Development of Measuring Instrument for Evaluating Volume Stability of HTHP Cement Slurry
-
摘要: 针对常用测试方法不能真实模拟井下高温高压受限环境、室内测试结果失真的问题,研制了高温高压水泥浆体积稳定性测定仪。该仪器能模拟井下高温高压条件,可连续测量水泥浆在塑性状态和硬化状态下的膨胀率,数据采集管理软件可记录整个试验过程,并能生成温度、压力、水泥浆高度增量随时间的变化曲线。该仪器有两套测试筒,可进行对比试验。与螺旋测微仪、量筒进行了对比试验,结果表明:对于晶体类膨胀剂,高温高压水泥浆体积稳定性测定仪的测量结果比螺旋测微仪小,数据更真实;对于常规仪器无法评价的发气类膨胀剂,该仪器也能客观评价。试验表明,高温高压水泥浆体积稳定性测定仪可用于评价固井水泥浆的体积稳定性、优选油井水泥膨胀剂和进行水泥浆配方设计,但数据采集管理软件界面不够简洁,需进一步优化。Abstract: Aiming to resolve the problem that the down-hole environments(HTHP and restrained)canimnot be simulated by the popularly used methods,and the measurements of laboratory experiment are impractical,a testing device,named measuring instrument for evaluating volume stability of HTHP cement slurry,was developed.The instrument can simulate the down-hole environment and measure the expansion rate of cement slurry continuously when it is in plastic state and hardening state.The process of experiment is recorded and the curves of temperature-time,pressure-time and height increment-time are drawn by data acquisition and management software.There are two measuring sensors which can complete a comparison test and the results are compared with the test detected by spiral micrometer and measuring cylinder.It was shown that data derived from this device was smaller and more reliable than spiral micrometer used to detect the cement slurry with crystalloid expanding agent.Volume stability of the cement slurry with gas former,which can not be evaluated by normal methods,can also be appraised by this instrument.The experiment showed that the device could be used for evaluating volume stability,oil cement additive optimization and formulation designing.However,the graphical interface of data acquisition and management software should be simplified because it was not concise.
-
Keywords:
- high temperature /
- high pressure /
- measuring instrument /
- cement slurry /
- volume stability
-
-
[1] 吴叶成,姚晓.低滤失双膨胀水泥浆体系的室内研究与应用[J].石油钻探技术,2005,33(2):26-29. Wu Yecheng,Yao Xiao.Improving the cementing quality using a novel additive with double-expansion and fluid-loss-control action [J].Petroleum Drilling Techniques,2005,33(2):26-29. [2] 桑来玉,丁士东,赵艳,等.油井水泥膨胀剂室内检测与评价[J].石油钻探技术,2000,28(3):24-26. Sang Laiyu,Ding Shidong,Zhao Yan,et al.Experimental test and evaluation of cement swelling agents[J].Petroleum Drilling Techniques,2000,28(3):24-26. [3] 姚晓,兰祥辉,邓敏,等.油井水泥多功能防窜剂的研究及应用[J].南京工业大学学报:自然科学版,2004,24(6):11-15. Yao Xiao,Lan Xianghui,Deng Min,et al.A multifunctional material for controlling fluid migration in cementing[J].Journal of Nanjing University of Technology:Natural Science Edition,2004,24(6):11-15. [4] 祝瑜,邓宏卫,曾京生,等.混凝土自收缩测量方法的进展[J].低温建筑技术,2010(10):7-10. Zhu Yu,Deng Hongwei,Zeng Jingsheng,et al.Research progress of measuring method for autogenous shrinkage concrete[J].Low Temperature Architecture Technology,2010(10):7-10. [5] Jupe A C,Wilkinson A P,Funkhouser G P.Oil-well cement and C3S hydration under high pressure as seen by in situ X-ray diffraction,temperatures ≤80 ℃ with no additives[J].Journal of the American Ceramic Society,2011,94(5):1591-1597.
[6] 秦国鲲,耿宏章,刘延明,等.泡沫钻井液动密度随井深变化关系模拟研究[J].石油钻探技术,2004,32(5):22-24. Qin Guokun,Geng Hongzhang,Liu Yanming,et al.Simulation study on how the density of foam drilling fluid varies with well depth [J].Petroleum Drilling Techniques,2004,32(5):22-24. [7] 郭宝利,袁孟雷,赵世军,等.水泥膨胀模拟试验装置:中国,200520108964.2006-11-22. Guo Baoli,Yuan Menglei,Zhao Shijun,et al.Volume variation measuring instrument for slurry:CN,200520108964.2006-11-22. [8] 郭盈盈,文守成,张俊睿.高温高压小型测长装置:中国,201010185649 .2010-09-08. Guo Yingying,Wen Shoucheng,Zhang Junrui.Dilatometer for high temperature and pressure:CN,201010185649.2010-09-08. [9] API specification 10A Specification for cements and materials for well cements[S].
[10] GB/T 1346—2001 水泥标准稠度用水量、凝结时间、安定性检验方法[S]. GB/T 1346—2001 Test methods for water requirement of normal consistency,setting time and soundness of the portland cements[S].
