The Development and Application of a Microsphere Gel Composite Plugging Agents
-
摘要: 为解决涪陵地区页岩气储层层理、裂缝发育导致的油基钻井液漏失严重的问题,通过分析页岩气地质特征及油基钻井液特性,研制出纳微米级可变形球状凝胶,辅配优选出的片状、纤维状封堵材料,合成了球状凝胶复合封堵剂。室内评价表明,在油基钻井液中加入2.4%球状凝胶复合封堵剂后,高温高压滤饼厚度由4.0 mm减小至1.5 mm,高温高压滤饼渗透率降低97.66%,20/40目石英砂床封堵承压能力由2 MPa提高至17 MPa。该球状凝胶复合封堵剂在涪陵地区66口井的现场应用结果表明,其与油基钻井液的配伍性好,可随钻封堵微孔、微裂缝,防止或减少钻井液漏失,从而有效降低油基钻井液的钻进损耗。Abstract: During drilling shale gas wells in the Fuling Area, the oil-based drilling fluid is often lost seriously due to bedding and developed fractures. To address this problem, a nano-micron deformable spherical gel was developed after the geological characteristics of shale gas and properties of oil based drilling fluid were analyzed, and sheet or fibrous plugging materials were selected additionally to form the composite microsphere gel plugging agent on the basis of compatibility and sealing performance evaluation. Laboratory evaluation showed that the thickness of mud cake at high temperature and high pressure (HTHP) decreased from 4.0 mm to 1.5 mm, permeability reduced by 97.66%, and the pressure-bearing capacity of quartz sand bed (20 to 40 mesh) increased from 2 MPa to 17 MPa after adding microsphere gel plugging agent by 2.4% into oil based drilling fluids. This agent was applied to 66 wells in Fuling Area, and the results indicated that composite microsphere gel plugging agent was well compatible with oil-based drilling fluids, and it can prevent or reduce the loss of drilling fluid by plugging micropores and microfractures in drilling operation, so as to decrease the loss of oil based drilling fluids effectively.
-
Keywords:
- micro-sphere gel /
- plugging agent /
- oil based drilling fluid /
- lost circulation /
- plugging /
- shale gas /
- Fuling Area
-
-
[1] 谭希硕.涪陵页岩气水平井钻井液防渗漏技术[J].承德石油高等专科学校学报,2015,17(1):10-13. TAN Xishuo.Drilling fluid anti-leakage technology for shale gas horizontal well of Fuling Area[J].Journal of Chengde Petroleum College,2015,17(1):10-13. [2] 封钦亚,许艺博,张欣,等.页岩气藏三重介质模型压力动态分析及其应用[J].断块油气田,2015,22(5):600-605. FENG Qinya,XU Yibo,ZHANG Xin,et al.Pressure dynamic analysis and application of triple medium model for shale gas reservoir[J].Fault-Block Oil Gas Field,2015,22(5):600-605. [3] 周贤海.涪陵焦石坝区块页岩气水平井钻井完井技术[J].石油钻探技术,2013,41(5):26-30. ZHOU Xianhai.Drilling completion techniques used in shale gas horizontal wells in Jiaoshiba Block of Fuling Area[J].Petroleum Drilling Techniques,2013,41(5):26-30. [4] 王显光,李雄,林永学.页岩水平井用高性能油基钻井液研究与应用[J].石油钻探技术,2013,41(2):17-22. WANG Xianguang,LI Xiong,LIN Yongxue.Research and application of high performance oil base drilling fluid for shale horizontal wells[J].Petroleum Drilling Techniques,2013,41(2):17-22. [5] 于延雄,代一钦.涪陵页岩气田油基钻井液防漏堵漏技术探讨[J].江汉石油科技,2015,25(1):33-36. YU Yanxiong,DAI Yiqin.The probe of Fuling Shale Gas Field oil-based drilling fluid leak plugging technique[J].Jianghan Petroleum Science and Technology,2015,25(1):33-36. [6] 王中华.国内外油基钻井液研究与应用进展[J].断块油气田,2011,18(4):533-537. WANG Zhonghua.Research and application progress of oil-based drilling fluid at home and abroad[J].Fault-Block Oil Gas Field,2011,18(4):533-537. [7] 何兴贵,乔军,张新旭,等.南方海相低压地层堵漏新技术[J].特种油气藏,2001,8(4):66-68. HE Xinggui,QIAO Jun,ZHANG Xinxu,et al.Lost circulation plugging technique in low pressure formation of marine facies in Southern China[J].Special Oil Gas Reservoirs,2001,8(4):66-68. [8] 张士万,孟志勇,郭战峰,等.涪陵地区龙马溪组页岩储层特征及其发育主控因素[J].天然气工业,2014,34(12):16-24. ZHANG Shiwan,MENG Zhiyong,GUO Zhanfeng,et al.Characteristics and major controlling factors of shale reservoirs in the Longmaxi Fm,Fuling Area,Sichuan Basin[J].Natural Gas Industry,2014,34(12):16-24. [9] 周贤海,臧艳彬,陈小锋.涪陵页岩气田井漏现状与技术对策[J].江汉石油职工大学学报,2015,28(3):16-19. ZHOU Xianhai,ZANG Yanbin,CHEN Xiaofeng.Technological strategies for lost circulation of Fuling Shale Gas Field[J].Journal of Jianghan Petroleum University of Staff and Workers,2015,28(3):16-19. [10] 李湘涛,石文睿,郭美瑜,等.涪陵页岩气田焦石坝区海相页岩气层特征研究[J].石油天然气学报,2014,36(11):11-15. LI Xiangtao,SHI Wenrui,GUO Meiyu,et al.Research of marine facies shale gas characteristics of Jiaoshiba in Fuling focal shale gas field[J].Journal of Oil and Gas Technology,2014,36(11):11-15. [11] 王中华.关于加快发展我国油基钻井液体系的几点看法[J].中外能源,2012,17(2):36-42. WANG Zhonghua.Several views on accelerating the development of oil-based drilling fluid system in China[J].Sino-Global Energy,2012,17(2):36-42. [12] 张凡,许明标,刘卫红,等.一种油基膨胀封堵剂的合成及其性能评价[J].长江大学学报(自科版),2010,7(3):507-509. ZHANG Fan,XU Mingbiao,LIU Weihong,et al.Synthesis and properties evaluation of a kind of oil-based swelling plugging agent[J].Journal of Yangtze University (Natural Science Edition),2010,7(3):507-509. [13] 岳前升,向兴金,李中,等.油基钻井液的封堵性能研究与应用[J].钻井液与完井液,2006,23(5):40-42. YUE Qiansheng,XIANG Xingjin,LI Zhong,et al.Study on sealing characteristics of oil based drilling fluid and its application[J].Drilling Fluid Completion Fluid,2006,23(5):40-42. -
期刊类型引用(21)
1. 孙金声，杨景斌，吕开河，白英睿，刘敬平，黄贤斌. 致密油气钻井液技术研究现状与展望. 石油学报. 2025(01): 279-288 .
百度学术
2. 严平. 某区块常用桥浆堵漏配方的优化与评价. 山东化工. 2024(07): 187-190 . 百度学术
3. 王长勤，李忠寿，黄桃，李广林，张勇，魏士军. 红星区块多粒径致密封堵油基钻井液技术. 钻井液与完井液. 2024(02): 191-197 . 百度学术
4. 孙金声，杨景斌，白英睿，吕开河，刘锋报. 深层超深层钻井液技术研究进展与展望. 石油勘探与开发. 2024(04): 889-898 . 百度学术
5. SUN Jinsheng，YANG Jingbin，BAI Yingrui，LYU Kaihe，LIU Fengbao. Research progress and development of deep and ultra-deep drilling fluid technology. Petroleum Exploration and Development. 2024(04): 1022-1034 . 必应学术
6. 杨国涛. 低黏高切型白油基钻井液体系优选及应用. 精细石油化工进展. 2024(05): 1-7 . 百度学术
7. 曾光，高德伟，曾家新，万秀梅，严俊涛. 抗返吐堵漏剂的研制及现场应用. 油田化学. 2023(01): 26-31+38 . 百度学术
8. 付旻皓，王平全，鲁劲松，冉超，苏俊霖. 延长组长_7段页岩水基钻井液封堵剂评价研究. 西南石油大学学报(自然科学版). 2023(05): 173-182 . 百度学术
9. 董云峰，韩成. 油基钻井液堵漏体系及材料研究进展. 化工设计通讯. 2023(11): 37-39 . 百度学术
10. 陈军，王平，李占超. 油基钻井液防漏堵漏理论与技术研究进展. 当代化工研究. 2022(12): 162-164 . 百度学术
11. 程荣超，王建华，闫丽丽，张继国，兰笛，李颖颖. 油基钻井液用抗高温树脂类封堵剂的研制. 当代化工研究. 2021(05): 160-162 . 百度学术
12. 孙金声，白英睿，程荣超，吕开河，刘凡，冯杰，雷少飞，张洁，郝惠军. 裂缝性恶性井漏地层堵漏技术研究进展与展望. 石油勘探与开发. 2021(03): 630-638 . 百度学术
13. SUN Jinsheng，BAI Yingrui，CHENG Rongchao，LYU Kaihe，LIU Fan，FENG Jie，LEI Shaofei，ZHANG Jie，HAO Huijun. Research progress and prospect of plugging technologies for fractured formation with severe lost circulation. Petroleum Exploration and Development. 2021(03): 732-743 . 必应学术
14. 项营，王玺，蒋官澄，邓正强，李万军，叶禹，周海秋. 反相乳液聚合法合成凝胶微球及其封堵性能评价. 钻井液与完井液. 2020(03): 275-281 . 百度学术
15. 黄津松，张家旗，王建华，杨海军，闫丽丽. 国内油基钻井液研发现状与思考. 化工管理. 2020(33): 130-133 . 百度学术
16. 赵福豪，黄维安. 钻井液防漏堵漏材料研究进展. 复杂油气藏. 2020(04): 96-100 . 百度学术
17. 马文英，刘昱彤，钟灵，刘文堂，孙东营，毛世发. 油基钻井液封堵剂研究及应用. 断块油气田. 2019(04): 529-532 . 百度学术
18. 杨海平. 涪陵平桥与江东区块页岩气水平井优快钻井技术. 石油钻探技术. 2018(03): 13-19 . 本站查看
19. 杨小华，王中华. 2015～2016年国内钻井液处理剂研究进展. 中外能源. 2017(06): 32-40 . 百度学术
20. 王广财，王丰年，张军，呼惠娜，王小龙，李俊. 凝胶复合防漏堵漏技术在火焰山腹地表层的应用. 钻井液与完井液. 2017(03): 49-53 . 百度学术
21. 李胜，夏柏如，林永学，王显光，韩秀贞. 焦页54-3HF井低油水比油基钻井液技术". 石油钻探技术. 2017(01): 51-56 . 本站查看
