套管水泥环组合应力计算边界条件分析

李国庆

李国庆. 套管水泥环组合应力计算边界条件分析[J]. 石油钻探技术, 2012, 40(2): 20-24. DOI: 10.3969/j.issn.1001-0890.2012.02.004
引用本文: 李国庆. 套管水泥环组合应力计算边界条件分析[J]. 石油钻探技术, 2012, 40(2): 20-24. DOI: 10.3969/j.issn.1001-0890.2012.02.004
Li Guoqing. Analysis of Boundary Condition of Stress Calculation on Casing/Cement-Sheath[J]. Petroleum Drilling Techniques, 2012, 40(2): 20-24. DOI: 10.3969/j.issn.1001-0890.2012.02.004
Citation: Li Guoqing. Analysis of Boundary Condition of Stress Calculation on Casing/Cement-Sheath[J]. Petroleum Drilling Techniques, 2012, 40(2): 20-24. DOI: 10.3969/j.issn.1001-0890.2012.02.004

套管水泥环组合应力计算边界条件分析

详细信息
    作者简介:

    李国庆(1959-),男,黑龙江齐齐哈尔人,1982年毕业于大庆石油学院钻井工程专业,2009年获中国地质大学(北京)地质工程专业博士学位,总工程师,高级工程师,主要从事油气井工艺理论方面的研究。联系方式(0459)4891544。

  • 中图分类号: TE21

Analysis of Boundary Condition of Stress Calculation on Casing/Cement-Sheath

  • 摘要: 合理的套管应力计算是套管柱强度设计和套管损坏判别的依据。目前常用计算套管应力的方法是将非均匀地应力作用于已经形成的套管水泥环组合体之上,再根据计算结果进行套管应力及变形分析,而实际上非均匀地应力所引起的应力集中效应在固井之前已经在井壁岩石处释放,并不能作用到套管水泥环组合体之上。在非均匀地应力作用下一般形成椭圆形井眼,水泥凝固之前井壁岩石在非均匀地应力和井内液柱压力的作用下已经达到平衡,套管与水泥环组合不需要承担由非均匀地应力所产生的载荷,短期内套管水泥环组合承受均匀的液柱压力;油田长期开发过程中由于地层岩石具有流变性,逐渐将部分甚至全部垂向地应力转嫁到套管水泥环组合体之上,使其承受均匀地应力的作用,从而造成套管被挤扁和缩径。非均匀地应力形成的椭圆形水泥环改变了套管柱周向应力分布,但并不能将非均匀地应力作为套管水泥环应力计算的边界条件。
    Abstract: Reasonable calculation of casing stress is the basis for design of casing string strength and for judging whether casing failure happened.At present,the common method of casing stress calculation is to apply the non-uniform in-situ stress to the casing/cement-sheath.Then according to the calculation results,casing string stress and deformation are analyzed,but in fact,stress concentration effect caused by non-uniform in-situ stress is already released on sidewall rock before well cementation,and can not be applied to casing/cement-sheath.Usually an oval hole is formed on the effect of non-uniform in-situ stress,the sidewall rock already reaches balance under the effect of non-uniform in-situ stress and fluid pressure before cement setting,so the load caused by non-uniform in-situ stress is not taken by casing/cement-sheath,and in short period uniform stress of salt water column is taken by casing/cement-sheath.In the long period development of oilfield,due to rheological property of formation rock,some even all of vertical crustal stress will be taken forward to casing/cement-sheath,then casing/cement-sheath will take the effect of uniform crustal stress,what is the main reason for casing collapse and necking down.The circumferential stress distribution is changed by oval cement sheath which is formed by non-uniform in-situ stress.But non-uniform in-situ stress cannot be concerned as the boundary condition of stress calculation on casing/cement-sheath.
  • [1] 廖华林,管志川,冯光通,等.深井超深井套管损坏机理与强度设计考虑因素[J].石油钻采工艺,2009,31(2):1-6. Liao Hualin,Guan Zhichuan,Feng Guangtong,et al.Casing failure mechanism and strength design considerations for deep and ultra-deep wells[J].Oil Drilling Production Technology,2009,31(2):1-6.
    [2] 阚庆山,刘汝东,苏娟.套损井修复技术在中原油田的应用[J].断块油气田,2009,16(3):121-122. Kan Qingshan,Liu Rudong,Su Juan.Application of repairing technology for casing damage well in Zhongyuan Oilfield[J].Fault-Block Oil Gas Field,2009,16(3):121-122.
    [3] 李军,陈勉,张辉,等.水泥环弹性模量对套管外挤载荷的影响分析[J].石油大学学报:自然科学版,2005,29(6):41-44. Li Jun,Chen Mian,Zhang Hui,et al.Effects of cement sheath elastic modulus on casing external collapse load[J].Journal of the University of Petroleum,China:Edition of Natural Science,2005,29(6):41-44.
    [4] 王耀锋,李军强,杨小辉,等.水泥环弹性模量和泊松比与地层性质匹配关系研究[J].石油钻探技术,2008,36(6):25-29. Wang Yaofeng,Li Junqiang,Yang Xiaohui,et al.Research on matching cement’s elastic modulus and Poisson’s ratio[J].Petroleum Drilling Techniques,2008,36(6):25-29.
    [5] 李茂华,徐守余,牛卫东.水泥环对油气井套管力学性能影响的分析计算[J].钻采工艺,2007,30(4):98-101. Li Maohua,Xu Shouyu,Niu Weidong.Analysis of effect of cement sheath on casing mechanical property in oil-gas well[J].Drilling Production Technology,2007,30(4):98-101.
    [6] 殷有泉,陈朝伟,李平恩.套管-水泥环-地层应力分布的理论解[J].力学学报,2006,38(6):835-842. Yin Youquan,Chen Zhaowei,Li Ping’en.Theoretical solutions of stress distribution in casing-cement and stratum system[J].Acta Mechanica Sinica,2006,38(6):835-842.
    [7] 李军,陈勉,柳贡慧,等.套管、水泥环及井壁围岩组合体的弹塑性分析[J].石油学报,2005,26(6):99-103. Li Jun,Chen Mian,Liu Gonghui,et al.Elastic-plastic analysis of casing-concrete sheath-rock combination[J].Acta Petrolei Sinica,2005,26(6):99-103.
    [8] 李子丰,张永贵,阳鑫军.蠕变地层与油井套管相互作用力学模型[J].石油学报,2009,30(1):129-131. Li Zifeng,Zhang Yonggui,Yang Xinjun.Mechanics model for interaction between creep formation and oil well casing[J].Acta Petrolei Sinica,2009,30(1):129-131.
    [9] 马旭,龚伟安,谢建华,等.套管水泥环的室内破坏试验及力学分析[J].石油机械,2000,28(4):15-18. Ma Xu,Gong Weian,Xie Jianhua,et al.Lab test of destruction of cement sheath outside casing[J].China Petroleum Machinery,2000,28(4):15-18.
    [10] 杨恒林,陈勉,金衍,等.套管水泥环刚度与强度对抗挤性能影响分析[J].天然气工业,2006,26(11):93-95. Yang Henglin,Chen Mian,Jin Yan,et al.Effects of stiffness and strength of casing/cement-sheath on collapsing strength[J].Natural Gas Industry,2006,26(11):93-95.
    [11] 陈占锋,朱卫平,狄勤丰,等.岩盐地层中水泥环弹性模量和厚度对套管强度的影响[J].石油钻探技术,2009,37(5):58-61. Chen Zhanfeng,Zhu Weiping,Di Qinfeng,et al.Effects of cement sheath elasticity modulus and thickness on casing strength in salt beds[J].Petroleum Drilling Techniques,2009,37(5):58-61.
    [12] 曾德智,林元华,李双贵,等.非均匀地应力下水泥环界面应力分布规律研究[J].石油钻探技术,2007,35(1):32-34. Zeng Dezhi,Lin Yuanhua,Li Shuanggui,et al.Study of stress distribution of cement sheath cross section non-uniform formation stress[J].Petroleum Drilling Techniques,2007,35(1):32-34.
    [13] 邹灵战,邓金根,曾义金,等.深井盐层套管非均匀载荷计算与套管设计方法研究[J].石油钻探技术,2008,36(1):23-37. Zou Lingzhan,Deng Jingen,Zeng Yijin,et al.Investigation of casing load calculation and casing design for deep salt formation[J].Petroleum Drilling Techniques,2008,36(1):23-37.
