渤海人工岛大型丛式井组加密防碰优化设计技术

许军富, 徐文浩, 耿应春

许军富, 徐文浩, 耿应春. 渤海人工岛大型丛式井组加密防碰优化设计技术[J]. 石油钻探技术, 2018, 46(2): 24-29. DOI: 10.11911/syztjs.2018048
引用本文: 许军富, 徐文浩, 耿应春. 渤海人工岛大型丛式井组加密防碰优化设计技术[J]. 石油钻探技术, 2018, 46(2): 24-29. DOI: 10.11911/syztjs.2018048
XU Junfu, XU Wenhao, GENG Yingchun. Anti-Collision Optimization Design Technology for Large-Scale Infill Drilling for Cluster Well Groups in the Artificial Island of the Bohai Sea[J]. Petroleum Drilling Techniques, 2018, 46(2): 24-29. DOI: 10.11911/syztjs.2018048
Citation: XU Junfu, XU Wenhao, GENG Yingchun. Anti-Collision Optimization Design Technology for Large-Scale Infill Drilling for Cluster Well Groups in the Artificial Island of the Bohai Sea[J]. Petroleum Drilling Techniques, 2018, 46(2): 24-29. DOI: 10.11911/syztjs.2018048

渤海人工岛大型丛式井组加密防碰优化设计技术

详细信息
    作者简介:

    许军富(1972-),男,河南郑州人,1996年毕业于江汉石油学院钻井工程专业,高级工程师,主要从事钻井工艺及海上钻井项目管理工作。

  • 中图分类号: TE22

Anti-Collision Optimization Design Technology for Large-Scale Infill Drilling for Cluster Well Groups in the Artificial Island of the Bohai Sea

  • 摘要: 针对渤海人工岛B岛丛式井组大规模加密调整时,防碰绕障设计难度大、效率低的问题,在分析加密井整体防碰形势及特点的基础上,对已钻井数据进行精确性校准,基于行业标准关于丛式井组平台优化及防碰设计的原则,制定了大规模加密井防碰轨道设计流程,形成了整体优化设计方法,优化了钻井顺序、槽口匹配关系和防碰轨道设计参数。通过多轮次的槽口调整和轨道优化,在有限的井台空间内完成了45口加密井的井眼轨道设计和防碰分析工作,各井分离系数的最小值均满足行业标准最小限值1.5的要求,并且70%集中在1.7以上,整体上降低了防碰风险。研究结果表明,渤海人工岛大型丛式井组加密防碰优化设计技术能解决丛式井组大规模加密调整的防碰设计问题,并有助于提高设计质量和设计效率。
    Abstract: When infill wells were drilled and massively upscaled within cluster well groups in the artificial island B of the Bohai Sea,it was difficult with low efficiency in the design of anti-collision and obstacle-bypassing systems.According to the analysis of the overall anti-collision situation and characteristics of the infill wells,the data of previously drilled wells were accurately calibrated;the principles for cluster well group platform optimization and anti-collision design which were specified in the industrial standard were used to formulate the specific workflow for anti-collision trajectory design in order to massively upscale the infill wells,and thus form an overall optimal design method and optimized the drilling sequence,slot matching relations,as well as anti-collision trajectory design parameters.Through multiple rounds of slots adjustment and trajectory optimization,trajectory design and anti-collision analysis were conducted in 45 infilling wells in a limited well platform space.The lowest separation coefficient values of all wells met the minimum limit of 1.5 specified by the industrial standard,and 70% of such values concentrated at more than 1.7,reducing the risk of borehole collision on the whole.The research results showed that the anti-collision optimization design technology can effectively solve the anti-collision design problem in large-scale infilling adjustment of well cluster groups,and improve the design quality and efficiency.
  • [1] SY/T 6396-2014丛式井平台布置及井眼防碰技术要求[S].
    [2] 刘晓艳,施亚楠,李培丽.丛式井组总体防碰与钻井顺序优化技术及应用[J].石油钻采工艺,2012,34(2):9-12,16. LIU Xiaoyan,SHI Yanan,LI Peili.Techniques of cluster well general anti-collision and drilling sequence optimization[J].Oil Drilling Production Technology,2012,34(2):9-12,16.
    [3] 闫铁,徐婷,毕雪亮,等.丛式井平台井口布置方法[J].石油钻探技术,2013,41(2):13-16. YAN Tie,XU Ting,BI Xueliang,et al.Wellhead arranged method of cluster well pad[J].Petroleum Drilling Techniques,2013,41(2):13-16.
    [4] 杨全枝,张晓斌,吴迪,等.延长油田丛式井网加密水平井直井段交碰风险量化分析[J].石油钻采工艺,2017,39(3):298-302. YANG Quanzhi,ZHANG Xiaobin,WU Di,et al.Quantitative analysis on collision risk of vertical hole section of infill horizontal well in cluster well pattern in Yanchang Oilfield[J].Oil Drilling Production Technology,2017,39(3):298-302.
    [5] 韩雪银,付建民,钟帆,等.丛式井防碰技术在金县1-1油田的应用[J].中国海上油气,2014,26(5):70-75,82. HAN Xueyin,FU Jianmin,ZHONG Fan,et al.Application of anti-collision solution for cluster wells in JX1-1 Oilfield[J].China Offshore Oil and Gas,2014,26(5):70-75,82.
    [6]

    DOGRU S.Selection of optimum platform locations[J].SPE Drilling Engineering,1987,2(4):382-386.

    [7]

    ZHOU Z,CUI L,LI J,et al.Application of cluster well drilling technology in Sulige Gas Field[R].SPE 156183,2012.

    [8]

    LIU B,WANG X,TU A,et al.Cluster wells applied in wetland environment in North Azadegan[R].SPE 178191,2016.

    [9]

    WU C,SHARMA M M.Effect of perforation geometry and orientation on proppant placement in perforation clusters in a horizontal well[R].SPE 179117,2016.

    [10] 张晓诚,刘亚军,王昆剑,等.海上丛式井网整体加密井眼轨迹防碰绕障技术应用[J].石油科技论坛,2010,29(5):13-17. ZHANG Xiaocheng,LIU Yajun,WANG Kunjian,et al.Application of path control technology of overall infill drilling on offshore cluster well group[J].Oil Forum,2010,29(5):13-17.
    [11]

    WILSON A.Intelligent-completion installations in the Santos basin presalt cluster[J].Journal of Petroleum Technology,2016,68(4):60-63.

    [12]

    MANCHANDA R,BRYANT E C,BHARDWAJ P,et al.Strategies for effective stimulation of multiple perforation clusters in horizontal wells[R].SPE 179126,2016.

    [13] 边瑞超,周洪林,曹华庆.冀东油田人工岛丛式井钻井防碰技术[J].石油钻探技术,2017,45(5):19-22. BIAN Ruichao,ZHOU Honglin,CAO Huaqing.Anti-collision technology for drilling cluster wells in the artificial island of Jidong Oilfield[J].Petroleum Drilling Techniques,2017,45(5):19-22.
    [14]

    MARTIN B,WALTERS J V,WOODARD P W.Application of a well slot optimization process to drilling large numbers of wells in clusters on artificial islands[R].SPE 137659,2010.

    [15] 葛云华,鄢爱民,高永荣,等.丛式水平井钻井平台规划[J].石油勘探与开发,2005,32(5):94-100. GE Yunhua,YAN Aimin,GAO Yongrong,et al.Drilling pad optimization for oilfield development by cluster horizontal wells[J].Petroleum Exploration and Development,2005,32(5):94-100.
    [16] 李文飞,朱宽亮,管志川,等.大型丛式井组平台位置优化方法[J].石油学报,2011,32(1):162-166. LI Wenfei,ZHU Kuanliang,GUAN Zhichuan,et al.Location optimization for the drilling platform of large-scale cluster wells[J].Acta Petrolei Sinica,2011,32(1):162-166.
    [17] 史玉才,管志川,陈秋炎,等.钻井平台位置优选方法研究[J].中国石油大学学报(自然科学版),2007,31(5):44-47. SHI Yucai,GUAN Zhichuan,CHEN Qiuyan,et al.Location optimization method for drilling platform[J].Journal of China University of Petroleum (Edition of Natural Science),2007,31(5):44-47.
    [18] 郭永峰,朱江,齐恒之.优选海洋平台钻井方式[J].中国海上油气(工程),2002,14(5):22-24. GUO Yongfeng,ZHU Jiang,QI Hengzhi.New way to select model of drilling in offshore[J].China Offshore Oil and Gas (Engineering),2002,14(5):22-24.
