全通径滑套球座打捞机构关键技术研究

杨德锴

杨德锴. 全通径滑套球座打捞机构关键技术研究[J]. 石油钻探技术, 2017, 45(4): 75-80. DOI: 10.11911/syztjs.201704013
引用本文: 杨德锴. 全通径滑套球座打捞机构关键技术研究[J]. 石油钻探技术, 2017, 45(4): 75-80. DOI: 10.11911/syztjs.201704013
YANG Dekai. Key Technology on Ball Seat Fishing Mechanism of Full Bore Size Sleeves[J]. Petroleum Drilling Techniques, 2017, 45(4): 75-80. DOI: 10.11911/syztjs.201704013
Citation: YANG Dekai. Key Technology on Ball Seat Fishing Mechanism of Full Bore Size Sleeves[J]. Petroleum Drilling Techniques, 2017, 45(4): 75-80. DOI: 10.11911/syztjs.201704013

全通径滑套球座打捞机构关键技术研究

基金项目:

国家科技重大专项"低丰度致密低渗油气藏开发关键技术"(编号:2016ZX05048)和中国石化科技攻关项目"免钻全通径开关滑套分段压裂技术研究"(编号:P14115)部分研究内容。

详细信息
    作者简介:

    杨德锴(1982-),男,山东济南人,2008年毕业于山东大学机械工程专业,副研究员,主要从固完井井下工具研发工作。

  • 中图分类号: TE925+

Key Technology on Ball Seat Fishing Mechanism of Full Bore Size Sleeves

  • 摘要: 球座可提出式全通径滑套可通过球座打捞机构将各级球座一次提出井口,实现管内全通径,要求球座打捞机构轴向插入载荷小,承载能力强。为此,设计了新型高承载球座打捞机构,采用理论计算和有限元分析方法,分析了齿根面锥度和承载面角度对轴向插入载荷和承载能力的影响规律,并确定了最优参数。分析结果表明,与常规球座打捞机构相比,新型高承载球座打捞机构轴向插入载荷降低了75%,当齿根锥度为1:16时,轴向插入载荷约为2 kN,轴向极限抗拉强度达到500 kN。当承载面角度小于90°时,随着齿根锥度增大,球座打捞机构的轴向承拉能力随之增强,轴向插入载荷随之降低。高承载球座打捞机构模拟入井试验一次打捞成功,表明高承载球座打捞机构能满足现场应用要求,为提高球座打捞成功率提供了新的技术途径。
    Abstract: The retrievable sleeve fishing mechanism can pull a multistage ball-seat out of hole in one trip,for a full bore size inside the pipe string,with lower axial insertion loads and high load bearing.Under such circumstances,an innovative high load bearing mechanism has been developed for fishing multi-stage ball seats.Through theoretical calculation and finite element analysis,the impact of tooth root taper and loading bearing angles on axial insertion load and load bearing capacity has been analyzed,and the optimal parameters determined.Results of analyses demonstrated that the innovative heavy-duty ball-seat fishing mechanism can reduce axial insertion loads 75% compared with conventional devices.When the tooth root taper is 1:16,the axial insertion load is approximately 2 kN,while the maximum axial insertion load is as much as 500 kN.When the load loading angle is less than 90°,the axial load bearing capacities of fishing mechanism inrease as the tooth root taper increases and the axial insertion load decreases.The high load bearing fishing mechanism has been simulated to run in hole,with successful operation in one trip thus demonstrating that the fishing mechanism can effectively meet the demands of wellsite application,and provide a new way for enhancing the success rate of ball seat fishing.
  • [1] 王迁伟,何青,陈付虎,等.可打捞滑套分段压裂技术在红河油田的应用[J].石油钻采工艺,2013,35(3):78-79. WANG Qianwei,HE Qing,CHEN Fuhu,et al.Application of separate layer fracturing with salvage sliding sleeve in Honghe Oilfield[J].Oil Drilling Production Technology,2013,35(3):78-79.
    [2] 秦金立,陈作,杨同玉,等.鄂尔多斯盆地水平井多级滑套分段压裂技术[J].石油钻探技术,2015,43(1):7-12. QIN Jinli,CHEN Zuo,YANG Tongyu,et al.Technology of staged fracturing with multi-stage sleeves for horizontal wells in the Ordos Basin[J].Petroleum Drilling Techniques,2015,43(1):7-12.
    [3] 秦金立,吴姬昊,崔晓杰,等.裸眼分段压裂投球式滑套球座关键技术研究[J].石油钻探技术,2014,42(5):52-56. QIN Jinli,WU Jihao,CUI Xiaojie,et al.Key technology on ball-activated sleeve for open hole staged fracturing[J].Petroleum Drilling Techniques,2014,42(5):52-56.
    [4] 郭朝辉,魏辽,孙文俊,等.全通径滑套分段压裂工具耐冲蚀性能试验研究[J].石油机械,2015,43(3):100-103. GUO Zhaohui,WEI Liao,SUN Wenjun,et al.Experimental study for erosion resistance of full-bore sliding sleeve staged fracturing tools[J].China Petroleum Machinery,2015,43(3):100-103.
    [5] 刘传刚,包陈义,鞠少栋,等.海上完井滑套开关工具弹性爪机构性能研究[J].石油机械,2014,42(4):34-37. LIU Chuangang,BAO Chenyi,JU Shaodong,et al.Research on the performance of the elastic claw mechanism on offshore completion sleeve switching tool[J].China Petroleum Machinery,2014,42(4):34-37.
    [6] 韩伟超.苏里格地区水平井事故复杂的预防处理[D].荆州:长江大学,2013. HAN Weichao.Prevention and treatment of the complicated accidents of horizontal wells in Sulige Area.[D].Jingzhou:Yangtze University,2013.
    [7] 苟文选.材料力学(Ⅰ)[M].北京:科学出版社,2010:369-371. GOU Wenxuan.Material mechanics(Ⅰ)[M].Beijing:Science Press,2010:369-371.
    [8] 祝效华,高原,贾彦杰.弯矩载荷作用下偏梯形套管连接螺纹参量敏感性分析[J].工程力学,2012,29(10):301-307. ZHU Xiaohua,GAO Yuan,JIA Yanjie.The parameter sensitivity analysis of buttress casing connecting thread under action of bending loading[J].Engineering Mechanics, 2012,29(10):301-307.
    [9] 祝效华,王宇,童华,等.基于弹塑性力学的油气井打捞公锥造扣全过程分析和评价[J].工程力学,2011,28(11):184-189. ZHU Xiaohua,WANG Yu,TONG Hua,et al.The overall process analysis and evaluation of pin tap tapping based on the elastoplasticity mechanics in oil and gas wells[J].Engineering Mechanics, 2011,28(11):184-189.
    [10] 章安辉,王泽,林华.弹簧钩断裂失效分析[J].分析仪器,2012,43(6):66-67. ZHANG Anhui,WANG Ze,LIN Hua.Failure analysis for the spring hook fracture[J].Analytical Instrumentation,2012,43(6):66-67.
    [11] 严仁田,王峰,张德平,等.流场诱导API圆螺纹油管接箍失效分析及结构优化[J].石油钻探技术,2012,40(5):111-114. YAN Rentian,WANG Feng,ZHANG Deping,et al.Failure analysis of API tubing round threaded connection induced by flow field[J].Petroleum Drilling Techniques,2012,40(5):111-114.
    [12] 焦文鸿,高连新,鲁喜宁.一种新型钻杆螺纹设计及应力分析[J].石油机械,2012,40(6):16-20. JIAO Wenhong,GAO Lianxin,LU Xining.Design of a new tool joint thread and its stress analysis[J].China Petroleum Machinery,2012,40(6):16-20.
    [13] 林艳华.机械制造技术基础[M].北京:化学工业出版社,2010:31-35. LIN Yanhua.Mechanical manufacturing technology[M].Beijing:Chemical Industry Press,2010:31-35.
