复杂条件下疏松砂岩油藏动态出砂预测研究

董长银, 张清华, 崔明月, 王鹏, 高彦才, 李效波

董长银, 张清华, 崔明月, 王鹏, 高彦才, 李效波. 复杂条件下疏松砂岩油藏动态出砂预测研究[J]. 石油钻探技术, 2015, 43(6): 81-86. DOI: 10.11911/syztjs.201506015
引用本文: 董长银, 张清华, 崔明月, 王鹏, 高彦才, 李效波. 复杂条件下疏松砂岩油藏动态出砂预测研究[J]. 石油钻探技术, 2015, 43(6): 81-86. DOI: 10.11911/syztjs.201506015
Dong Changyin, Zhang Qinghua, Cui Mingyue, Wang Peng, Gao Yancai, Li Xiaobo. A Dynamic Sanding Prediction Model for Unconsolidated Sandstone Reservoirs with Complicated Production Conditions[J]. Petroleum Drilling Techniques, 2015, 43(6): 81-86. DOI: 10.11911/syztjs.201506015
Citation: Dong Changyin, Zhang Qinghua, Cui Mingyue, Wang Peng, Gao Yancai, Li Xiaobo. A Dynamic Sanding Prediction Model for Unconsolidated Sandstone Reservoirs with Complicated Production Conditions[J]. Petroleum Drilling Techniques, 2015, 43(6): 81-86. DOI: 10.11911/syztjs.201506015

复杂条件下疏松砂岩油藏动态出砂预测研究

基金项目:

国家自然科学"疏松砂岩油气藏水平井管外地层砾石充填机理及模拟基础研究"(编号:51374226)资助。

详细信息
    作者简介:

    董长银(1976—),男,河南卫辉人,1998年毕业于石油大学(华东)石油工程专业,2003年获石油大学(华东)油气田开发工程专业博士学位,教授,硕士生导师,主要从事采油采气工程、岩石力学与防砂完井方面的研究工作。

  • 中图分类号: TE254

A Dynamic Sanding Prediction Model for Unconsolidated Sandstone Reservoirs with Complicated Production Conditions

  • 摘要: 静态出砂预测没有考虑地层压力、含水饱和度和地层温度等变化对出砂临界条件的影响,导致开发过程中出砂预测结果与实际偏差较大。为了研究动态因素对出砂条件的影响规律,根据试验结果拟合岩石强度含水饱和度的变化规律,含水饱和度由0.15变为0.50时,储层岩石强度下降幅度可达60%左右;考虑地层压力下降对近井地应力的影响,以及温度变化导致的储层热应力改变,建立了稠油热采储层动态出砂临界条件的预测方法。渤海油田注多元热流体油井数据分析表明,储层出砂临界压差随着地层压力下降和温度升高以类似于指数式规律降低,在早期变化较快,然后下降速度逐步变缓;出砂临界压差随含水饱和度和含水率的升高以接近线性的规律降低。研究表明,注热开采稠油油藏出砂风险最大的时期为注热—焖井—生产的转换阶段,即转生产的初期,此时应逐步缓慢提高产量到正常产量。
    Abstract: Static sanding prediction models overlook the effect of reservoir pressure, water cut, water saturation and reservoir temperature on critical sanding conditions, so some differences resulted between the predicted sanding result and the practical one in the production process. In this paper, studies were performed on the influential law of dynamic factors on sanding conditions. First, the variation rules of rock strength and water saturation were fitted on the basis of experimental results. They indicated that the rock strength would decrease up to 60% with water saturation increasing from 0.15 to 0.50. Second, a dynamic prediction method was developed for critical sanding conditions in heavy-oil thermal production reservoirs by investigating the effect of reservoir pressure decrease on near wellbore stresses and the variation of reservoir thermal stress variation induced from temperature variation. And finally, an analysis was conducted on the data of injected with multiple thermal fluids of oil wells in Bohai Bay. It indicates that critical sanding pressure drawdown (CSPD) drops with the decrease of reservoir pressure and the increase of reservoir temperature can be represented by by approximate exponential law. It decreases faster in the early stages and gradually slows down. CSPD also decreases with the increase of water cut or water saturation and approximates a linear rule. For heavy oil reservoirs with thermal production, the most potential sanding is in the transitional stage of heat injection, soaking and production, i.e. the initial transitional stage to production. The production rate should be increased gradually to normal levels in this stage.
  • [1] 董长银.油气井防砂技术[M].北京:中国石化出版社,2009:29-40. Dong Changyin.Oil gas well sand control technology[M].Beijing:China Petrochemical Press,2009:29-40.
    [2] 王艳辉,刘希圣.定向油气井出砂模型的建立与参数分析[J].石油大学学报:自然科学版,1995,19(增刊1):60-65. Wang Yanhui,Liu Xisheng.Analysis on stress distribution in directional well and factors affecting on sand production[J].Journal of the University of Petroleum,China:Edition of Natural Science,1995,19(supplement 1):60-65.
    [3] 董长银,张启汉,饶鹏.气井系统出砂预测模型研究及应用[J].天然气工业,2005,25(9):98-100. Dong Changyin,Zhang Qihan,Rao Peng.Model of systematic sanding prediction and its application for gas wells[J].Natural Gas Industry,2005,25(9):98-100.
    [4] 饶鹏,唐刚,董长银,等.以临界生产压差法进行涩北气田出砂预测研究[J].天然气勘探与开发,2005,28(2):32-34. Rao Peng,Tang Gang,Dong Changyin,et al.Sebei Gas Field sanding prediction by critical producing pressure drop[J].Natural Gas Exploration Development,2005,28(2):32-34.
    [5] 王东辉,韩英.斜井临界生产压差预测[J].断块油气田,2008,15(6):102-104. Wang Donghui,Han Ying.Prediction of critical drawdown pressure for inclined well[J].Fault-Block Oil Gas Field,2008,15(6):102-104.
    [6] 张锦宏.利用声波测井资料预测油井出砂的问题研究[J].江汉石油学院学报,2003,25(3):122-123. Zhang Jinhong.Problems in predicting sand production with sonic logging data[J].Journal of Jianghan Petroleum Institute,2003,25(3):122-123.
    [7] 董长银,王爱萍.出砂水平井近井塑性区出砂半径预测研究[J].中国矿业大学学报,2012,41(4):663-668. Dong Changyin,Wang Aiping.Distribution of plastic stress near wellbore and prediction of sanding radius for sanding horizontal wells[J].Journal of China University of Mining Technology,2012,41(4):663-668.
    [8] 董长银.水平井防砂完井理论与技术[M].北京:中国石化出版社,2012:27-45. Dong Changyin.Sand control completion theory and technology for horizontal wells[M].Beijing:China Petrochemical Press,2012:27-45.
    [9]

    El-Sayed Abdel-Alim H,Alsughayer Ali A.A new concept to predict sand production from extended reach and horizontal wells[R].SPE 68134,2001.

    [10]

    Dou Hongen,Hu Dandan,Cai Wenxin.Sand production prediction and the selection of completion methods for horizontal well in Intercampo Oilfield,Venezuela[R].SPE 93821,2005.

    [11]

    Nouri Alireza,Vaziri Hans,Belhaj Hadi,et al.Comprehensive transient modeling of sand production in horizontal wellbores[R].SPE 84500,2007.

    [12] 赵益忠,孙德旭,梁伟,等.考虑开发动态的定性经验出砂动态预测[J].石油钻采工艺,2013,35(5):67-70. Zhao Yizhong,Sun Dexu,Liang Wei,et al.Research on qualitative experimental dynamic sanding prediction considering the development performance[J].Oil Drilling Production Technology,2013,35(5):67-70.
    [13] 孙强,姜春露,朱术云,等.饱水岩石水稳试验及力学特性研究[J].采矿与安全工程学报,2011,28(2):236-240. Sun Qiang,Jiang Chunlu,Zhu Shuyun,et al.Water stability test and mechanical property of water saturated rocks[J].Journal of Mining Safety Engineering,2011,28(2):236-240.
    [14] 汪伟英,张公社,何海峰,等.毛管力与含水饱和度对岩石出砂的影响[J].中国海上油气:工程,2003,15(3):47-48. Wang Weiying,Zhang Gongshe,He Haifeng,et al.The effect of capillary pressure and water saturation on sand production[J].China Offshore Oil and Gas:Engineering,2003,15(3):47-48.
    [15] 王煜霞,许波涛.水对不同岩石声波速度影响的研究[J].岩土工程技术,2006,20(3):144-146. Wang Yuxia,Xu Botao.Study on the water influence on the acoustic wave velocity of different rock[J].Geotechnical Engineering Technique,2006,20(3):144-146.
    [16] 李静,林承焰,杨少春,等.套管-水泥环-地层耦合系统热应力理论解[J].中国石油大学学报:自然科学版,2009,33(2):63-69. Li Jing,Lin Chengyan,Yang Shaochun,et al.Theoretical solution of thermal stress for casing-formation coupling system[J].Journal of China University of Petroleum:Edition of Natural Science,2009,33(2):63-69.
    [17] 李维特,黄保海,毕仲波.热应力理论分析及应用[M].北京:中国电力出版社,2004:60-65. Li Weite,Huang Baohai,Bi Zhongbo.Thermal stress theory and application[M].Beijing:China Electric Power Press,2004:60-65.
    [18] 陈朝晖,谢一婷,邓勇.疏松砂岩油藏出砂应力敏感实验研究[J].石油钻探技术,2013,41(1):61-64. Chen Zhaohui,Xie Yiting,Deng Yong.Experimental study on sanding stress sensitivity in unconsolidated sandstone reservoirs[J].Petroleum Drilling Techniques,2013,41(1):61-64.
