Law of Water Flooding in Vug-Fracture-Vug Medium
-
摘要: 为了揭示缝洞型油藏的注采机理,研究了缝洞介质中的水驱油规律。利用有机玻璃制作了一组不同裂缝宽度的洞-缝-洞组合模式物理模型,开展了物理模拟试验,分析了水驱后剩余油分布规律及形成机制,并研究了注入速度、裂缝宽度、毛管力对水驱油采收率、含水率的影响,通过相似理论计算得到了不同溶洞高度对应的临界裂缝宽度。研究发现:水驱后的剩余油主要存在于未波及的单向连通溶洞与裂缝中,表面活性剂溶液驱后的剩余油主要存在于单向连通溶洞的上部;当溶洞内的油水界面到达一定高度产生的压差克服毛管力作用时,水才能进入裂缝底部;注入速度越小、裂缝宽度越大、毛管力越小,模型采收率越高;溶洞高度越高,其对应的临界裂缝宽度越小。研究结果表明,表面活性剂驱可以提高洞-缝-洞型油藏的采收率。Abstract: It is important to study the law of water flooding in fractured-vuggy medium to determine the development mechanism of fractured-vuggy reservoir.Based on a typical connecting type of fractures and vugs,a series models with different fracture aperture were made from synthetic glass.Physical simulation experiments were carried out by using those models,and the distribution and origin of residual oil were analyzed.The influences of flow velocity,fracture aperture and capillary force on oil recovery and water cut were studied.The critical fracture aperture in different vug heights was further calculated using similarity criteria.The results indicated that the residual oil after water flooding mainly lay in the not connected bypassed vugs and fractures.The residual oil after surfactant flooding mainly lay in the top of the not connected vugs.When the differential pressure,which was caused by the interface of oil and water rising in the vugs,could overcome the capillary force,water would flow into the bottom of the fracture.The oil recovery of the model increased along with the decreasing of flow velocity,increasing of fracture aperture and decreasing of capillary force.The critical fracture aperture decreased along with the increasing of vug height.The oil recovery of this vug-fracture-vug medium can be effectively enhanced by surfactant flooding.
-
-
[1] 熊伟,刘玉祥,常宝华,等.无供给溶洞弹性开采实验[J].科技导报,2011,29(2):41-43. Xiong Wei,Liu Yuxiang,Chang Baohua,et al.Experimental study of elastic minning in a cave of no-supply type[J].Science Technology Review,2011,29(2): 41-43. [2] 程倩,熊伟,高树生,等.单缝洞系统弹性开采的试验研究[J].石油钻探技术,2009,37(3):88-90. Cheng Qian,Xiong Wei,Gao Shusheng,et al.Experimental study of elastic producing single cavity/fracture system[J].Petroleum Drilling Techniques,2009,37(3): 88-90. [3] 李鹴,李允.缝洞型碳酸盐岩孤立溶洞注水替油实验研究[J].西南石油大学学报:自然科学版,2010,32(1):117-120. Li Shuang,Li Yun.An experimental research on water injection to replace the oil in isolated caves in fracture-cavity carbonate rock oilfield[J].Journal of Southwest Petroleum University :Science Technology Edition,2010,32(1): 117-120. [4] 刘鹏飞,姜汉桥,徐晖,等.缝洞型油藏开发室内模拟研究[J].石油钻采工艺,2009,31(5):72-76. Liu Pengfei,Jiang Hanqiao,Xu Hui,et al.Laboratory simulation study on exploitation of fractured and cavernous reservoirs[J].Oil Drilling Production Technology,2009,31(5): 72-76. [5] Zhang Dong,Li Aifen,Yao Jun,et al.A single-phase fluid flow pattern in a kind of fractured-vuggy media[J].Petroleum Science and Technology,2011,29(10): 1030-1040.
[6] 荣元帅,黄咏梅,刘学利,等.塔河油田缝洞型油藏单井注水替油技术研究[J].石油钻探技术,2008,36(4):57-60. Rong Yuanshuai,Huang Yongmei,Liu Xueli,et al.Single well water injection production in Tahe fracture-vuggy reservoir[J].Petroleum Drilling Techniques,2008,36(4): 57-60. [7] 卢占国,姚军,王殿生.正交裂缝网络单相流动实验和数值模拟[J].中国矿业大学学报,2010,39(4):563-567. Lu Zhanguo,Yao Jun,Wang Diansheng.Experimental study and numerical simulation of single-phase flow in orthogonal fracture network[J].Journal of China University of Mining Technology,2010,39(4):563-567. [8] 卢占国,姚军,王殿生,等.正交裂缝网络单相流动试验研究[J].石油钻探技术,2010,38(3):92-94. Lu Zhanguo,Yao Jun,Wang Diansheng,et al.Experimental study on single-phase flow in orthogonal fracture network[J].Petroleum Drilling Techniques,2010,38(3):92-94. [9] 迈杰鲍尔.裂缝型油田开发特征[M].黄希陶,译.北京:石油工业出版社,1986:42-46. Майдебоp B H.Development feature of fractured reservoir[M].Huang Xitao,translated.Beijing: Petroleum Industry Press,1986:42-46. [10] 李江龙,陈志海,高树生.缝洞型碳酸盐岩油藏水驱油微观实验模拟研究[J].石油实验地质,2009,31(6):637-642. Li Jianglong,Chen Zhihai,Gao Shusheng.Microcosmic experiment modeling on water-driven-oil mechanism in fractured-vuggy reservoirs[J].Petroleum Geology Experiment,2009,31(6): 637-642. [11] 康志宏.缝洞型碳酸盐岩油藏水驱油机理模拟试验研究[J].中国西部油气地质,2006,2(1):87-90. Kang Zhihong.Principium experiment of oil seepage driven by water in fracture and vug reservoir of carbonate rocks[J].West China Petroleum Geosciences,2006,2(1): 87-90. [12] 王雷,窦之林,林涛,等.缝洞型油藏注水驱油可视化物理模拟研究[J].西南石油大学学报:自然科学版,2011,33(2):121-124. Wang Lei,Dou Zhilin,Lin Tao,et al.Study on the visual modeling of water flooding in carbonate fracture-cavity reservoir[J].Journal of Southwest Petroleum University:Science Technology Edition,2011,33(2): 121-124. [13] 郑小敏,孙雷,王雷,等.缝洞型油藏大尺度可视化水驱油物理模拟实验及机理[J].地质科技情报,2010,29(2):77-80. Zheng Xiaomin,Sun Lei,Wang Lei,et al.Large-scale visible water/oil displacing physical modeling experiment and mechanism research of fracture-vuggy reservoir[J].Geological Science and Technology Information,2010,29(2): 77-80. [14] 卢占国,姚军,王殿生,等.正交裂缝网络中渗流特征实验研究[J].煤炭学报,2010,35(4):555-558. Lu Zhanguo,Yao Jun,Wang Diansheng,et al.Experimental study on fluid flow characteristic in orthogonal fracture network[J].Journal of China Coal Society,2010,35(4): 555-558. [15] 熊伟,常宝华,潘懋,等.单井缝洞系统注水对含水率的影响分析[J].断块油气田,2012,18(4):479-481. Xiong Wei,Chang Baohua,Pan Mao,et al.Impact of water injection on water content in single well fractured-vuggy system[J].Fault-Block Oil Gas Field,2012,18(4):479-481. [16] 修乃岭,熊伟,高树生,等.缝洞型油藏储集空间连通关系和开发特征初探[J].中国西部油气地质,2007,3(1):105-107. Xiu Nailing,Xiong Wei,Gao Shuheng,et al.Discussion on connecting relation among pore spaces and producing characteristic of fracture-vuggy reservoirs[J].West China Petroleum Geosciences,2007,3(1): 105-107.
