不同加重剂对超高密度钻井液性能的影响

王琳, 林永学, 杨小华, 蔡利山, 柴龙

王琳, 林永学, 杨小华, 蔡利山, 柴龙. 不同加重剂对超高密度钻井液性能的影响[J]. 石油钻探技术, 2012, 40(3): 48-53. DOI: 10.3969/j.issn.1001-0890.2012.03.010
引用本文: 王琳, 林永学, 杨小华, 蔡利山, 柴龙. 不同加重剂对超高密度钻井液性能的影响[J]. 石油钻探技术, 2012, 40(3): 48-53. DOI: 10.3969/j.issn.1001-0890.2012.03.010
Wang Lin, Lin Yongxue, Yang Xiaohua, Cai Lishan, Chai Long. Effects of Weighting Agent on Ultra-High Density Drilling Fluid’s Performance[J]. Petroleum Drilling Techniques, 2012, 40(3): 48-53. DOI: 10.3969/j.issn.1001-0890.2012.03.010
Citation: Wang Lin, Lin Yongxue, Yang Xiaohua, Cai Lishan, Chai Long. Effects of Weighting Agent on Ultra-High Density Drilling Fluid’s Performance[J]. Petroleum Drilling Techniques, 2012, 40(3): 48-53. DOI: 10.3969/j.issn.1001-0890.2012.03.010

不同加重剂对超高密度钻井液性能的影响

基金项目:

中国石化重点科技攻关项目"官渡地区超高密度钻井液技术研究与应用"(编号:P10038)部分研究内容

详细信息
    作者简介:

    王琳(1970-),女,河北吴桥人,1995年毕业于山东大学化学与化工学院有机合成专业,2004年获中国科学院物理化学专业博士学位,主要从事油田化学剂的研究工作.

  • 中图分类号: TE254+.4

Effects of Weighting Agent on Ultra-High Density Drilling Fluid’s Performance

  • 摘要: 针对超高密度钻井液中加重剂用量大、货源稀少、价格昂贵,或硬度较大、磨损钻具、具有毒性等问题,选择目前应用最广泛的重晶石粉和国外开发的微锰粉MicroMAX为加重剂,研究了其对钻井液性能的影响。分别用扫描电镜和激光粒度仪分析了重晶石粉和微锰粉的微观形态和粒度分布,并将其按一定比例复配为加重剂,配制出2.85~2.90 kg/L的超高密度钻井液,高温老化后进行流变性、滤失性和沉降稳定性的评价试验。试验结果表明:纯度较高的重晶石粉能够配制出具有良好流变性、悬浮稳定性的超高密度钻井液,且高温高压滤失量小;用重晶石粉和密度更高、粒径较小的微锰粉复配加重,高温老化后钻井液的黏度和动切力下降,流变性有一定改善,但高温高压滤失量增大。综合考虑钻井液性能、经济性和实用性,建议用性价比相对较高的重晶石粉为加重剂。用重晶石粉加重的2.75~2.89 kg/L的超高密度钻井液在官深1井三开井段进行了现场试验,安全钻进约745 m。
    Abstract: In view of some problems about weighting agent in ultra-high density drilling fluid,such as large dosage,scarce supply,expensive prices,high hardness,drilling tools wear,toxicity,etc.,weighting agents,most widely used barite and MicroMax developed abroad,were selected to study their influence on drilling fluid’s properties.Their microscopic shape and size distribution were analyzed and then two kinds of ultra-high density drilling fluid (ρ=2.85-2.90 kg/L) were prepared with barite and the mixture of barite and MicroMAX as weighting materials to evaluate their rheology,filtration and sedimentation stability.After high temperature aging,the test results showed that high purity barite can make ultra-high density drilling fluid with good rheology,suspension stability and low filtration at high temperature and pressure.Whereas the ultra-high density drilling fluid,using mixed barite and MicroMAX of higher density and smaller grain size as weighting agent,showed reduction in viscosity and dynamic shear force,improvement in rheology,but increased filtration at high temperature and high pressure.Taking drilling fluid performance,economy and practicability into comprehensive consideration,it is suggested that the cost effective barite alone be used as weighting agent as far as possible.The ultra-high density drilling fluid based on barite with densities of 2.75-2.89 kg/L was tested in Well Guanshen 1 in Guandu Area,which was safely drilled for 745 m.
  • [1] 刘永福.高密度钻井液的技术难点及其应用[J].探矿工程:岩土钻掘工程,2007,34(5):47-49. Liu Yongfu.Technological difficulties and application of high density drilling fluid[J].Exploration Engineering:Rock Soil Drilling and Tunneling,2007,34(5):47-49.
    [2] 刘常旭,张茂奎,王平全,等.国内外高密度水基钻井液体系研究现状[J].西部探矿工程,2006,18(5):139-140. Liu Changxu,Zhang Maokui,Wang Pingquan,et al.Research status of high-density water-based drilling fluid system[J].West-China Exploration Engineering,2006,18(5):139-140.
    [3] 张斌,卢虎,王秀平,等.克拉4井超高密度钻井液现场应用技术[J].钻井液与完井液,2007,24(5):22-25. Zhang Bin,Lu Hu,Wang Xiuping,et al.Application of ultra-high density drilling fluid in Well Kela4[J].Drilling Fluid Completion Fluid,2007,24(5):22-25.
    [4]

    Ezell R,Harrison D J.Design of improved high-density,thermally-stable drill-in fluid for HTHP applications.SPE 115537,2008.

    [5]

    Gregoire M,Hodder M,Peng Shuangjiu,et al.Successful drilling of a deviated,ultra-HTHP well using a micronised barite fluid.SPE 119567,2009.

    [6]

    Carbajal D,Burress C,Shumway B,et al.Combining proven anti-sag technologies for HPHT North Sea applications:clay-free oil-based fluid and synthetic,sub-micron weight material.SPE 119378,2009.

    [7]

    Spooner M,Magee K,Otto M,et al.The application of high temperature polymer drilling fluid on smackover operations in Mississippi:the AAED 2004 Drilling Fluids Conference,Houston,Texas,April 6-7,2004.

    [8]

    Al-Saeedi M J,Al-Khayyat B,Al-Enezi D,et al.Successful HPHT application of potassium formate/manganese tetra-oxide fluid helps improve drilling characteristics and imaging log quality.SPE 132151,2010.

    [9] 胡德云.超高密度(ρ≥3.00 g/cm3)钻井液的研究与应用[J].钻井液与完井液,2001,18(1):6-11. Hu Deyun.Study and application of ultra-high density drilling fluid[J].Drilling Fluid Completion Fluid,2001,18(1):6-11.
    [10] 张东海,马洪会.超高密度钻井液在官7井的应用[J].钻井液与完井液,2006,23(5):8-11. Zhang Donghai,Ma Honghui.The application of ultra-high density mud in Well Guan-7[J].Drlling Fluid Completion Fluid,2006,23(5):8-11.
    [11] 周长虹,崔茂荣,马勇,等.深井高密度钻井液的应用及发展趋势探讨[J].特种油气藏,2006,13(3):1-3,11. Zhou Changhong,Cui Maorong,Ma Yong,et al.Application and development of deep well high-density drilling fluids[J].Special Oil Gas Reservoirs,2006,13(3):1-3,11.
    [12] 周成华,王平全,王进涛,等.不同级配活化铁矿粉对高密度水基钻井液黏度效应的影响[J].钻井液与完井液,2008,25(1):21-23,26. Zhou Chenghua,Wang Pingquan,Wang Jintao,et al.The influences of different sized ground iron ores on the viscosity of high density water base muds[J].Drilling Fluid Completion Fluid,2008,25(1):21-23,26.
    [13] 黄维安,邱正松,钟汉毅,等.高密度钻井液加重剂的研究[J].国外油田工程,2010,26(8):37-40. Huang Weian,Qiu Zhengsong,Zhong Hanyi,et al.The study of weighting agent in high density drilling fluids[J].Foreign Oilfield Engineering,2010,26(8):37-40.
    [14] 赵素丽,常连玉,蔡利山.活化铁矿粉技术及其效果评价[J].钻井液与完井液,2007,24(增刊1):78-81. Zhao Suli,Chang Lianyu,Cai Lishan.Activated iron ore powder:technology and performance evaluation[J].Drilling Fluid Completion Fluid,2007,24 (supplement 1):78-81.
    [15]

    Franks T,Marshall D S.Novel drilling fluid for through-tubing rotary drilling .IADC/SPE 87127,2004.

    [16]

    Al-Yami A S,Nasr-El-Din H A,Al-Majed A A,et al.An innovative manganese tetraoxide/KCl water-based drill-in fluids for HT/HP wells .SPE 110638,2007.

    [17] 沈伟,潘惠芳,秦永强.重晶石表面化学改性进展[J].油田化学,1999,16(1):86-90. Shen Wei,Pan Huifang,Qin Yongqiang.Advances in chemical surface modification of barite[J].Oilfield Chemistry,1999,16(1):86-90.
    [18] 林永学,杨小华,蔡利山,等.超高密度钻井液技术[J].石油钻探技术,2011,39(6):1-5. Lin Yongxue,Yang Xiaohua,Cai Lishan,et al.Ultra-high density drilling fluid technology[J].Petroleum Drilling Techniques,2011,39(6):1-5.
