High-Efficiency and Safe Drilling Technologies for Development Wells in the Beibuwan Basin
-
摘要:
南海西部北部湾盆地地层微裂缝发育，水敏性强，尤其是涠洲组2段地层井眼失稳问题突出，导致井下故障频发。为了提高北部湾开发井钻井效益，使用废弃井槽，在隔水导管内开窗侧钻建立井口，以高效利用槽口资源；表层井段使用海水聚合物钻井液，同时减小其井眼直径，达到增加表层井段钻深的目的；目的层井段使用强封堵全油基钻井液钻穿涠洲组2段地层；在优选钻井液的基础上，将三开井身结构优化为二开井身结构，提高了目的层井段钻井安全，同时提高了机械钻速、缩短了钻井周期，最终形成了北部湾盆地开发井高效安全钻井技术。该技术在北部湾盆地多个油田30余口井进行了现场应用，避免了槽口资源浪费，降低了表层井段钻井液成本和目的层井段发生井下故障的概率，全井段机械钻速提高超过20%，钻井周期缩短近25%。北部湾盆地开发井高效安全钻井技术为类似油田的高效开发提供了技术借鉴。
Abstract:The Beibuwan Basin in the western South China Sea has well developed micro-fractures and strong water sensitivity, which leads to frequent drilling complexities, especially wellbore instability in the second member of the Weizhou Formation. In order to improve the drilling efficiency of development wells in Beibuwan Basin, drilling technologies and practices were summarized. The wellhead was constructed by sidetracking the riser of the abandoned wellhead slot, so as to make full use of the wellhead slot; the seawater polymer drilling fluid system was used to drill the surface casing section while reducing the borehole size of surface casing section, and to achieve deep drilling of this section; the strong plugging full oil-based drilling fluid was used to penetrate the target layer which named Weizhou 2 Formation; the casing program was optimized, and the intermediate casing and production casing were integrated, so as to improve the drilling safety of the target layer and reduce the operation time. Thus, high-efficiency and safe drilling technologies for development wells in Beibuwan Basin were finally formed. With these technologies applied in more than 30 wells in several oilfields in Beibuwan Basin, the waste of wellhead slot resources was avoided, the drilling fluid cost for surface casing section was reduced, the complex accident ratio of the target layer was reduced, the ROP of the whole well was improved by more than 20%, and the drilling period of development well was shortened by nearly 25%. These drilling technologies could provide technical references for the efficient development of similar oilfields.
-
-
![]()
图 2 优化前后全油基钻井液承压封堵性能评价结果
Figure 2. Evaluation results of under-pressure plugging performances of full oil-based drilling fluid before and after optimization
表 1 涠洲A油田一期和二期部分开发井表层井段钻井指标
Table 1 ROP Statistics in the surface casing section of some wells in the phase I and II development project of the Weizhou A Oilfield
项目 井号 井眼直径/
mm井深/
m进尺/
m纯钻时间/
h机械钻速/
（m∙h–1）一期 A2H 444.5 1 755.00 1 677.00 20.21 82.98 A4 444.5 1 643.00 1 565.00 20.84 75.10 A6 444.5 1 469.00 1 391.00 18.20 76.43 A5 444.5 1 442.00 1 364.00 15.86 86.00 二期 B6 406.4 1 893.00 1 812.00 18.82 96.30 B24 406.4 1 788.00 1 707.00 17.06 100.08 B29 406.4 1 672.00 1 591.00 16.74 95.06 B23 406.4 1 562.00 1 481.00 14.30 103.59 B13 406.4 1 481.00 1 347.00 13.04 103.30
下载: 导出CSV
表 2 北部湾盆地开发井井身结构优化前后钻井指标对比
Table 2 ROP comparison of development wells in Beibuwan Basin before and after optimization of the casing programs
油田 阶段 套管
层次井数/
口平均井深/
m平均机械
钻速/（m∙h–1）平均钻井
周期/d涠洲A 一期 3 11 3 002.00 43.21 14.48 二期 2 30 2 954.00 52.36 11.00 涠洲B 优化前 3 1 3 600.00 37.43 18.32 优化后 2 4 3 569.00 48.46 13.53
下载: 导出CSV
-
[1] 黄凯文,徐一龙,李磊,等. 南海西部油田北部湾难钻地层钻井提速技术[J]. 石油钻采工艺, 2013, 35(5): 20–23, 28. doi: 10.3969/j.issn.1000-7393.2013.05.004 HUANG Kaiwen, XU Yilong, LI Lei, et al. ROP acceleration technology for poor drill ability formation at Beibuwan Basin in the west of South China Sea Oilfield[J]. Oil Drilling & Production Technology, 2013, 35(5): 20–23, 28. doi: 10.3969/j.issn.1000-7393.2013.05.004
[2] 魏安超,罗鸣,韩成,等. 南海西部油田常规探井钻井提效技术与实践[J]. 钻采工艺, 2017, 40(3): 107–109. doi: 10.3969/J.ISSN.1006-768X.2017.03.33 WEI Anchao, LUO Ming, HAN Cheng, et al. Technology and practice of improving efficiency for conventional exploration wells in Western South China Sea Oilfield[J]. Drilling & Production Technology, 2017, 40(3): 107–109. doi: 10.3969/J.ISSN.1006-768X.2017.03.33
[3] 林四元,张杰,韩成,等. 东方气田浅部储层大位移水平井钻井关键技术[J]. 石油钻探技术, 2019, 47(5): 17–21. LIN Siyuan, ZHANG Jie, HAN Cheng, et al. Key technology for horizontal well of extended reach drilling in the shallow reservoirs of the Dongfang Gas Field[J]. Petroleum Drilling Techniques, 2019, 47(5): 17–21.
[4] 蒲晓林,梁大川,王平全,等. 抑制钻屑形成泥球的钻井液研究[J]. 西南石油学院学报, 2002, 24(2): 46–49. PU Xiaolin, LIANG Dachuan, WANG Pingquan, et al. Study on drilling fluids of inhibiting formation of mud balls by rock cuttings[J]. Journal of Southwest Petroleum Institute, 2002, 24(2): 46–49.
[5] 马勇新. 涠洲12–1油田储层损害及其防治[J]. 中国海上油气(地质), 2003, 17(6): 389–393. MA Yongxin. Reservoir damage and its control measures in Weizhou 12–1 Oilfield[J]. China Offshore Oil and Gas (Geology), 2003, 17(6): 389–393.
[6] 葛鹏飞,马庆涛,张栋. 元坝地区超深井井身结构优化及应用[J]. 石油钻探技术, 2013, 41(4): 83–86. doi: 10.3969/j.issn.1001-0890.2013.04.018 GE Pengfei, MA Qingtao, ZHANG Dong. Optimization and application of ultra-deep well casing program in Yuanba Area[J]. Petroleum Drilling Techniques, 2013, 41(4): 83–86. doi: 10.3969/j.issn.1001-0890.2013.04.018
[7] 杨玉坤. 川东北地区深井井身结构优化设计[J]. 石油钻探技术, 2008, 36(3): 33–36. doi: 10.3969/j.issn.1001-0890.2008.03.008 YANG Yukun. Deep well casing structure optimization in Northeast Sichuan area[J]. Petroleum Drilling Techniques, 2008, 36(3): 33–36. doi: 10.3969/j.issn.1001-0890.2008.03.008
[8] 田宗强,韦龙贵,韩成,等. 东方1–1气田浅层大位移水平井钻井液优化与实践[J]. 石油钻采工艺, 2017, 39(6): 713–718. TIAN Zongqiang, WEI Longgui, HAN Cheng, et al. Optimization and application of drilling fluid in the shallow extended-reach horizontal well in Dongfang1–1 Gas field[J]. Oil Drilling & Production Technology, 2017, 39(6): 713–718.
[9] 赵宝祥,陈江华,徐一龙,等. 北部湾盆地开发井表层钻井模式[J]. 石油钻采工艺, 2015, 37(6): 23–26. ZHAO Baoxiang, CHEN Jianghua, XU Yilong, et al. The pattern of surface drilling in development wells of Beibu Gulf Basin[J]. Oil Drilling & Production Technology, 2015, 37(6): 23–26.
[10] 臧艳彬,王瑞和,张锐. 川东北地区钻井漏失及堵漏措施现状分析[J]. 石油钻探技术, 2011, 39(2): 60–64. doi: 10.3969/j.issn.1001-0890.2011.02.011 ZANG Yanbin, WANG Ruihe, ZHANG Rui. Current situation analysis of circulation lost and measure in Northeast Sichuan Basin[J]. Petroleum Drilling Techniques, 2011, 39(2): 60–64. doi: 10.3969/j.issn.1001-0890.2011.02.011
[11] 林永学,王伟吉,金军斌. 顺北油气田鹰1井超深井段钻井液关键技术[J]. 石油钻探技术, 2019, 47(3): 113–120. doi: 10.11911/syztjs.2019068 LIN Yongxue, WANG Weiji, JIN Junbin. Key drilling fluid technology in the ultra deep section of Well Ying-1 in the Shunbei Oil and Gas Field[J]. Petroleum Drilling Techniques, 2019, 47(3): 113–120. doi: 10.11911/syztjs.2019068
[12] 韩成,韦龙贵,陈浩东,等. 南海西部油田常规探井钻井提速配套技术[J]. 石油钻采工艺, 2018, 40(5): 567–571. HAN Cheng, WEI Longgui, CHEN Haodong, et al. ROP enhancing technologies applied in conventional exploration wells in Western South China Sea Oilfield[J]. Oil Drilling & Production Technology, 2018, 40(5): 567–571.
[13] 吴江,李龙,任冠龙,等. 海上复杂易垮塌地层高性能油基钻井液研发与应用[J]. 钻井液与完井液, 2018, 35(5): 55–60. doi: 10.3969/j.issn.1001-5620.2018.05.011 WU Jiang, LI Long, REN Guanlong, et al. Development and application of a high performance oil base drilling fluid for drilling complex sloughing formations in offshore operations[J]. Drilling Fluid & Completion Fluid, 2018, 35(5): 55–60. doi: 10.3969/j.issn.1001-5620.2018.05.011
