应力对泥页岩储层脆性影响的试验分析及应用

周顺林; 尹帅; 王凤琴; 李东; 易旺

doi:10.11911/syztjs.201703020

应力对泥页岩储层脆性影响的试验分析及应用

周顺林^1,2,
尹帅^3, ,,
王凤琴³,
李东²,
易旺²

1.
贵州煤矿地质工程咨询与地质环境监测中心, 贵州贵阳 550081;
2.
贵州省煤层气页岩气工程技术研究中心, 贵州贵阳 550081;
3.
西安石油大学地球科学与工程学院, 陕西西安 710065

基金项目:

国家科技重大专项"盘县-金沙地区海陆交互相页岩气勘查评价应用试验"（编号：2016ZX05034004-007）部分研究内容。

详细信息

作者简介:
周顺林(1981—),男,贵州兴义人,2005年毕业于中国矿业大学环境科学专业,工程师,主要从事煤田地质勘查及煤层气、页岩气勘查与开发工作。

通讯作者:
尹帅,speedysys@163.com。

中图分类号: P313.1
计量
- 文章访问数: 6143
- HTML全文浏览量: 89
- PDF下载量: 5406
出版历程
- 收稿日期: 2016-08-14
- 修回日期: 2017-03-12
- 刊出日期: 2017-07-05

Experimental Analysis of the Effect of Stress on Shale Reservoir Brittleness and Its Application

1.
Guizhou Coal Mine Geological Engineering Consulting and Geological Environment Monitoring Center, Guiyang, Guizhou, 550081, China;
2.
Guizhou Provincial CBM and Shale Gas Engineering Research Center, Guiyang, Guizhou, 550081, China;
3.
School of Earth Science and Engineering, Xi’an Petroleum University, Xi’an, Shaanxi, 710065, China

摘要

摘要: 随着地层埋深增加，岩石脆性降低，逐渐由硬脆性转变为韧性，而常规矿物组分法评价泥页岩脆性时没有考虑地层应力（埋深）的影响，因此评价结果存在一定误差。为此，从岩石脆性的最初定义出发，在不同围压条件下对陆相泥页岩岩样进行了力学测试，并利用应变法分析了泥页岩的脆性特征。结果表明：随着围压升高，泥页岩的弹性应变与塑性应变均增大，而脆性指数降低；泥页岩的弹性应变与塑性应变具有非常好的正相关性。对于文中所研究区块，埋深1 250.00，2 500.00和3 500.00 m处及埋深3 500.00~5 000.00 m和5 000.00~6 000.00 m范围内的泥页岩脆性指数分别约降低5.97%，8.55%，10.74%，14.00%和18.00%；当泥页岩储层中脆性矿物含量分别大于65%，60%，55%和小于50%时，其开发埋深下限分别为6 000.00，5 000.00和3 000.00 m以及基本不具备商业开发价值。研究结果表明，将应力（埋深）对泥页岩脆性的影响定量化，可以对采用矿物组分法计算的泥页岩脆性指数进行校正，为优选可压裂层段提供依据。
- 地层应力 /
- 埋深 /
- 泥页岩 /
- 脆性指数 /
- 岩石力学试验 /
- 应变
Abstract: As well depth increases,formation rocks brittleness may be reduced and consequently manifest as ductile behavior.Conventional mineral composition can be used to assess the brittleness of shales.Because it does not take the impact of confining pressures (burial depths) into account,one arrives at less than satisfactory assessment conclusions.Under such circumstances,mechanical tests were conducted with continental deposit shale samples under different confining pressures and a strain method was deployed in a tested result analysis to highlight brittleness features of the shale.Research results showed that both elastic and plastic strains may increase with confining pressures while the brittleness index may decrease.Within the concerned Block,the brittleness index of shale at the depths of 1 250.00 m,2 500.00 m,3 500.00 m and between the interval of 3 500.00~5 000.00 m and 5 000.00~6 000.00 m fell approximately 5.97%,8.55%,10.74%,14.00% and 18.00%,respectively.With brittle minerals content in these shale reservoir formations over 65%,60%,55% and below 50%,the formation depth limitation for economic development of those reservoirs are determined to be 6 000.00 m,5 000.00 m,2 500.00 m and no commercial value,respectively.So the shale brittleness index determined from conventional mineral composition can be calibrated through quantification of impacts of stresses (burial depths) and it can provide help in the identification of intervals for staged hydraulic fracturing.
- confining pressure /
- burial depth /
- shale /
- brittleness index /
- rock mechanical test /
- strain

HTML全文

参考文献(18)

[1]	DE SILVA P N K,SIMONS S J R,STEVENS P,et al.A comparison of North American shale plays with emerging non-marine shale plays in Australia[J].Marine and Petroleum Geology,2015,67:16-29.
[2]	ZHANG Decheng,RANJITH P G,PERERA M S A.The brittleness indices used in rock mechanics and their application in shale hydraulic fracturing:a review[J].Journal of Petroleum Science and Engineering,2016,143:158-170.
[3]	尹帅,丁文龙,李昂,等.裂缝对致密碎屑岩储层弹性影响的数值分析[J].石油钻探技术,2016,44(2):112-118. YIN Shuai,DING Wenlong,LI Ang,et al.Numerical analysis on the effect of fractures on elastic properties of tight clastic reservoirs[J].Petroleum Drilling Techniques,2016,44(2):112-118.
[4]	LI Qinghui,CHEN Mian,ZHOU Yu,et al.Rock mechanical properties of shale gas reservoir and their influences on hydraulic fracture:International Petroleum Technology Conference,Beijing,March 26-28,2013[C].
[5]	陆益祥,潘仁芳,唐小玲,等.四川盆地威远地区龙马溪组页岩储层上下亚段脆性差异[J].断块油气田,2016,23(4):429-433. LU Yixiang,PAN Renfang,TANG Xiaoling,et al.Brittleness comparison between upper and lower sub-sections of Longmaxi Formation shalereservoir in Weiyuan,Sichuan Basin[J].Fault-Block Oil Gas Field,2016,23(4): 429-433.
[6]	蒋廷学,卞晓冰,苏瑗,等.页岩可压性指数评价新方法及应用[J].石油钻探技术,2014,42(5):16-20. JIANG Tingxue,BIAN Xiaobing,SU Yuan,et al.A new method for evaluating shale fracability index and its application[J].Petroleum Drilling Techniques,2014,42(5):16-20.
[7]	王建波,冯明刚,严伟,等.焦石坝地区页岩储层可压裂性影响因素及计算方法[J].断块油气田,2016,23(2):216-220,225.WANG Jianbo,FENG Minggang,YAN Wei,et al.Influence factors and evaluation methods for shale reservoir fracability in Jiaoshiba Area[J].Fault-Block Oil Gas Field,2016,23(2):216-220,225.
[8]	HOLT R M,FJAER E,STENEBRATEN J F,et al.Brittleness of shales:relevance to borehole collapse and hydraulic fracturing[J].Journal of Petroleum Science and Engineering,2015,131(1):200-209.
[9]	UIBU M,SOMELAR P,RAADO L M.Oil shale ash based backfilling concrete-strength development,mineral transformations andleachability[J].Construction and Building Materials,2016,102:620-630.
[10]	DEWHURST D N,SAROUT J,DELLE PIANE C A,et al.Empirical strength prediction for preserved shales[J].Marine and Petroleum Geology,2015,67:512-525.
[11]	JAEGER J C,COOK N G W,ZIMMERMAN R W,et al.Fundamentals of rock mechanics[M].4th ed.Oxford:Blackwell Publishing,2007:499-500.
[12]	刘君龙,纪友亮,杨克明,等.川西须家河组前陆盆地构造层序及沉积充填响应特征[J].中国石油大学学报(自然科学版),2015,39(6):11-23. LIU Junlong,JI Youliang,YANG Keming,et al.Tectono-stratigraphy and sedimentary infill characteristics of Xujiahe Formation in Western Sichuan foreland basin[J].Journal of China University of Petroleum(Edition of Natural Science),2015,39(6):11-23.
[13]	陈冬霞,刘雨晨,庞雄奇,等.川西坳陷须五段陆相页岩层系储层特征及对含气性的控制作用[J].地学前缘,2016,23(1):174-184. CHEN Dongxia,LIU Yuchen,PANG Xiongqi,et al.Reservoir characteristics and its control on gas-bearing properties of the 5th member of the Triassic Xujiahe Formation continental shale in the Sichuan Basin of China[J].Earth Science Frontiers,2016,23(1):174-184.
[14]	陈磊,姜振学,纪文明,等.川西坳陷须五段页岩微观孔隙结构发育控制因素及其成藏意义[J].煤炭学报,2015,40(增刊2):449-457. CHEN Lei,JIANG Zhenxue,JI Wenming,et al.Controlling factors and accumulation significance of microscopic pore structure in the fifth member of Xujiahe Formation in the Western Sichuan Depression[J].Journal of China Coal Society,2015,40(supplement2):449-457.
[15]	赵金洲,许文俊,李勇明,等.页岩气储层可压性评价新方法[J].天然气地球科学,2015,26(6):1165-1172. ZHAO Jinzhou,XU Wenjun,LI Yongming,et al.A new method for fracability evaluation of shale-gas reservoirs[J].Natural Gas Geoscience,2015,26(6):1165-1172.
[16]	郭天魁,张士诚,葛洪魁.评价页岩压裂形成缝网能力的新方法[J].岩土力学,2013,34(4):947-954. GUO Tiankui,ZHANG Shicheng,GE Hongkui.A new method for evaluating ability of forming fracture network in shale reservoir[J].Rock and Soil Mechanics,2013,34(4):947-954.
[17]	尹帅,丁文龙,孙雅雄,等.泥页岩单轴抗压破裂特征及UCS影响因素[J].地学前缘,2016,23(2):75-95. YIN Shuai,DING Wenlong,SUN Yaxiong,et al.Shale uniaxial compressive failure property and the affecting factors of UCS[J].Earth Science Frontiers,2016,23(2):75-95.
[18]	刁海燕.泥页岩储层岩石力学特性及脆性评价[J].岩石学报,2013,29(9):3300-3306. DIAO Haiyan.Rock mechanical properties and brittleness evaluation of shale reservoir[J].Acta Petrologica Sinica,2013,29(9):3300-3306.
