Indoor Test of Heavy Oil Recovery by Gravity Drainage with Solvent
-
摘要: 多孔介质和Hele-Shaw设备中的溶剂辅助重力泄油开采机理不同,特别是两者产生脱沥青作用的压力范围是否一致及增产幅度的差别程度如何尚不明确。为研究溶剂辅助重力泄油技术开采多孔介质中稠油的机理,建立了3层结构的溶剂辅助重力泄油可视化填砂模型,对高渗岩心溶剂辅助重力泄油不同注入压力与泄油速率关系及相同注入压力下不同渗透率岩心溶剂辅助重力泄油脱沥青降黏作用和堵塞流动通道的复合作用机理进行了室内试验研究。试验结果表明:多孔介质溶剂脱沥青作用出现在饱和蒸气压附近,试验泄油速度提高3倍,但脱沥青作用发生的压力范围较小;脱沥青作用会造成低渗地层部分孔喉堵塞。因此,低渗地层VAPEX溶剂注入压力应低于溶剂的饱和蒸气压,而高渗地层则可以充分利用脱沥青降黏作用来提高泄油速率。Abstract: VAPEX in Hele-Shaw and porous media are different in mechanism,we are especially uncertain whether their pressure ranges of deasphalting are the same and the degree of difference in increasing oil production.In order to study the mechanism of VAPEX in porous media,a three-layer sand-packed physical model for VAPEX was built.VAPEX tests in high permeability cores were conducted to find the relationship between operating pressures and production rates,and several tests were conducted to study the effect of asphaltene precipitation on different permeability of cores under the same pressure.The experiment results show that deasphalting in porous medium happens near saturated vapour pressure,oil drainage ratio increased by three times,but deasphalt appeared in narrow pressure ranges,the asphaltene deposition would plug part of the pore throats,so the operating pressure should be lower than the solvent’s saturated vapour pressure,but for high permeability formations,the lower viscosity in deasphalting can be fully used to improve production rate.
-
Keywords:
- heavy oil recovery /
- solvent /
- gravity drainage /
- physical model /
- oil displacement mechanism /
- laboratory test
-
-
[1] Butler R M,Mokrys I J.A new process (VAPEX) for recovering heavy oils using hot water and hydrocarbon vapour[J].Journal of Canadian Petroleum Technology,1991,30(1):97-106.
[2] Boustani A,Maini B B.The role of diffusion and convective dispersion in vapour extraction process[J].Journal of Canadian Petroleum Technology,2001,40(4):68-77.
[3] Das S K,Butler R M.Mechanism of the vapour extraction process for heavy oil and bitumen[J].Journal of Petroleum Science Engineering,1998,21(1):43-59.
[4] Das S K.In situ recovery of heavy oil and bitumen using vaporized hydrocarbon solvents.Calgary,Alberta:University of Calgary,Department of Chemical and Petroleum Engineering,1995.
[5] Oduntan A R,Chatzis I,Smith J,et al.Heavy oil recovery using the VAPEX process:scale-up issues:the 2nd Canadian International Petroleum Conference,Calgary,Alberta,June 12-14,2001.
[6] Boustani A,Maini B B.The role of diffusion and convective dispersion in vapour extraction process[J].Journal of Canadian Petroleum Technology,2001,40(4):68-77.
[7] Zhang H,Luo P,Gu Y.Physical modeling of heavy oil production rate in a vapour extraction process:the 7th Canadian International Petroleum Conference,Calgary,Alberta,June 13-15,2006.
[8] Butler R M,Mokrys I J.Solvent analog model of steam-assisted gravity drainage[J].AOSTRA Journal of Research,1989,5(1):17-32.
[9] Das S K,Butler R M.Investigation of VAPEX process in a packed cell using butane as a solvent:SPE/CIM/CANMET International Conference on Recent Advances in Horizontal Well Applications,Calgary,Alberta,March 20-23,1994.
[10] 杨滨.溶剂辅助重力泄油技术及组分模拟研究.北京:中国石油大学(北京)石油工程学院,2009. Yang Bin.Research on vapour extraction process mechanism and compositional numerical simulation for heavy oil reservoir.Beijing:China University of Petroleum(Beijing),College of Petroleum Engineering,2009. [11] 杨滨,姜汉桥,Yongan Gu.溶剂辅助重力泄油注入压力试验[J].中国石油大学学报:自然科学版,2009,33(6):77-81. Yang Bin,Jiang Hanqiao,Yongan Gu.Experiment on injection pressure of vapour extraction Process[J].Journal of China University of Petroleum:Edition of Natural Science,2009,33(6):77-81. [12] Jiang Q.Recovery of heavy oil and bitumen using VAPEX process in homogenous reservoirs.Calgary,Alberta:University of Calgary,Department of Chemical and Petroleum Engineering,1997.
[13] Butler R M,Stephens D J.The gravity drainage of steam-heated heavy oil to parallel horizontal wells[J].Journal of Canadian Petroleum Technology,1981,20(2):90-96.
