Technologies for Raising the Oil Drainage Rate with Vertical-Horizontal Well Combinations in SAGD Mode
-
摘要: 针对辽河油田直井与水平井组合SAGD井组在开发过程中存在泄油速率低、蒸汽腔扩展不均匀等问题,以R.M.Bulter建立的双水平井泄油模型为理论基础,将直井与水平井简化为双水平井,在考虑端点效应有限长度水平井日产量方程的基础上,建立了水平井的泄油速率模型,并得到直井与注汽水平井组合SAGD上产和稳产阶段的泄油速率方程。分析泄油速率方程发现,直井与水平井组合SAGD井组泄油速率的主控因素为泄油井点数和蒸汽腔纵向扩展高度,结合辽河油田稠油开发实践,给出了直井与水平井组合SAGD井组提高泄油速率的技术措施,即水平段跟部注汽井增加2口,并将注汽井注汽排量提高20%,同时将最佳射孔位置设在靠近低物性段处,补孔长度确定为8 m。该技术在辽河油田6井组进行了现场应用,日产油量均呈现不同程度的上升,取得阶段性成功,为进一步提高SAGD井组泄油速率奠定了良好的基础。Abstract: Due to the low drainage rate and the uneven expansion of steam cavity appearing in the development of the Liaohe Oilfield which utilizes a vertical-horizontal well combination by steam assisted gravity drainage (SAGD), a horizontal-well drainage rate model was developed. It focused on a daily output equation for horizontal wells which have limited length and take into account the point effect (following the theory of R. M. Butler). With a dual-horizontal-well drainage model, and the vertical-horizontal well group was simplified as dual horizontal wells, finally, the drainage rate equation that was used for vertical well and horizontal steam injection well in SAGD. The drainage model was developed and applied to the stages of initial production and stable production. It is shown from the analysis on drainage rate equation that the drainage rate of vertical-horizontal well group SAGD is mainly controlled by the quantity of oil drainage wells and the vertical expansion height of the steam cavity. Combined with the heavy oil development practice in Liaohe Oilfield, the technical measures for increasing the drainage rate of vertical-horizontal well group SAGD were proposed. The approach involved drilling another two steam injection wells at the heel of the horizontal section and to increase the steam injection rate by 20%. Meanwhile, the best perforation position was set near the sections with low physical properties, with reperforation length of 8 m. These technical measures were applied to 6 well groups in the Liaohe Oilfield, and as a result, the daily oil production increased by different percentages. This research with field test provides the good basis for further improving the drainage rate of SAGD well groups.
-
Keywords:
- vertical well /
- horizontal well /
- steam /
- gravity drainage /
- oil drainage rate
-
-
[1] 吴霞.蒸汽辅助重力泄油技术研究进展[J].特种油气藏,2007,14(1):7-10,18. WU Xia.Progress of steam assisted gravity drainage[J].Special Oil Gas Reservoirs,2007,14(1):7-10,18. [2] 褒建军.国外水平井稠油热力开采技术[J].石油钻探技术,1996,24(4):44-47. BAO Jianjun.The technology of thermal production with horizontal well abroad[J].Petroleum Drilling Techniques,1996,24(4):44-47. [3] 杨明合,张文波,李积风,等.浅层稠油SAGD水平井与直井联合钻完井技术[J].石油钻探技术,2011,39(5):23-26. YANG Minghe,ZHANG Wenbo,LI Jifeng,et al.Shallow heavy oil reservoir SAGD horizontal well and vertical well joint operation drilling completion technology[J].Petroleum Drilling Techniques,2011,39(5):23-26. [4] 刘尚奇,包连纯,马德胜.辽河油田超稠油油藏开采方式研究[J].石油勘探与开发,1999,26(4):80-81. LIU Shangqi,BAO Lianchun,MA Desheng.The study on the exploitation way of ultra heavy oil reservoir in Liaohe Oilfield[J].Petroleum Exploration and Development,1999,26(4):80-81. [5] 岳宗杰,李勇,于海军.辽河油田杜84区块超稠油油藏水平井钻井技术[J].石油钻探技术,2005,33(6):15-18. YUE Zongjie,LI Yong,YU Haijun.Horizontal drilling technologies for exploiting ultra-thick reservoir in Du-84 Block,Liaohe Oilfield[J].Petroleum Drilling Techniques,2005,33(6):15-18. [6] 张辉登,李春兰,黄世军,等.直平组合SAGD注采井网及参数影响研究[J].断块油气田,2015,22(1):94-97. ZHANG Huideng,LI Chunlan,HUANG Shijun,et al.Effects of injection-production pattern and parameter on SAGD using combination of vertical and horizontal wells[J].Fault-Block Oil Gas Field,2015,22(1):94-97. [7] 武毅,张丽萍,李晓漫,等.超稠油SAGD开发蒸汽腔形成及扩展规律研究[J].特种油气藏,2007,14(6):40-43. WU Yi,ZHANG Liping,LI Xiaoman,et al.Study of steam chamber growth and expansion in SAGD for ultra heavy oil[J].Special Oil Gas Reservoirs,2007,14(6):40-43. [8] 杨立强,陈月明,王宏远,等.超稠油直井-水平井组合蒸汽辅助重力泄油物理和数值模拟[J].中国石油大学学报(自然科学版),2007,31(4):64-69. YANG Liqiang,CHEN Yueming,WANG Hongyuan,et al.Physical and numerical simulation of steam assisted gravity drainage with vertical and horizontal well combination in extra heavy oil reservoir[J].Journal of China University of Petroleum(Edition of Natural Science),2007,31(4):64-69. [9] 张孝燕.馆陶SAGD下步动态调整[J].内蒙古石油化工,2012,38(5):49-51. ZHANG Xiaoyan.The next dynamic adjustment of Guantao SAGD[J].Inner Mongulia Petrochemical Industry,2012,38(5):49-51. [10] 刘尚奇,王晓春,高永荣,等.超稠油油藏直井与水平井组合SAGD技术研究[J].石油勘探与开发,2007,34(2):234-238. LIU Shangqi,WANG Xiaochun,GAO Yongrong,et al.SAGD process with the combination of vertical and horizontal wells in super-heavy oil reservoir[J].Petroleum Exploration and Development,2007,34(2):234-238. [11] 郭二鹏,刘尚奇,王晓春,等.直井与水平井组合的蒸汽辅助重力泄油产量预测[J].断块油气田,2008,15(3):71-74. GUO Erpeng,LIU Shangqi,WANG Xiaochun,et al.Method of production forecast for SAGD with combination of vertical and horizontal wells[J].Fault-Block Oil and Gas Field,2008,15(3):71-74. [12] YANG G,Bulter R M.Effects of reservoir heterogeneities on heavy oil recovery by steam-assisted gravity drainage[J].The Journal of Canadian Petroleum Technology,1992,31(8):37-43.
[13] 赵田,高亚丽,乙广燕,等.水平井蒸汽辅助重力驱数学模型的建立及求解方法[J].大庆石油地质与开发,2005,24(4):40-41. ZHAO Tian,GAO Yali,YI Guangyan,et al.Establishment of mathematical model for horizontal well SAG flooding and its solution method[J].Petroleum Geology Oilfield Development in Daqing,2005,24(4):40-41. [14] BUTLER R M.Gravity drainage to horizontal wells[J].Journal of Canadian Petroleum Technology,1992,31(4):31-37.
[15] 吴向红,叶继根,马远乐.水平井蒸汽辅助重力驱油藏模拟方法[J].计算物理,2002,19(6):549-552. WU Xianghong,YE Jigen,MA Yuanle.SAGD numerical simulation with horizontal wells[J].Chinese Journal of Computational Physics,2002,19(6):549-552. [16] BULTER R M.Thermal recovery of oil and bitumen[M].Upper Saddle River:Prentice Hall,1991:233-237.
[17] CHOW L,BUTLER R M.Numerical simulation of the steam-assisted gravity drainage process(SAGD)[J].Journal of Canadian Petroleum Technology,1996,35(6):55-62.
[18] 尤洪军,王宏远,刘洪涛,等.温度观察井系统在超稠油SAGD开发中的应用[J].油气地质与采收率,2008,15(3):99-101. YOU Hongjun,WANG Hongyuan,LIU Hongtao,et al.Application of temperature observation wells system in the SAGD[J].Petroleum Geology and Recovery Efficiency,2008,15(3):99-101. -
