High Quality and High Speed Drilling Technology for Ultra-Shallow Horizontal Wells in the Weibei Oilfield
-
摘要: 针对渭北油田超浅层水平井钻井过程中摩阻大、托压严重、钻井周期长、钻速慢等问题，以井身结构优化为核心，研究形成了渭北油田超浅层水平井优快钻井技术：采用二开井身结构，二开采用φ215.9 mm钻头钻进；采用“直-增-平”三段式井眼轨道，以保证井眼轨迹平滑，降低钻进摩阻与扭矩；采用倒装钻具组合，以保证钻头有效加压，提高机械钻速；优选钾铵基聚合物钻井液，造斜段摩阻系数控制在0.08以内，水平段摩阻系数控制在0.06以内，以避免或减少托压现象。该技术在8口井进行了现场应用，平均钻井周期为17.81 d，与同区块三开井身结构水平井相比钻井周期缩短了51.06%。渭北油田超浅层水平井优快钻井技术解决了该油田超浅层水平井钻井中存在的技术难点，为超浅层油藏的高效开发提供了技术支持。Abstract: Crews involved in the drilling of an ultra-shallow horizontal well in Weibei Oilfield encountered multiple problems, such as high friction, serious weight on bit (WOB) stack, long drilling cycle and low ROP. Focusing on optimization of casing program, a high quality and high speed (HQHS) drilling technology was developed. Specifically, a casing program with two spudding well sections was used, and φ215.9 mm drill bits were used to drill the second section. The "straight-increase-flat" well trajectory was adopted in order to ensure the hole smoothness and reduce the friction and torque. The inverted BHA was selected to ensure that the WOB could be increased effectively to improve the ROP. In order to avoid or eliminate WOB stack, a potassium amino polymer drilling fluid system was selected to control the friction coefficient to keep the building up section less than 0.08 and the friction coefficient in the horizontal section less than 0.06. Field application in 8 wells showed that the average drilling cycle was 17.81 d, which was 51.06% less than a horizontal well with three spudding well sections in the same block. The HQHS drilling technology for ultra-shallow horizontal wells had been successfully applied in Weibei Oilfield, providing technical reference for effective development of ultra-shallow reservoirs.
-
Keywords:
- ultra-shallow formation /
- horizontal well /
- casing program /
- optimization design /
- Weibei Oilfield
-
-
[1] 闫吉曾.渭北油田高水垂比水平井钻井设计与应用[J].石油钻探技术,2015,43(2):130-134.YAN Jizeng.The design and application of horizontal well drilling with high Dep/TVD ratio in the Weibei Oilfield[J].Petroleum Drilling Techniques,2015,43(2):130-134. [2] 彭志恒,王翔.渭北油田延长组储层油层保护技术研究[J].江汉石油职工大学学报,2014,27(1):16-19.PENG Zhiheng,WANG Xiang.A study of reservoir protection technology applied to Yanchang Formation in Weibei Oilfield[J].Journal of Jianghan Petroleum University of Staff and Workers,2014,27(1):16-19. [3] 赵静.吉林油田低渗油藏水平井开发技术[J].石油勘探与开发,2011,38(5):594-599.ZHAO Jing.Development techniques of horizontal wells in low permeability reservoirs,Jilin Oilfield[J].Petroleum Exploration and Development,2011,38(5):594-599. [4] 唐洪卫,刘伟,李辉,等.川西浅层长水平段水平井井身结构优化与应用[J].天然气技术与经济,2014,8(1):46-48.TANG Hongwei,LIU Wei,LI Hui,et al.Optimization of casing program for shallow horizontal wells with long horizontal interval,Western Sichuan Basin[J].Natural Gas Technology and Economy,2014,8(1):46-48. [5] 王勇茗,周文军,王彦博,等.致密油1500 m长水平段水平井井身结构优化设计[J].钻采工艺,2013,36(6):20-23.WANG Yongming,ZHOU Wenjun,WANG Yanbo,et al.Optimization design of well structure with 1500 m horizontal segment in the tight reservoir[J].DrillingProduction Technology,2013,36(6):20-23. [6] 赵金洲,韩来聚,唐志军.高平1井大位移水平井钻井设计与施工[J].石油钻探技术,2010,38(6):29-32.ZHAO Jinzhou,HAN Laiju,TANG Zhijun.Design and drilling of Gaoping 1 ERD horizontal well[J].Petroleum Drilling Techniques,2010,38(6):29-32. [7] 陈庭根,管志川.钻井工程理论与技术[M].东营:石油大学出版社,2000:112-114.CHEN Tinggen,GUANG Zhichuan.Theory and techniques in drilling engineering[M].Dongying:Petroleum University Press,2000:112-114. [8] 陈路原.大牛地气田盒1气藏水平井开发工程技术与实践[J].石油钻探技术,2015,43(1):44-51.CHEN Luyuan.Technology and practice for horizontal well development in the He-1 Gas Reservoir of Daniudi Gas Field[J].Petroleum Drilling Techniques,2015,43(1):44-51. [9] 张永清,张阳,邓红琳,等.红河油田长8油藏水平井钻完井技术[J].断块油气田,2015,22(3):384-387.ZHANG Yongqing,ZHANG Yang,DENG Honglin,et al.Technology of well drilling and completion for horizontal well in Chang 8 oil reservoir of Honghe Oilfield[J].Fault-Block OilGas Field,2015,22(3):384-387. [10] 都振川,秦利民,周跃云.埕北21-平1大位移水平井的设计与施工[J].石油钻探技术,2000,28(5):9-11.DU Zhenchuan,QIN Limin,ZHOU Yueyun.Design and operation of Chengbei 21-Ping 1 extended-reach horizontal well[J].Petroleum Drilling Techniques,2000,28(5):9-11. [11] 韩来聚,牛洪波.对长水平段水平井钻井技术的几点认识[J].石油钻探技术,2014,42(2):7-11.HAN Laiju,NIU Hongbo.Understandings on drilling technology for long horizontal section wells[J].Petroleum Drilling Techniques,2014,42(2):7-11. [12] 王伟.浅层大位移水平井轨迹控制技术[J].钻采工艺,2013,36(1):15-17,21.WANG Wei.Trajectory control technology of extended reach horizontal well in shallow reservoir[J].DrillingProduction Technology,2013,36(1):15-17,21. [13] 李克智,闫吉曾.红河油田水平井钻井提速难点与技术对策[J].石油钻探技术,2014,42(2):117-122.LI Kezhi,YAN Jizeng.Difficulties and technical countermeasures for improving penetration rate of horizontal wells in Honghe Oilfield[J].Petroleum Drilling Techniques,2014,42(2):117-122. [14] 刘从军,蓝强,张斌,等.高平1井钻井液技术[J].石油钻探技术,2010,38(6):71-74.LIU Congjun,LAN Qiang,ZHANG Bin,et al.Drilling fluid for Well Gaoping 1[J].Petroleum Drilling Techniques,2010,38(6):71-74. [15] 刘魁威,刘霞,邱建军,等.井楼超浅层大位移水平井钻井液体系[J].断块油气田,2008,15(5):88-90.LIU Kuiwei,LIU Xia,QIU Jianjun,et al.Drilling fluid system for extended reach horizontal well with ultra-shallow layer in Block Jinglou[J].Fault-Block OilGas Field,2008,15(5):88-90. [16] 徐同台,洪培云,潘世奎.水平井钻井液与完井液[M].北京:石油工业出版社,1999:55-70.XU Tongtai,HONG Peiyun,PAN Shikui.The drilling fluid and completion fluid for horizontal well[M].Beijing:Petroleum Industry Press,1999:55-70. -
