A Calculation Method for the Top Tension of Deepwater Drilling Risers Based on Recoil Response
-
摘要: 张紧力是深水钻井隔水管系统作业的安全的关键因素，尤其对隔水管系统紧急脱离作业安全影响显著，但目前的隔水管张紧力设计方法（包括API算法、底部残余张力算法以及下放最大钩载算法）均未考虑隔水管系统的反冲问题。为此，基于隔水管系统反冲响应，确定了隔水管张紧力设计准则，提出了张紧力修正API算法及计算流程，并通过实例分析验证了修正API算法的可行性。研究结果表明，修正API算法可为隔水管系统提供合理的张紧力，改善了隔水管紧急脱离反冲过程中的隔水管底部总成位移、张紧器冲程以及有效张力波动范围，从而提高了紧急脱离后隔水管系统的安全性，有效保证了深水钻井隔水管系统紧急脱离作业的安全。Abstract: Tension is the key factor in the safe operation of deepwater drilling riser systems, especially for the safe operation of emergency disconnection of the riser system. However, the present calculation methods of the top tension of drilling riser system (including the API theoretical method, a method based on the residual tension at bottom of the drilling riser system and a method based on the maximal hook load during drilling riser system running procedure) do not take riser recoil response into consideration. To address the issue, the tension design criteria based on the riser recoil response was determined. The modified API top tension calculation method and process were proposed and then verified by examples. The results showed that the modified API algorithm could provide reasonable tension calculation for riser systems. The LMRP displacement, the stroke of tensioner and fluctuation range of the effective tension during riser recoil were reduced, thus improving the security of drilling riser system after emergency disconnection and ensuring a safe deepwater drilling riser system emergency disconnection operation.
-
Keywords:
- deepwater drilling /
- riser /
- tension force /
- recoil response
-
-
[1] 刘秀全,陈国明,彭朋,等.深水钻井隔水管单根寿命管理方法[J].石油钻探技术,2011,39(2):40-44.LIU Xiuquan,CHEN Guoming,PENG Peng,et al.Deepwater drilling riser joints management[J].Petroleum Drilling Techniques,2011,39(2):40-44. [2] 刘秀全,陈国明,宋强,等.基于有限元法的深水钻井隔水管压溃评估[J].石油钻探技术,2015,43(4):43-47.LIU Xiuquan,CHEN Guoming,SONG Qiang,et al.Collapse assessment for deepwater drilling risers on the basis of finite element method[J].Petroleum Drilling Techniques,2015,43(4):43-47. [3] HOCK C J,YOUNG R D.A deepwater riser emergency disconnect antirecoil system[J].Journal of Petroleum Technology,1993,45(8):744-751.
[4] API RP 16Q Recommended practice for design selection operation and maintenance of marine drilling riser system[S].
[5] PERSENT E,GUESNON J M,HEITZ S,et al.New riser design and technologies for greater water depth and deeper drilling operations[R].SPE 119519,2009.
[6] 鞠少栋,畅元江,陈国明,等.超深水钻井作业隔水管顶张力确定方法[J].海洋工程,2011,29(1):100-104.JU Shaodong,CHANG Yuanjiang,CHEN Guoming,et al.Determination methods for the top tension of ultra deepwater drilling risers[J].The Ocean Engineering,2011,29(1):100-104. [7] 杨进,孟炜,姚梦彪,等.深水钻井隔水管顶张力计算方法[J].石油勘探与开发,2015,42(1):107-110.YANG Jin,MENG Wei,YAO Mengbiao,et al.Calculation method of riser top tension in deep water drilling[J].Petroleum Exploration and Development,2015,42(1):107-110. [8] 阮庆,陈欢,杨胜,等.深水钻井隔水管顶张力最优化设计[J].中国造船,2009,50(增刊1):20-24.RUAN Qing,CHEN Huan,YANG Sheng,et al.Optimal design of deepwater drilling riser[J].Shipbuilding of China,2009,50(supplement 1):20-24. [9] RUSTAD A M,LARSEN C M,SØRENSEN A J.FEM modelling and automatic control for collision prevention of top tensioned risers[J].Marine Structures,2008,21(1):80-112.
[10] 张磊,畅元江,刘秀全,等.深水钻井隔水管与防喷器紧急脱离后的反冲响应分析[J].石油钻探技术,2013,41(3):25-30.ZHANG Lei,CHANG Yuanjiang,LIU Xiuquan,et al.Recoil analysis for deepwater drilling riser after emergency disconnection with blowout preventer[J].Petroleum Drilling Techniques,2013,41(3):25-30. [11] 鞠少栋,畅元江,陈国明,等.深水钻井隔水管悬挂窗口确定方法[J].石油学报,2012,33(1):133-136.JU Shaodong,CHANG Yuanjiang,CHEN Guoming,et al.Determination of the hang-off window for deepwater drilling riser[J].Acta Petrolei Sinica,2012,33(1):133-136. [12] 畅元江,陈国明,孙友义,等.深水钻井隔水管的准静态非线性分析[J].中国石油大学学报(自然科学版),2008,32(3):114-118.CHANG Yuanjiang,CHEN Guoming,SUN Youyi,et al.Quasi-static nonlinear analysis of deepwater drilling risers[J].Journal of China University of Petroleum (Edition of Natural Science),2008,32(3):114-118. [13] 孙友义,陈国明,畅元江,等.超深水隔水管悬挂动力分析与避台风策略探讨[J].中国海洋平台,2009,24(2):29-32.SUN Youyi,CHEN Guoming,CHANG Yuanjiang,et al.Hang-off dynamic analysis and the discuss of typhoon-avoidance strategy for ultra-deepwater drilling risers[J].China Offshore Platform,2009,24(2):29-32. [14] 畅元江,陈国明,许亮斌.导向架隔水管在波流联合作用下的非线性动力响应[J].中国石油大学学报(自然科学版),2006,30(5):74-77,83.CHANG Yuanjiang,CHEN Guoming,XU Liangbin.Non-linear dynamic response induced by wave-current for marine risers with guide-frames[J].Journal of China University of Petroleum (Edition of Natural Science),2006,30(5):74-77,83. [15] MA P,PYKE J,VANKADARI A,et al.Ensuring safe riser emergency disconnect in harsh environments:experience and design requirements,Anchorage,Alaska,USA,June 30-July 5,2013[C].ISOPE,2013.
[16] LANG D W,REAL J,LANE M.Recent developments in drilling riser disconnect and recoil analysis for deepwater applications,Honolulu,Hawaii,USA,May 31-June 5,2009[C].ASME,2009.
[17] 盛磊祥,王荣耀,许亮斌,等.台风应急期间深水钻井隔水管悬挂撤离安全分析[J].石油钻探技术,2015,43(4):25-29.SHENG Leixiang,WANG Rongyao,XU Liangbin,et al.Safety analysis of the hang-off of deepwater drilling risers during a typhoon emergency period[J].Petroleum Drilling Techniques,2015,43(4):25-29. -
