哈拉哈塘超深水平井井眼轨道优化设计

文志明, 李宁, 张波

文志明, 李宁, 张波. 哈拉哈塘超深水平井井眼轨道优化设计[J]. 石油钻探技术, 2012, 40(3): 43-47. DOI: 10.3969/j.issn.1001-0890.2012.03.009
引用本文: 文志明, 李宁, 张波. 哈拉哈塘超深水平井井眼轨道优化设计[J]. 石油钻探技术, 2012, 40(3): 43-47. DOI: 10.3969/j.issn.1001-0890.2012.03.009
Wen Zhiming, Li Ning, Zhang Bo. Optimal Trajectory Design of Ultra-Deep Horizontal Wells in Halahatang Block[J]. Petroleum Drilling Techniques, 2012, 40(3): 43-47. DOI: 10.3969/j.issn.1001-0890.2012.03.009
Citation: Wen Zhiming, Li Ning, Zhang Bo. Optimal Trajectory Design of Ultra-Deep Horizontal Wells in Halahatang Block[J]. Petroleum Drilling Techniques, 2012, 40(3): 43-47. DOI: 10.3969/j.issn.1001-0890.2012.03.009

哈拉哈塘超深水平井井眼轨道优化设计

详细信息
    作者简介:

    文志明(1983-),男,四川成都人,2006年毕业于西南石油大学石油工程专业,工程师,主要从事科研管理工作.

  • 中图分类号: TE22

Optimal Trajectory Design of Ultra-Deep Horizontal Wells in Halahatang Block

  • 摘要: 哈拉哈塘区块已钻水平井井眼轨道设计虽可以满足施工的需要,但设计的造斜率偏小,定向施工时间较长,导致定向仪器和造斜工具在井底时间长,增加了仪器和工具高温下失效的风险。从造斜率优化的角度出发,分析计算了不同套管可以通过的最大井眼曲率和工具的造斜能力,结合钻井现场造斜工具的实际造斜情况,选择哈拉哈塘区块水平井双增轨道中第一造斜段的造斜率为7°/30m,第二造斜段的造斜率为10°/30m。然后运用Landmark软件计算分析了以下内容:所选造斜率的轨道,垂深变化对造斜率带来的影响是否影响螺杆钻具的选择,造斜率增大情况下管柱能否安全下入井底,摩阻的变化情况。计算结果显示,采用大造斜率设计是可靠的。现场应用表明,优化后的水平井井眼轨道设计更利于控制井眼轨迹,同时缩短了定向施工时间。
    Abstract: Although the original horizontal well trajectory in Halahatang block can meet the demand drilling,its build-up rate is slightly lower,causing long directional time,and extended time of orientation tools in well bottom,which increases the risk of tool failure under high temperature.In order to decrease this hazard,from the view of optimizing build-up rate,the maximum passing curvature of different casing and build-up capacity of tools were calculated.Double-increase trajectory chose a build-up rate of 7 degrees per 30 meters at the first section,and 10 degrees per 30 meters at the second section according to build-up rate on site.Landmark software was used to calculate whether the new trajectory and change in vertical depth affect the choice of PDM,and whether the drilling and casing string can run into the well bottom safely,as well as the change of drag.The calculated results showed that the design with higher build-up rate was reliable. Moreover,field application showed that the optimized profile was favorable for trajectory control and shortened the direction time.
  • [1] 苏义脑.水平井井眼轨道控制[M].北京:石油工业出版社,2000:172-174. Su Yinao.Horitontal wellbore trajectory control[M].Beijing:Petroleum Industry Press,2000:172-174.
    [2] 韩志勇,王德新.套管可通过的最大井眼曲率的确定方法[J].石油钻探技术,1999,27(2):15-17. Han Zhiyong,Wang Dexin.Method of determining the maximum hole curvature that casing can be run through[J].Petroleum Drilling Techniques,1999,27(2):15-17.
    [3] 刘修善.井眼轨道几何学[M].北京:石油工业出版社,2006:188-196. Liu Xiushan.The geometry of wellbore trajectory[M].Beijing:Petroleum Industry Press,2006:188-196.
    [4] 何龙,陈岳军.塔河油田侧钻短半径水平井技术[J].石油钻探技术,2003,31(6):63-65. He Long,Chen Yuejun.The short-radius horizontal sidetracking technology in Tahe Oilfield[J].Petroleum Drilling Techniques,2003,31(6):63-65.
    [5] 崔红英.水平井轨道优化设计方法[J].石油钻探技术,2002,30(6):18-20. Cui Hongying.Study on optimum design of horizontal well path[J].Petroleum Drilling Techniques,2002,30(6):18-20.
    [6] 刘修善,何树山,邹野.导向钻具几何造斜率的研究[J].石油学报,2004,25(6):83-87. Liu Xiushan,He Shushan,Zou Ye.Study on the geometric build angle rate of steerable motor[J].Acta Petrolei Sinica,2004,25(6):83-87.
    [7] 宫华,郑瑞强,范存,等.大庆油田超短半径水平井钻井技术[J].石油钻探技术,2011,39(5):19-22. Gong Hua,Zheng Ruiqiang,Fan Cun,et al.Ultra-short radius horizontal well drilling technology in Daqing Oilfield[J].Petroleum Drilling Techniques,2011,39(5):19-22.
