Key Technologies of Green Development in the Fuling Shale Gas Field
-
摘要: 涪陵页岩气田地处山区，地下暗河溶洞发达，人口密集，开发过程中面临着环境保护问题。结合涪陵页岩气田地表自然环境特征和页岩气开发工程特点，分析了涪陵页岩气田开发过程中面临的主要环境问题，开展了土地集约化利用、水资源节约与保护、油基钻屑无害化与资源化利用、钻井和压裂污水循环利用及页岩气田开发绿色环境管理模式等技术研究，形成了适用于涪陵页岩气田的绿色开发技术体系。现场应用表明，应用绿色开发技术体系后节约土地62.1%，钻井和压裂污水循环利用率达到100%，处理后的油基钻屑含油率低于0.3%，二氧化碳减排64.47×104 t，实现了页岩气田开发零污染。研究认为，涪陵页岩气田绿色开发技术对我国页岩气田规模化开发中的环境保护具有示范作用和借鉴价值。Abstract: The Fuling Shale Gas Field is located in a mountainous area,with well developed underground rivers and karst caves.It also has a highly concentrated population,so the shale gas development in this field is faced with environmental protection problems.Combined with the characteristics of surface natural environment in the Fuling Shale Gas Field and features of shale gas development engineering,the main environmental issues encountered in the development of the Fuling Shale Gas Field were analyzed.Studies on intensive land utilization,water conservation and protection,environmentally neutral utilization and disposal of oil-based drill cuttings,recycling of drilling and fracturing wastewater,and green environment management mode of shale gas development were conducted.They were used in order to establish the green development technology system suitable for the Fuling Shale Gas Field.Field applications showed that after applying the green development technology,the land occupation was reduced by 62.1%,the recycling rate of drilling and fracturing wastewater reached 100%,the oil content of treated oil-based drill cuttings is less than 0.3%,and carbon dioxide emission has been reduced by 64.47×104 t.Thus,the goal of "zero pollution" was realized during shale gas field development.The green and environmental protection development technology of the Fuling Shale Gas Field has served as a valuable model in the environmental protection of large-scale development of shale gas fields in China.
-
-
[1] 王志刚.涪陵页岩气勘探开发重大突破与启示[J].石油与天然气地质,2015,36(1):1-6. WANG Zhigang.Breakthrough of Fuling shale gas exploration and development and its inspiration[J].Oil Gas Geology,2015,36(1):1-6. [2] 周贤海,臧艳彬.涪陵地区页岩气山地"井工厂"钻井技术[J].石油钻探技术,2015,43(3):45-49. ZHOU Xianhai,ZANG Yanbin. Application of "well factory" drilling technology in the Fuling Shale Gas Field[J]. Petroleum Drilling Techniques,2015,43(3):45-49. [3] 周德华,焦方正,贾长贵,等.JY1HF页岩气水平井大型分段压裂技术[J].石油钻探技术,2014,42(1):75-80. ZHOU Dehua,JIAO Fangzheng,JIA Changgui,et al.Large-scale multi-stage hydraulic fracturing technology for shale gas horizontal Well JY1HF[J].Petroleum Drilling Techniques,2014,42(1):75-80. [4] 刘志雄.我国能源安全保障与环境保护的相互关系及影响机制[J].科学·经济·社会,2014,32(2):125-130. LIU Zhixiong.Research on the relationship and influence mechanism of energy security and environmental protection in China[J].Science·Economy·Society,2014,32(2):125-130. [6] Ground Water Protection Council,All Consulting.Modern shale gas development in the United States:a primer[R]. Oklahoma:Ground Water Protection Council,2009.
[7] 王楠. 页岩气开发环境问题研究[J].当代经济,2013(1):62-65. WANG Nan.Research on environmental problems in shale gas development[J].Contemporary Economics,2013(1):62-65. [8] HOWARTH R W,SANTORO R,INGRAFFEA A.Methane and the greenhouse-gas footprint of natural gas from shale formations[J].Climatic Change,2011,106(4):679-690.
[9] 王亚运,柯研,周晓珉,等.页岩气勘探开发过程中的环境影响[J].油气田环境保护,2012,22(3):50-53. WANG Yayun,KE Yan,ZHOU Xiaomin,et al.Environmental impact during shale gas exploration and development process[J].Environmental Protection of Oil Gas Fields,2012,22(3):50-53. [10] ARTHUR J D,COUGHLIN B J,BOHM B K. Summary of environmental issues,mitigation strategies,and regulatory challenges associated with shale gas development in the United States and applicability to development and operations in Canada[R].SPE 138977,2010.
[11] 陈平,刘阳,马天寿.页岩气"井工厂"钻井技术现状及展望[J].石油钻探技术,2014,42(3):1-7. CHEN Ping,LIU Yang,MA Tianshou.Status and prospect of multi-well pad drilling technology in shale gas[J]. Petroleum Drilling Techniques,2014,42(3):1-7. -
