through finite element analysis.The field test using KPL229 type DTA has shown that both torque and shock amplitude are reduced.The drilling time has shortened from 5-40 min/m to 5-9 min/m,the footage of single bit is improved,the bit is not worn seriously.The results of finite element analysis and field test show that using KPL229 type DTA can not only reduce the shock damage of drill stem,but also improve the rate of penetration in gas drilling,and improve the service life of drilling tools.Using KPL229 type DTA provides a new solution for the prevention of tool failure caused by shock in gas drilling.At the same time,the energy of vibration can be used to break rock.
-
Keywords:
- gas drilling /
- drilling-tool absorber /
- drilling tool failure
-
-
[1] 徐进,蒋祖军,练章华,等.气体钻井钻柱失效统计及其失效原因分析[J].钻采工艺,2010,33(4):13-14. Xu Jin,Jiang Zujun,Lian Zhanghua,et al.Statistic and causes analysis of drill string failure in gas drilling[J].Drilling Production Technology,2010,33(4):13-14. [2] 朱化蜀,余瑞青,廖忠会,等.气体钻井井斜有限元岩石应力分析[J].天然气工业,2009,29(5):72-74. Zhu Huashu,Yu Ruiqing,Liao Zhonghui,et al.Finite element analysis on rock stress status during gas drilling deviation[J].Natural Gas Industry,2009,29(5):72-74. [3] Li Zifeng,Guo Boyun.Analysis of long itudinal vibration of drillstring in air and gas drilling.SPE 107697,2007.
[4] 祝效华,童华,刘广川.气体钻井钻具断裂机理分析[J].石油矿场机械,2008,37(1):5-8. Zhu Xiaohua,Tong Hua,Liu Guangchuan.Mechanism analysis on drill-string partial accident in air drilling[J].Oil Field Equipment,2008,37(1):5-8. [5] 黄志强,范永涛,李琴,等.冲旋钻头的现状及发展趋势[J].石油矿场机械,2009,38(2):92-96. Huang Zhiqiang,Fan Yongtao,Li Qin,et al.Current situation and development trend of percussion-rotary bit[J].Oil Field Equipment,2009,38(2):92-96. [6] 孙继明,侯树刚,李铁成.空气钻井技术在普光D-1井的应用[J].石油钻探技术,2006,34(4):24-26. Sun Jiming,Hou Shugang,Li Tiecheng.Application of air drilling technology to Well D-1 in the Puguang Oilfield[J].Petroleum Drilling Techniques,2006,34(4):24-26. [7] Whiteley M C,England W P.Air drilling operationgs improved by percussion-bit/ hammer-too ltandem.SPE 13499,1986.
[8] 黄小兵,熊建新,陈次昌.气体钻井钻具冲蚀磨损试验装置[J].石油机械,2008,36(9):1-3. Huang Xiaobing,Xiong Jianxin,Chen Cichang.The experimental device for erosion of drilling tool of gas drilling[J].China Petroleum Machinery,2008,36(9):1-3. [9] 廖忠会,张杰,李群生,等.气体钻井断钻铤事故的原因分析及预防[J].钻采工艺,2007,30(6):6-8. Liao Zhonghui,Zhang Jie,Li Qunsheng,et al.Reasons analysis and protection of drill collar breaking in gas drilling[J].Drilling Production Technology,2007,30(6):6-8. [10] 吴立新,陈平,祝效华,等.气体钻井钻柱疲劳失效周期分析[J].石油钻探技术,2012,40(1):42-46. Wu Lixin,Chen Ping,Zhu Xiaohua,et al.Contrast of fatigue failure cycles of drill string during gas drilling[J].Petroleum Drilling Techniques,2012,40(1):42-46. [11] 兰志钢.双向液压减振器的失效机理及改进建议[J].石油钻探技术,2012,40(2):104-108. Lan Zhigang.Failure mechanism of two-way hydraulic shock absorbers and improvement measures[J].Petroleum Drilling Techniques,2012,40(2):104-108. -
