Research and Application of Drilling, Milling-Grinding Techniques for Drilling out Composite Bridge Plugs in Coiled Tubing in Horizontal Wells
-
摘要: 针对连续油管钻磨桥塞过程中经常由于工艺参数选择不合理导致施工效率低的问题,通过分析连续油管钻磨工艺特点、钻磨工具的工作特性以及井底磨屑在不同井段的运移规律,结合"上提扫屑和定点循环"的钻除桥塞模式,对施工工艺进行了调整,对工作参数进行了优化,形成了水平井连续油管钻磨桥塞的工艺方案:选用PDC镶齿5刀翼磨鞋,螺杆钻具选择"中扭矩、中转速"工作模式,排量不低于420 L/min,钻压控制在14.7~19.6 kN。该工艺在数十口井进行了现场应用,与优化调整前相比,单个桥塞的平均钻除时间缩短46.5 min,钻磨动力液消耗量减少49.4%,一趟钻具能够连续钻除12个复合桥塞。应用结果表明,连续油管钻磨桥塞工艺在压裂后可以迅速恢复井筒畅通,达到提速增效的目的,具有很好的推广应用价值。Abstract: Due to the selection of improper parameters, the operational efficiency is low in the application of tubing drilling and grinding technology to drill and mill the bridge plug. Through the analysis of the characteristics of coiled tubing drilling and milling/grinding process, the working performance of drilling tools and the carrying regularity of cuttings at different sections of wellbore hole drilling, combined with the mode of drilling bridge plug:"cleaning cuttings by pulling up making circulationling at a fixed point", the operations were improved, technology was optimized, the working parameters were optimized, and a technical scheme of drilling and milling the bridge plug in the working mode of the horizontal wells was implemented. The PDC mill shoe bit with 5 blades and PDM screw drilling tools featured as medium torques and rotation speeds have been selected. It is recommended that the flow rate displacement should be maintained no lower than 420 L/min, and the weight on bit should be controlled within 14.7-19.6 kN. These technology processes have been carried out in several wells in the field. The average drilling time of a single bridge plug is shortened by 46.5 min compared with the performances before optimization and adjustment, and the consumption of drilling fluid is reduced by 49.4%. Twelve composite bridge plugs can be removed by running drilling strings once. The application results showed that the techniques of coiled tubing drilling and milling and grinding can quickly restore wellbore flow after fracturing and increase drilling efficiency. Consequently, it is worth promoting and applying widely.
-
-
[1] 陈立人,张永泽,龚惠娟.连续油管钻井技术与装备的应用及其新进展[J].石油机械,2006,34(2):59-63. CHEN Liren,ZHANG Yongze,GONG Huijuan.Application and new progress of coiled tubing drilling technology and equipment[J].China Petroleum Machinery,2006,34(2):59-63. [2] 刘寿军,李根生.我国连续管技术面临的挑战和发展建议[J].石油机械,2013,41(11):1-5. LIU Shoujun,LI Gensheng.Challenges for China’s coiled tubing technology and development suggestions[J].China Petroleum Machinery,2013,41(11):1-5. [3] DUAN Mingqin,MISKA S,YU Mengjiao,et al.Transport of small cuttings in extended-reach drilling[J].SPE Drilling Completion,2008,23(3):258-265.
[4] 宋先知,李根生,王梦抒,等.连续油管钻水平井岩屑运移规律数值模拟[J].石油钻探技术,2014,42(2):28-32. SONG Xianzhi,LI Gensheng,WANG Mengshu,et al.Numerical simulation on cuttings carrying regularity for horizontal wells drilled with coiled tubing[J].Petroleum Drilling Techniques,2014,42(2):28-32. [5] Williams C E Jr,Bruce G H.Carrying capacity of drilling muds[J].Journal of Petroleum Technology,1951,3(4):111-120.
[6] 曲洪娜,黄中伟,李根生,等.水平井旋转射流冲砂洗井水力参数设计方法[J].石油钻探技术,2011,39(6):39-43. QU Hongna,HUANG Zhongwei,LI Gensheng,et al.Hydraulic parameters of sand-flushing with rotating jets in horizontal wells[J].Petroleum Drilling Techniques,2011,39(6):39-43. [7] 李洪乾,杲传良,任耀秀,等.水平井钻井第二洗井区环空止动返速的计算[J].石油钻探技术,1995,23(增刊1):27-29,85. LI Hongqian,GAO Chuanliang,REN Yaoxiu,et al.Calculations of annular slip velocity in the 2nd cleaning area during horizontal drilling[J].Petroleum Drilling Techniques,1995,23(supplement 1):27-29,85. [8] 窦国仁.再论泥沙起动流速[J].泥沙研究,1996(6):1-9. Dou Guoren,Incipient motion of coarse and fine sediment[J].Journal of Sediment Research,1999(6):1-9. [9] 赖枫鹏,李治平,岑芳,等.水平井水力冲砂最优工作参数计算[J].石油钻探技术,2007,35(1):69-71. LAI Fengpeng,LI Zhiping,CEN Fang,et al.Optimum working parameters for hydraulic sand washing in horizontal wells[J].Petroleum Drilling Techniques,2007,35(1):69-71. [10] 陈迎春,张仕民,王文明,等.连续油管屈曲力学特性研究进展[J].石油矿场机械,2013,42(12):15-20. CHEN Yingchun,ZHANG Shimin,WANG Wenming,et al.Study progress in buckling behavior of coiled tubing[J].Oil Field Equipment,2013,42(12):15-20. [11] 汪海阁,刘希圣,丁岗,等.水平井水平井段环空压耗模式的建立[J].石油大学学报(自然科学版),1996,20(2):30-35. WANG Haige,LIU Xisheng,DING Gang,et al.Development of model in annular space of for pressure drop horizontal well[J].Journal of the University of Petroleum,China(Edition of Natural Science),1996,20(2):30-35. [12] 沈忠厚.水射流理论与技术[M].东营:石油大学出版社,1997:176-210. SHEN Zhonghou.Theory and technology of water jet[M].Dongying:University of Petroleum Press,1997:176-210. -
