Research and Application of the Position-Occupying Drilling String Techniques for Twin Holes in Monobores in Bohai Oilfield
-
摘要: 传统的单筒双井技术一般为两口井共用一个一开井眼,受工具、工艺和技术的限制,一开井段中完井深较浅(约300.00~400.00 m),且存在一开井段双井轨迹无法分离、扩眼易出现新井眼、水泥用量大等问题,严重限制了一开井段单筒双井作业的顺利实施。为解决该问题,结合渤海A油田的具体情况,引进了占位钻具技术,并通过改造悬挂基座等配套工具、细化工艺及优化设计,成功实现了海4井、海22井两口井的井眼轨迹独立预斜、一开φ339.7 mm套管分别加深至1000.00 m和600.00 m,同井深情况下水泥用量相对减少50%以上,既达到封固浅层气地层、降低井眼轨迹碰撞风险及减小水泥用量的目的,又为后续二开、三开等井段留足了安全余量。最终海4井和海22井的完钻井深分别达到4428.00 m和3173.00 m,实现了安全、高效作业,有效缩短了工期,取得了较大的经济效益。Abstract: In twin hole drilling, traditional technology only allows achieving an initial depth about 300.00-400.00 meters in twinhole due to limitations imposed by tools, processes and technologies. At the same time, there are some drawbacks, such as having two wells in one hole, making another hole when reaming and providing a large amount of cement. All these conditions may make it impossible to meet demands of some wells. To solve these problems, and with consideration to specific conditions of the A Oilfield in the Bohai Area, position-occupying drilling techniques had been introduced. With the combination of reconstruction, fine tuning and design optimization of hanger base and other auxiliary facilities, borehole trajectories in Well Hai 4 and Well Hai 22 were controlled independently. The depth of the φ339.7 mm casing in the first spud-in was deepened to 1, 000.00 m and 600.00 m. The volume of cement consumed was reduced by more than 50% when compared with wells of similar depths. Deployment of these techniques can effectively seal off shallow gas formations, minimize risks related to collision of boreholes and reduce the volume of cement consumption. In addition, these techniques might generate necessary safety redundancy for the second, third and other well intervals. TVD of the Well Hai 4 and the Well Hai 22 are 4428.00 m and 3173.00 m, respectively. In addition to achieve safe and high-efficiency implementation of relevant operations, these techniques can effectively reduce the time required and significantly enhance economic benefits of relevant operations.
-
-
[1] 李凡,赵少伟,张海,等.单筒双井表层预斜技术及其在绥中36-1油田的应用[J].石油钻采工艺,2012,34(增刊1):12-15. LI Fan,ZHAO Shaowei,ZHANG Hai,et al.Preventive oblique technology of single hole double wells surface andits application in Suizhong 36-1 Oilfield[J].Oil Drilling Production Technology,2012,34(supplement 1):12-15. [2] 梁奇敏,冯舒,赵铁桥,等.单筒双井表层预斜扩眼钻井技术在渤海油田定向井中的应用[J].中国海上油气,2013,25(5):64-68. LIANG Qimin,FENG Shu,ZHAO Tieqiao,et al.The application of dual bore well surface pre-deflection and reaming drilling technology in directional well in Bohai Oilfield[J].China Offshore Oil and Gas,2013,25(5):64-68. [3] 王宝毅,李建辉,张敏峰.单筒双井技术应用及经济性分析[J].钻井液与完井液,2011,28(增刊1):51-53,58. WANG Baoyi,LI Jianhui,ZHANG Minfeng.Application and economic analying of single-conductor and double-wells technology[J].Drilling Fluid Completion Fluid,2011,28(supplement 1):51-53,58. [4] 姬洪刚,卓振洲,张雪峰,等.渤海某油田利用模块钻机调整井钻井作业的难点与对策[J].科技创新与应用,2014,80(6):77-78. JI Honggang,ZHUO Zhenzhou,ZHANG Xuefeng,et al.Difficulties and countermeasures of drilling operation in the use of module drilling rig in Bohai[J].Technology Innovation and Application,2014,80(6):77-78. [5] 叶周明,刘小刚,崔治军,等.大尺寸井眼钻井工艺在渤海油田某探井中的应用和突破[J].石油钻采工艺,2014,36(4):18-21. YE Zhouming,LIU Xiaogang,CUI Zhijun,et al.Application and breakthrough of large-size hole drilling technology in some exploration well in Bohai Oilfield[J].Oil Drilling Production Technology,2014,36(4):18-21. [6] 王小勇,李虎成,杨可三,等.占位钻具形式单筒双井钻井技术研究及应用[J].中国海上油气,2015,27(4):107-111. WANG Xiaoyong,LI Hucheng,YANG Kesan,et al.Research and application of twinhole in monbore drilling technology with occupying position drilling string[J].China Offshore Oil and Gas,2015,27(4):107-111. [7] 庞炳章,徐荣强,牟小军,等.非对称单筒双井技术在文昌13-2油田的应用[J].石油钻采工艺,2007,29(6):4-6. PANG Bingzhang,XU Rongqiang,MU Xiaojun,et al.Application of a symmetric two-in-one technology in Wenchang 13-2 Oilfield[J].Oil Drilling Production Technology,2007,29(6):4-6. [8] 梁丹,吕鑫,蒋珊珊,等.渤海油田分级组合深部调剖技术[J].石油钻探技术,2015,43(2):104-109. LIANG Dan,LYU Xin,JIANG Shanshan,et al.The technology of classified combination of deep profile control in the Bohai Oilfield[J].Petroleum Drilling Techniques,2015,43(2):104-109. [9] 刘小刚,崔治军,陶林,等.渤海油田科学探索井井身结构优化设计[J].断块油气田,2011,18(5):663-665. LIU Xiaogang,CUI Zhijun,TAO Lin,et al.Optimization design of wellbore structure for scientific exploration well in Bohai[J].Fault-Block Oil Gas Field,2011,18(5):663-665. [10] 张海山,杨进,宫吉泽,等.东海西湖区块高温高压深探井井身结构优化[J].石油钻探技术,2014,42(6):25-29. ZHANG Haishan,YANG Jin,GONG Jize,et al.Optimization of casing program for HTHP deep exploratory wells in Block Xihu of East China Sea[J].Petroleum Drilling Techniques,2014,42(6):25-29. [11] 刘小刚,陶林,王玉山,等.渤海油田高温高压井套管优化设计[J].断块油气田,2011,18(6):787-789. LIU Xiaogang,TAO Lin,WANG Yushan,et al.Optimal design of casing of high temperature and high pressure well in Bohai Oilfield[J].Fault-Block Oil Gas Field,2011,18(6):787-789. [12] 董星亮,曹式敬,唐海雄,等.海洋钻井手册[M].北京:石油工业出版社,2011:51-53. DONG Xingliang,CAO Shijing,TANG Haixiong,et al.Offshore drilling manual[M].Beijing:Petroleum Industry Press,2011:51-53. -
