天然气水合物脱气装置研制及性能试验

魏纳; 陈光凌; 郭平; 李清平; 吕鑫

doi:10.11911/syztjs.201702020

天然气水合物脱气装置研制及性能试验

1.
油气藏地质及开发工程国家重点实验室(西南石油大学), 四川成都 610500;
2.
中海油研究总院, 北京 100027

基金项目:

国家重点研发计划项目"海洋水合物固态流化测试新技术"（编号：2016YFC0304008）、国家自然科学"控压钻井测控理论及关键问题研究"（编号：51334003）及油气藏地质及开发工程国家重点实验室开放"水合物藏固态采掘水下输送气液固多相非平衡管流基础理论"（编号：PLN1418）资助。

详细信息

作者简介:
魏纳(1980—),男,四川成都人,2003年毕业于西南石油学院油气储运工程专业,2011年获西南石油大学油气井工程专业博士学位,副教授,主要从事海洋天然气水合物绿色钻采、控压钻井、欠平衡钻井与气体钻井等方面的技术研究工作。

中图分类号: TE242
计量
- 文章访问数: 9253
- HTML全文浏览量: 80
- PDF下载量: 10740
出版历程
- 收稿日期: 2016-09-11
- 修回日期: 2017-02-15
- 刊出日期: 2017-05-10

The Development and Experimental Testing of Gas Hydrate Degassing Devices

1.
State Key Laboratory of Oil and Gas Geology and Exploration, Southwest Petroleum University, Chengdu, Sichuan, 610500, China;
2.
CNOOC Research Institute, Beijing, 100027, China

摘要

摘要: 天然气水合物录井过程中，与振动筛相连接的脱气装置其脱气效率非常低，为解决该问题，研制了专用于天然气水合物录井的脱气装置并对其性能进行了室内试验。采用长0.7 m、宽0.7 m、高1.7 m的试验装置，开展了气液比10%~30%、转速0.33~1.33 r/s条件下的脱气效率数值模拟研究和室内试验。研究发现，在相同转速条件下，气液比为30%时模拟和室内试验得出的脱气装置的脱气效率最高；在相同气液比条件下，转速1.00 r/s时脱气装置的脱气效率最高。研究结果表明，研制的天然气水合物脱气装置能显著提高脱气效率，最优工况为气液比30%、转速1.00 r/s。
- 天然气水合物 /
- 录井 /
- 脱气装置 /
- 数值模拟 /
- 脱气效率
Abstract: During gas hydrate logging, degassing devices connected with the shale shaker have extremely low degassing efficiencies. Accordingly, degassing devices designated for gas hydrate logging have been developed. To determine the performances of these devices, lab tests were performed. By using experiment facilities with a length of 0.7 m, a width of 0.7 m and a height of 1.7 m, numerical simulations and lab tests were conducted with gas/liquid ratios of 10%-30% and rotation speeds of 0.33-1.33 r/s to determine the degassing efficiencies of these facilities. Test results showed that under identical rotation speeds, the maximum degassing efficiency of the degassing device could be achieved with gas/liquid ratio of 30% in both numerical simulation and lab tests. At the same time, under identical gas/liquid ratio, the highest degassing efficiency could be observed in degassing devices with a rotation speed of 1.00 r/s. Research results showed that gas hydrate degassing devices could significantly enhance degassing efficiency with an optimal gas/liquid ratio of 30% and a rotation speed of 1.00 r/s.
- gas hydrate /
- logging /
- degassing device /
- numerical simulation /
- degassing efficiency

HTML全文

参考文献(16)

[1]	张修安.天然气水合物开采及输送工艺技术研究[D].青岛:中国石油大学(华东)储运与建筑工程学院,2007. ZHANG Xiuan.Natural gas hydrate exploitation and transportation technology research[D].Qingdao: China University of Petroleum(Huadong),College of Pipeline and Civil Engineering,2007.
[2]	许俊良,薄万顺,朱杰然.天然气水合物钻探取心关键技术研究进展[J].石油钻探技术,2008,36(5):32-36. XU Junliang,BO Wanshun,ZHU Jieran.Development of gas hydrate coring technology[J].Petroleum Drilling Techniques,2008,36 (5):32-36.
[3]	吴华,邹德永,于守平.海域天然气水合物的形成及其对钻井工程的影响[J].石油钻探技术,2007,35(3):91-93. WU Hua,ZOU Deyong,YU Shouping.Gas hydrate formation and its influence on offshore drilling operations[J].Petroleum Drilling Techniques,2007,35 (3):91-93.
[4]	高兴军,段鸿彦.天然气水合物勘探开发技术浅析及研究策略[J].断块油气田,2001,8(3):6-7. GAO Xingjun,DUAN Hongyan.Natural gas hydrate exploration and development and its research strategy[J].Fault-Block Oil Gas Field,2001,8(3):6-7.
[5]	严国平,武庆河.脱气器的现状及发展趋势探讨[J].录井技术,1999,10(1):10-14. YAN Guoping,WU Qinghe.Existing state of degasser and the discussion of its developing trend[J].Mud Logging Technology,1999,10(1):10-14.
[6]	赵东涛.新型脱气器研发理论探讨[J].西部探矿工程,2015,27(12):90-92. ZHAO Dongtao.Research and development theory of new type degassing device[J].West-China Exploration Engineering,2015,27(12):90-92.
[7]	陈相国,姜和兴.一种新型的定量气体脱气器[J].录井技术,1997,8(4):10-16. CHEN Xiangguo,JIANG Hexing.A new type of quantitative gas degassing device[J].Mud Logging Technology,1997,8(4):10-16.
[8]	杨明清.俄罗斯气测录井脱气器现状及其与国产脱气器的对比[J].录井工程,2008,19(3):67-70. YANG Mingqing.The existing state of Russian mud logging gas trap and its comparison with the domestic gas trap[J].Mud Logging Engineering,2008,19(3):67-70.
[9]	奚庆祥.新型脱气器的改进思路及其优势[J].录井工程,2005,16(1):44-45. XI Qingxiang.Improving ideas and superiority for a new type of degasser[J].Mud Logging Engineering,2005,16(1):44-45.
[10]	Patrick Delaune.一种提高泥浆录井气体检测精度的新型脱气器[J].录井技术,1997,8(2):46-48. PATRICK D.A new type of deaerator for improving the accuracy of mud logging gas detection [J].Mud Logging Technology,1997,8(2):46-48.
[11]	颜廷俊,姜丰华,胡中南,等.新型高效定量脱气器研制及试验研究[J].中国石油大学学报(自然科学版),2015,39(6):124-128. YAN Tingjun,JIANG Fenghua,HU Zhongnan,et al.Design and field test of a new efficient quantitative degasser[J].Journal of China University of Petroleum (Edition of Natural Science),2015,39(6):124-128.
[12]	刘明,邸龙,谭建敏,等.油气分离的恒温脱气系统设计[J].机电工程技术,2015,44(4):79-81. LIU Ming,DI Long,TAN Jianmin,et al.The design of a thermostat degassing device used in the oil and gas separation module [J].Mechanical Electrical Engineering Technology,2015,44 (4):79-81.
[13]	袁惠新.分离工程[M].北京:中国石化出版社,2002:51-56. YUAN Huixin.Separation engineering[M].Beijing:China Petrochemical Press,2002:51-56.
[14]	任相军,王振波,金有海.气液分离技术设备进展[J].过滤与分离,2008,18(3):43-47. REN Xiangjun,WANG Zhenbo,JIN Youhai.Progressing of gas-liquid separation technology and equipment[J].Journal of Filtration Separation,2008,18 (3):43-47.
[15]	丁德智.新型油水分离装置的研制[D].大连:大连海事大学轮机工程学院,2003. DING Dezhi.Development of a new type of oil water separation device[D].Dalian: Dalian Maritime University,Matine Engineering College,2003.
[16]	何昭军.旋流脱气除砂试验装置在油田的应用[J].化学工程与装备,2016 (8):80-81. HE Zhaojun.Application of cyclone degassing and sand removal device in oilfield[J].Chemical Engineering Equipment,2016 (8):80-81.
