抗硫化氢高强度冻胶阀试验研究

李志勇, 陈帅, 陶冶, 马攀, 杨超

李志勇, 陈帅, 陶冶, 马攀, 杨超. 抗硫化氢高强度冻胶阀试验研究[J]. 石油钻探技术, 2016, 44(2): 65-69. DOI: 10.11911/syztjs.201602011
引用本文: 李志勇, 陈帅, 陶冶, 马攀, 杨超. 抗硫化氢高强度冻胶阀试验研究[J]. 石油钻探技术, 2016, 44(2): 65-69. DOI: 10.11911/syztjs.201602011
LI Zhiyong, CHEN Shuai, TAO Ye, MA Pan, YANG Chao. Experimental Study on High Strength Anti-H2S Gel Valves[J]. Petroleum Drilling Techniques, 2016, 44(2): 65-69. DOI: 10.11911/syztjs.201602011
Citation: LI Zhiyong, CHEN Shuai, TAO Ye, MA Pan, YANG Chao. Experimental Study on High Strength Anti-H2S Gel Valves[J]. Petroleum Drilling Techniques, 2016, 44(2): 65-69. DOI: 10.11911/syztjs.201602011

抗硫化氢高强度冻胶阀试验研究

基金项目:

国家科技重大专项"易漏易塌地层钻完井及储层保护技术研究"(编号:2016ZX05044);国家自然科学"低渗裂缝性砂岩凝析气藏损害机理及有效保护开发一体化新方法研究"(编号:51374225);国家留学基金(编号:CSCNo.201506445008)和校优秀青年教师"封堵钻井恶性漏失的新型高强度凝胶研制"(编号:2462015YQ0211)联合资助。

详细信息
    作者简介:

    李志勇(1978-),男,山东莱州人,2000年毕业于石油大学(华东)石油工程专业,2006年获中国石油大学(北京)油气井工程专业博士学位,副教授,主要从事钻井液优化设计、储层保护和钻井废弃物处理方面的研究。E-maillzysoar11@163.com。

  • 中图分类号: TE249

Experimental Study on High Strength Anti-H2S Gel Valves

  • 摘要: 在新疆油田实施冻胶阀欠平衡钻井时,地层中富含的硫化氢气体会侵蚀破坏冻胶,影响冻胶阀的性能与使用寿命,针对此问题,开展了抗硫化氢高强度冻胶阀研究。在模拟井温125℃条件下,依次筛选出了主聚合物、有机交联剂、除硫剂三氧化二铁和处理剂,并对其加量进行了优选,配制了冻胶液。对该冻胶液的黏度、冻胶强度、最大可封隔压力及破胶性能等基本性能进行了评价,并利用抗硫化氢评价装置评价了硫化氢对冻胶性能的影响。评价结果显示,冻胶液黏度为50 mPa·s,抗硫化氢高强度冻胶阀在125℃下3.5 h后完全成胶,170 h内保持冻胶性能不下降,成胶24 h后每单位长度冻胶的封隔压力为0.08 MPa,能有效抵抗10000 mg/L硫化氢气体连续24 h侵入,体积分数10%的破胶剂可使冻胶60 min内完全破胶。研究表明,抗硫化氢高强度冻胶阀具有良好的抗温性、粘壁性和较高的承压强度,能够满足含硫化氢地层欠平衡钻井安全的需要。
    Abstract: When underbalanced drilling is carried out in Xinjiang Oilfield, the gel is eroded by rich H2S existed in the formation, and gel valves are severely affected by its working performance and life. In order to solve this problem, a series of studies were performed with high strength anti-H2S gel valves. At the simulated well temperature of 125℃, main polymers, organic crosslinking agents, ferric oxide (sulfide scavenger) and additives were selected in order, and optimized dosages to make up the gel. Experimental evaluation was performed on the basic performance of gel fluids, such as viscosity, gel strength, maximum sealing pressure and breaking capacity. Moreover, the effect of hydrogen sulfide on gel performance was evaluated by using anti-H2S evaluation apparatus. The results of evaluation showed that the viscosity of gel fluid was 50 mPa·s, the high-strength anti-H2S gel valve could be completely formed into gel at the temperature of 125℃ for 3.5 hours, and performance kept no change for 170 hours. Twenty four hours after gelling, the sealing pressure per meter of gel was 0.08 MPa, which could effectively resist 24 hours’ continuous invasion of 10000 mg/L H2S, and it may be broken completely within 60 minutes by adding the gel breaker with volume fraction of 10%. The research indicated that the high-strength anti-H2S gel valve had good performance in temperature resistance, wall stickiness and bearing strength, and it can meet the safety requirements for the underbalanced drilling in H2S-bearing formations.
  • [1] 陈会年,张国龙,梁何生.国内外欠平衡钻井工艺技术现状[J].西部探矿工程,2000,12(2):72-73,76. CHEN Huinian,ZHANG Guolong,LIANG Hesheng.Status at home and abroad of under-balanced drilling technology[J].West-China Exploration Engineering,2000,12(2):72-73,76.
    [2] 栗广科.负压钻井技术在探井中的初步应用[J].石油钻探技术,1998,26(2):19-20. LI Guangke.Application of underbalanced pressure drilling techniques in exploration wells[J].Petroleum Drilling Techniques,1998,26(2):19-20.
    [3] 张辉,刘功威,兰凯,等.欠平衡钻井技术在元坝121H井的应用[J].断块油气田,2014,21(4):524-526. ZHANG Hui,LIU Gongwei,LAN Kai,et al.Application of underbalanced drilling technology in Well Yuanba121H[J].Fault-Block Oil Gas Field,2014,21(4):524-526.
    [4] 杨顺辉,赵向阳,石宇,等.高温高压凝析气井全过程欠平衡设计[J].石油钻探技术,2012,40(5):22-25. YANG Shunhui,ZHAO Xiangyang,SHI Yu,et al.Total UBO design of HPHT gas-condensate well[J].Petroleum Drilling Techniques,2012,40(5):22-25.
    [5] 赵小祥,邢树宾,毛迪,等.沙特MTLH-1井全过程欠平衡钻井技术[J].石油钻探技术,2010,38(5):60-64. ZHAO Xiaoxiang,XING Shubin,MAO Di,et al.Whole process under-balanced drilling technology in Well MTLH-1 in Saudi Arabia[J].Petroleum Drilling Techniques,2010,38(5):60-64.
    [6] 陈永明.全过程欠平衡钻井中的不压井作业[J].石油钻探技术,2006,34(2):22-25. CHEN Yongming.No-killing operations in whole course underbalanced drilling[J].Petroleum Drilling Techniques,2006,34(2):22-25.
    [7] 胡金忠.全过程欠平衡钻井技术概述[J].长江大学学报(自科版),2013,10(32):167-168. HU Jinzhong.Overview of the whole process of underbalanced drilling technology[J].Journal of Yangtze University(Natural Science Edition),2013,10(32):167-168.
    [8] 王在明,朱宽亮,冯京海,等.高温冻胶阀的研制与现场试验[J].石油钻探技术,2015,43(4):78-82. WANG Zaiming,ZHU Kuangliang,FENG Jinghai,et al.Development and field test of high-temperature valve[J].Petroleum Drilling Techniques,2015,43(4):78-82.
    [9] 高成军,张立春,张讲丽.欠平衡钻井技术的应用与认识[J].断块油气田,2009,16(5):116-119. GAO Chengjun,ZHANG Lichun,ZHANG Jiangli.Application and knowledge of underbalanced drilling technology[J].Fault-Block Oil Gas Field,2009,16(5):116-119.
    [10] 管桐,杨慧,邹啁,等.欠平衡钻井中冻胶阀技术研究及应用[J].广东化工,2012,39(10):70-71. GUAN Tong,YANG Hui,ZOU Zhou,et al.Gel valve technology and its application in underbalanced drilling[J].Guangdong Chemical Industry,2012,39(10):70-71.
    [11] 胡挺,曾权先,李华磊,等.冻胶阀完井技术研究与应用[J].石油钻采工艺,2012,34(1):32-35. HU Ting,ZENG Quanxian,LI Hualei,et al.Study and application of smart pack completion technology[J].Oil Drilling Production Technology,2012,34(1):32-35.
    [12] 刘德基,廖锐全,张慢来,等.冻胶阀技术及应用[J].钻采工艺,2013,36(2):28-29,33. LIU Deji,LIAO Ruiquan,ZHANG Manlai,et al.Technology and application of gel valve[J].Drilling Production Technology,2013,36(2):28-29,33.
    [13] 戴彩丽,冯海顺,简家斌,等.耐高温冻胶泡沫选择性堵水剂:适用于东海气田高温气藏堵水稳产[J].天然气工业,2015,35(3):60-67. DAI Caili,FENG Haishun,JIAN Jiabin,et al.A selective water-plugging system with heat-resistant gel foam:a case study from the East China Sea Gas Field[J].Natural Gas Industry,2015,35(3):60-67.
    [14] 戴彩丽,赵福麟,海热提,等.基于溶剂置换法的冻胶堵剂选择性试验[J].中国石油大学学报(自然科学版),2008,32(4):73-75,98. DAI Caili,ZHAO Fulin,HAI Reti,et al.Test on selective plugging of gel based on solvent substitution method[J].Journal of China University of Petroleum(Edition of Natural Science),2008,32(4):73-75,98.
    [15] 王任芳,李克华.聚丙烯酰胺与高价金属离子交联机理研究[J].江汉石油学院学报,1999,21(2):38-40. WANG Renfang,LI Kehua.Study on the crosslinking mechanism of polyacrylamide with multivalent metal ions[J].Journal of Jianghan Petroleum Institute,1999,21(2):38-40.
    [16] 王鉴,赵福麟.高价金属离子与聚丙烯酰胺的交联机理[J].石油大学学报(自然科学版),1992,16(3):32-39. WANG Jian,ZHAO Fulin.Crosslinking mechanism of multivalent metal ions with polyacrylamide[J].Journal of the University of Petroleum,China(Edition of Natural Science),1992,16(3):32-39.
    [17] 刘德基,尹玉川,陈超,等.冻胶阀[J].石油科技论坛,2012(4):61-62,67. LIU Deji,YIN Yuchuan,CHEN Chao,et al.Gel valve[J].Oil Forum,2012(4):61-62,67.
    [18] 何龙,崔亚,陈凯,等.新型冻胶型堵剂微冻胶的制备及其评价工艺[J].精细石油化工,2007,24(3):11-15. HE Long,CUI Ya,CHEN Kai,et al.Preparation and evaluation techniques for new gel plugging agent microgel[J].Speciality Petrochemicals,2007,24(3):11-15.
    [19] 唐孝芬,刘玉章,向问陶,等.交联聚合物冻胶调堵剂性能评价指标及方法[J].石油钻采工艺,2004,26(2):49-53. TANG Xiaofen,LIU Yuzhang,XIANG Wentao,et al.Performance evaluation indexes and measures of cross-linked polymer gel for water shutoff and profile control[J].Oil Drilling Production Technology,2004,26(2):49-53.
    [20] 李晓辉.冻胶段塞密封井筒油气强度研究[J].油田化学,2015,32(1):15-17. LI Xiaohui.Oil and gas intensity of wellbore sealing by gel slug[J].Oilfield Chemistry,2015,32(1):15-17.
