海上油田注水井液控式环空安全封隔器的研制与应用

刘红兰

刘红兰. 海上油田注水井液控式环空安全封隔器的研制与应用[J]. 石油钻探技术, 2017, 45(5): 103-107. DOI: 10.11911/syztjs.201705018
引用本文: 刘红兰. 海上油田注水井液控式环空安全封隔器的研制与应用[J]. 石油钻探技术, 2017, 45(5): 103-107. DOI: 10.11911/syztjs.201705018
LIU Honglan. Development and Application of a Hydraulic Control-Type Safety Annulus Packer for Water Injectors in Offshore Oilfields[J]. Petroleum Drilling Techniques, 2017, 45(5): 103-107. DOI: 10.11911/syztjs.201705018
Citation: LIU Honglan. Development and Application of a Hydraulic Control-Type Safety Annulus Packer for Water Injectors in Offshore Oilfields[J]. Petroleum Drilling Techniques, 2017, 45(5): 103-107. DOI: 10.11911/syztjs.201705018

海上油田注水井液控式环空安全封隔器的研制与应用

基金项目:

中国石化胜利油田分公司科技攻关项目"海上长效分层注水技术研究"(编号:YKC1403)资助。

详细信息
    作者简介:

    刘红兰(1970-),女,江苏泰兴人,1993年毕业于石油大学(华东)钻井工程专业,高级工程师,主要从事浅海油气田采油工艺研究及应用推广工作。

  • 中图分类号: TE953

Development and Application of a Hydraulic Control-Type Safety Annulus Packer for Water Injectors in Offshore Oilfields

  • 摘要: 针对埕岛油田现有环空安全封隔器无洗井通道因而难以满足开发要求的问题,在分析国内外环空安全工具优缺点的基础上,研制了具有2条独立液路(分别控制洗井和坐封机构)的液控式环空安全封隔器。该封隔器的顶部液路控制洗井机构,液压强制开启洗井,液控管线泄压后由双重弹簧控制滑套,强制关闭;中部液路与底部液路相通,控制该封隔器与管柱油层部位的分层液控封隔器同时坐封;该封隔器设计有坐封锁紧机构,在紧急情况下,液控管线意外泄压胶筒也不回缩,以达到控制环空安全的目的。基于三维井眼中管柱受力分析计算模型,根据环空安全工具的下入深度,确定了洗井结构中心管的抗拉强度,并对液控式环空安全封隔器的性能进行了分析验证。该封隔器在42口注水井进行了现场应用,结果表明,完成坐封后的滑套多次洗井作业,套压始终为0 MPa,可有效保护海洋生态环境。研究认为,液控式环空安全封隔器不仅可以解决埕岛油田现有环空安全封隔器无法解决的问题,也可以满足其他海上油田安全环保开发的要求。
    Abstract: Without flushing channels,the conventional annular-safe packers used in the Chengdao Oilfield can hardly satisfy demands for adequate oilfield development.By analyzing the annular-safe tools in China and around the world,the hydraulic annular-safe packer with two independent hydraulic channels (for control over flushing and seating devices,respectively) has been developed.The hydraulic system in the top section of the packer can be used to control the over flushing devices:and flushing operations can be initialized under control of hydraulic pressure.Upon pressure release in hydraulic control pipelines,dual springs can be initialized to control the slip sleeve and close the system.The hydraulic system in the central part is connected with that in lower parts.Jointly,they may control the simultaneous seating of packer and the packer for layered injection in reservoir sections of the pipe string;The innovative packer is equipped with locking mechanism for seating.Under emergency conditions,the rubber barrel may not retract even in circumstances with accidental pressure releasing.In this way,the annular safety can be guaranteed.Upon successful development of the hydraulic annular-safe packer,calculation model for stresses on pipe string in 3D wellbore have been used to determine tensile strength of the central pipe in accordance with setting depths of annular-safe tools.During this research,the performance of the new hydraulic annular-safe packer has been reviewed prior to the application in 42 water injectors on site.Field application performances show that properly seated slip sleeves can effectively maintain casing pressure at 0 MPa after multiple flushing operations.Generally speaking,the innovative packer can provide effective protection over marine environments.Research results show that this hydraulic annular-safe packer can effectively solve problems in existing annular-safe packers in the Chengdao Oilfield.In addition,the newly-developed packer can satisfy demands for development of other offshore oilfields in safe and environment-friendly manner.
  • [1] 刘建华.埕岛海上油井安全控制系统的应用[J].安全、健康和环境,2008,8(6):14-15. LIU Jianhua.The application of safety control systems in Chengdao offshore oil well[J].Safety Health Environment,2008,8(6):14-15.
    [2] 赵仲浩,张成富,刘军,等.海上油田过电缆封隔器坐封用堵塞器[J].石油机械,2015,43(12):86-88. ZHAO Zhonghao,ZHANG Chengfu,LIU Jun,et al.Setting plug for through-cable packer in offshore oilfield[J].China Petroleum Machinery,2015,43(12):86-88.
    [3] 王增林,孙宝全,董社霞,等.埕岛油田油水井安全控制系统[J].石油机械,2001,29(6):35-37. WANG Zenglin,SUN Baoquan,DONG Shexia,et al.Safety control system for production of Chengdao Oilfield[J].China Petroleum Machinery,2001,29(6):35-37.
    [4] 周大伟,钟功祥,梁政.国内外井下安全阀的技术现状及发展趋势[J].石油矿场机械,2007,36(3):14-16. ZHOU Dawei,ZHONG Gongxiang,LIANG Zheng.The study of technical state and development tendency for down-hole safety valve of domestic and foreign[J].Oil Field Equipment,2007,36(3):14-16.
    [5] 蔡涛,魏忠华,蔡秀玲.井下安全阀的技术分析[J].石油矿场机械,2003,32(6):93-94. CAI Tao,WEI Zhonghua,CAI Xiuling.Technical analysis of surface controlled subsurface safety valve[J].Oil Field Equipment,2003,32(6):93-94.
    [6] 李常友,刘明慧,贾兆军,等.液控式分层注水工艺技术[J].石油机械,2008,36(9):102-104. LI Changyou,LIU Minghui,JIA Zhaojun,et al.Technology of hydraulic control stratified waterflooding[J].China Petroleum Machinery,2008,36(9):102-104.
    [7] 姜广彬,姜道勇,郑金中,等.液控封隔器的设计与现场应用[J].石油机械,2010,38(1):48-50. JIANG Guangbin,JIANG Daoyong,ZHENG Jinzhong,et al.The design of hydraulic control packer and field application[J].China Petroleum Machinery,2010,38(1):48-50.
    [8] 聂飞朋,孙宝全,李治军,等.大港油田滩海地区电泵井井下安全控制系统研制[J].石油矿场机械,2011,40(1):80-83. NIE Feipeng,SUN Baoquan,LI Zhijun,et al.Subsurface safety control of electrical submersible pump oil wells in neritic area of Dagang Oilfield[J].Oil Field Equipment,2011,40(1):80-83.
    [9] 金显军,刘华东,王爱君.液控滑套开关在胜利埕岛油田的应用[J].才智,2011(31):60. JIN Xianjun,LIU Huadong,WANG Aijun.Hydraulic control sliding sleeve switch in Shengli Chengdao Oilfield[J].Intelligence,2011(31):60.
    [10] 安百新.YSYK344型液控压缩式封隔器研制与应用[J].石油矿场机械,2014,43(10):82-84. AN Baixin.Development and application of YSYK344 hydraulic control compression packet[J].Oil Field Equipment,2014,43(10):82-84.
    [11] 董文魁,尚水龙,唐凡,等.新型Y341型封隔器的研制与应用[J].石油矿场机械,2012,41(5):74-76. DONG Wenkui,SHANG Shuilong,TANG Fan,et al.New Y341 type packer develop and apply[J].Oil Field Equipment,2012,41(5):74-76.
    [12] 李奎元,金志俊.封隔器压缩式胶筒的力学特征[J].石油钻采工艺,1984,6(5):61-68. LI Kuiyuan,JIN Zhijun.Mechanical characteristics of the packer compression cylinder[J].Oil Drilling Production Technology,1984,6(5):61-68.
