投球式井下智能分控开关系统的研制及功能试验

孙浩玉, 薄鹏, 李作会, 华陈权, 朱烈涛, 马建鹏

孙浩玉, 薄鹏, 李作会, 华陈权, 朱烈涛, 马建鹏. 投球式井下智能分控开关系统的研制及功能试验[J]. 石油钻探技术, 2017, 45(4): 87-92. DOI: 10.11911/syztjs.201704015
引用本文: 孙浩玉, 薄鹏, 李作会, 华陈权, 朱烈涛, 马建鹏. 投球式井下智能分控开关系统的研制及功能试验[J]. 石油钻探技术, 2017, 45(4): 87-92. DOI: 10.11911/syztjs.201704015
SUN Haoyu, BO Peng, LI Zuohui, HUA Chenquan, ZHU Lietao, MA Jianpeng. Development and Function Test of an Intelligent Split-Control Switch for Separate-Layer Oil Production[J]. Petroleum Drilling Techniques, 2017, 45(4): 87-92. DOI: 10.11911/syztjs.201704015
Citation: SUN Haoyu, BO Peng, LI Zuohui, HUA Chenquan, ZHU Lietao, MA Jianpeng. Development and Function Test of an Intelligent Split-Control Switch for Separate-Layer Oil Production[J]. Petroleum Drilling Techniques, 2017, 45(4): 87-92. DOI: 10.11911/syztjs.201704015

投球式井下智能分控开关系统的研制及功能试验

基金项目:

国家科技重大专项"大型油气田及煤层气开发"课题"低渗油气田高效开发钻井技术(二期)"(编号:2011ZX05022)资助。

详细信息
    作者简介:

    孙浩玉(1978-),男,山东陵县人,2000年毕业于石油大学(华东)自动化仪表及应用专业,2014年获石油大学(华东)机械设计及理论专业博士学位,高级工程师,机械科学研究院哈尔滨焊接研究所与哈尔滨工业大学博士后联合培养工作站在站博士后,主要从事井下工具与仪器方面的研究工作。

  • 中图分类号: TE355.2;TE931+.2

Development and Function Test of an Intelligent Split-Control Switch for Separate-Layer Oil Production

  • 摘要: 为了降低分层采油中的生产维护成本,结合无线射频和单片机技术,研制了一种投球式井下智能分控开关控制系统,并在室内对其进行了功能试验。在分析各类井下开关系统优缺点的基础上,明确了研制思路:在地面通过投入信号小球的方式来实时灵活地控制井下目标油层开关阀的开启/关闭,实现对目标油层的有效控制。确定了总体设计方案:在油管内先后投入2个信号小球,先投入的信号小球用于井下控制系统的唤醒,后投入的信号小球携带开启/关闭目标油层开关阀的指令,用于控制目标层位开关。室内模拟试验表明,投入唤醒信号小球后井下控制器由待机模式变为工作模式,投入油层控制信号小球后,各目标油层开关阀能按预定指令正确开/关,各层通信、开关控制均满足设计要求。研究认为,研制的井下智能分控开关系统能够实现对目标油层的有效控制和降低油层间的干扰,从而实现分层采油、提高采收率。
    Abstract: Separate-layer oil production is an effective way to reduce oilfield interlayer interference and to enhance the oil recovery. In consideration toof field demands,RFID radio frequency and single-chip microcomputer technologies were used jointly to develop an intelligent split-control switch controlling system for separate-layer oil production. Lab tests were conducted to assess performances of the designed system. By analyzing advantages and disadvantages of downhole switches of various types,the following principles were identified for the development of the system:open/close of switch valve in downhole target formation could be controlled flexibly in real time by ball-throwing from the ground surface to realize effective control over target formation. Overall design could be summarized as flowing:deploy two balls in the tubing,one to trigger the downhole control system and the other one with signals for open/close of switch valves in target formations to control the switch. Lab tests showed the first ball could effectively trigger the downhole controller from low energy consumption mode into operation mode. Upon deployment of the ball with control signals,all switches in target formations could be opened/closed as required. Generally speaking,controls for communication and switches in various target formations could meet design requirements. Research results showed the newly developed intelligent split-control switch system could effectively control target formations,minimize inter-layer interferences to realize separate-layer oil production and to enhance oil recovery.
  • [1] 王妍.井下智能阀门控制系统的技术研究与装置开发[D].大连:大连理工大学,2006. WANG Yan.The research and development of intelligent valve control system of pumping well[D].Dalian:Dalian University of Technology,2006.
    [2] 周望,李志,谢朝阳.大庆油田分层开采技术的发展与应用[J].大庆石油地质与开发,1998,17(1):36-39. ZHOU Wang,LI Zhi,XIE Chaoyang.Development and application of stratified mining technology in Daqing[J].Petroleum Geology Oilfield Development in Daqing,1998,17(1):36-39.
    [3]

    CHRUSCH L J.Downhole oil and water separation:potential of a new technology[C].Indonesian Petroleum Association,25th Annual Convention Proceedings,1996:343-355.

    [4]

    ZHOU Wang,XIE Chaoyang,LI Jingshen,et al.Development and practice of separate layer production technique in Daqing Oilfield[J].SPE Advanced Technology Series,1997,5(1):87-92.

    [5] 杨百新,谭河清,魏冬花.小断块油井智能分层测试技术[J].油气田地面工程,2003,22(6):67. YANG Baixin,TAN Heqing,WEI Donghua.Intelligent hierarchical test technology for small fault block oil wells[J].Oil-Gas Field Surface Engineering,2003,22(6):67.
    [6] 谭河清,陈践发,刘静,等.抽油井智能分层测试技术研究[J].测井技术,2003,27(4):334-337. TAN Heqing,CHEN Jianfa,LIU Jing,et al.On intelligent zonation testing technology for pumping well[J].Well Logging Technology,2003,27(4):334-337.
    [7]

    MATTHEWS C M,CHACHULA R,PEACHEY B R,et al.Application of downhole oil/water separation systems in the Alliance Field[R].SPE 35817,1996.

    [8] 孙丕昊,李晶,田庆国,等.液控式修井井下开关的研制[J].石油机械,2002,30(6):38-40. SUN Pihao,LI Jing,TIAN Qingguo,et al.Development of downhole switch with hydraulic control[J].China Petroleum Machinery,2002,30(6):38-40.
    [9] 常亮.二极管包络检波电路原理及失真探究[J].电子测试,2013(17):34-36. CHANG Liang.Study on principle and distortion of diode envelope detection circuit[J].Electronic Test,2013(17):34-36.
    [10] 游志宇,杜杨,张洪,等.基于场效应管的直流电机驱动控制电路设计[J].国外电子元器件,2008(2):3-6. YOU Zhiyu,DU Yang,ZHANG Hong,et al.Design of driver and control circuit for DC motor base on MOSFET[J].Foreign Electronic Components,2008(2):3-6.
