Numerical Simulation for Cuttings Migration during Gas Drilling of Horizontal Wells
-
摘要: 针对气体钻水平井过程中的井眼净化问题,开展了水平段岩屑运移特征研究。基于气固两相流动模型,采用FLUENT软件模拟了气体钻井条件下不同粒径、不同注气量、不同钻杆转速和不同钻杆偏心距下单颗粒岩屑和岩屑颗粒群在水平环空的运移特性。模拟结果表明,单颗粒岩屑在水平环空的运移以跃移形式为主,而岩屑颗粒群的运移主要包括蠕移和跃移两种形式;粒径5.0 mm岩屑在注气量50,70和90 m3/min下的首次跳跃距离分别为0.55,0.90和1.50 m;在注气量为50 m3/min时,粒径1.5 mm岩屑的首次跳跃距是粒径3.0 mm岩屑的1.5倍;粒径7.0 mm岩屑在钻杆静止和转速为60 r/min下的第3次跳跃距离分别为0.43和0.62 m;粒径6.0 mm岩屑在偏心距0,10和15 mm条件下的第2次跳跃距离分别为0.55,0.44和0.28 m。研究表明,注气量越大、粒径越小、偏心距越小、钻杆转动越快,则岩屑运移的距离越远。建议采取适当提高注气量、安装水平井井眼净化工具、提高钻杆居中度等措施,以提高井眼净化效果。Abstract: To enhance the hole-cleaning performance during gas drilling of horizontal wells, research has been conducted for characteristics of cutting migration in horizontal sections. Based on the gas-solid flow model, the migration characteristics of single-particle cuttings and multi-particle cuttings were simulated using FLUENT at different diameters, gas injection rates, rotating speeds and eccentric distances of drillpipe. The results showed that in a horizontal annulus, single-particle cuttings mainly migratedin saltation, while multi-particle cuttings migrated in creep and saltation. For the gas injection rates of 50 m3/min, 70 m3/min and 90 m3/min, the first saltation distances of 5mm diameter cuttings were 0.55 m, 0.90 m and 1.50 m respectively. For the gas injection rate of 50 m3/min, 1.5 mm diameter cuttings’ first saltation distance is 1.5 times of 3.0 mm diameter cuttings.For the rotating speeds of 0 r/min and 60 r/min, the third saltation distances of 7.0 mm diameter cuttings were 0.43 m and 0.62 m respectively under the gas injection rate of 50 m3/min. For the eccentric distances of 0 mm, 10 mm and 15 mm, the second saltation distances of 6 mm diameter cuttings were 0.55 m, 0.44 m and 0.28 m respectively under the gas injection rate of 50 m3/min. Therefore, the faster gas injection rate, the smaller diameter of cuttings, the faster rotating speed and the smaller eccentric distance, the further would cuttings be removed. Taking measures such as improving gas injection rate appropriately, installing a hole cleaning device for horizontal well and moderating drilling pipe could benefit the hole cleaning efficiently.
-
-
[1] 贾承造,郑民,张永峰.中国非常规油气资源与勘探开发前景[J].石油勘探与开发,2012,39(2):129-136. Jia Chengzao,Zheng Min,Zhang Yongfeng.Unconventional hydrocarbon resources in China and the prospect of exploration and development[J].Petroleum Exploration and Development,2012,39(2):129-136. [2] 唐波,唐志军,耿应春,等.国内低渗透油气田高效开发钻完井关键技术发展现状[J].天然气工业,2013,33(2):65-70. Tang Bo,Tang Zhijun,Geng Yingchun,et al.Drilling and completion technologies for efficient exploitation of low-permeability oil gas fields in China:a state-of-the-art review[J].Natural Gas Industry,2013,33(2):65-70. [3] 武恒志.低渗油气田高效开发钻井技术研究与实践[J].石油钻探技术,2012,40(3):1-6. Wu Hengzhi.Drilling technology for highly efficient development of low permeability oil gas fields[J].Petroleum Drilling Techniques,2012,40(3):1-6. [4] 孟英峰,练章华,李永杰,等.气体钻水平井的携岩研究及在白浅111H井的应用[J].天然气工业,2005,25(8):50-53. Meng Yingfeng,Lian Zhanghua,Li Yongjie,et al.Research on the cuttings-carried ability in gas horizontal drilling and its application to Well Baiqian-111H[J].Natural Gas Industry,2005,25(8):50-53. [5] 孙海芳,谯抗逆,胡超,等.广安 002-H8 井气体钻水平井实践[J].天然气工业,2008,28(4):61-63. Sun Haifang,Qiao Kangni,Hu Chao,et al.Gas drilling practices in the horizontal Well Guang’an 002-H8[J].Natural Gas Industry,2008,28(4):61-63. [6] 石建刚,陈一健,谢双喜.气体钻井井眼净化程度判断方法探讨[J].石油钻采工艺,2008,30(4):5-7. Shi Jiangang,Chen Yijian,Xie Shuangxi.Discussion on methods for determining hole cleaning degree in gas drilling[J].Oil Drilling Production Technology,2008,30(4):5-7. [7] 陈锋,狄勤丰,袁鹏斌,等.高效岩屑床清除钻杆作用机理[J].石油学报,2012,33(2):298-303. Chen Feng,Di Qinfeng,Yuan Pengbin,et al.Mechanism of an effective hydroclean drill pipe for hole cleaning[J].Acta Petrolei Sinica,2012,33(2):298-303. [8] Angel R R.Volume requirements for air or gas drilling[J].Transactions of the American Institute of Mining and Metallurgical Engineers,1957,210(12):325-330.
[9] Guo B,Ghalambor A.Gas volume requirements for underbalanced drilling:deviated holes[M].Tulsa:PennWell Books,2002.
[10] 王岩,韩辉,闫铁,等.气体钻井水平井注气量模型修正[J].大庆石油学院学报,2009,33(3):69-71,74. Wang Yan,Han Hui,Yan Tie,et al.Modification of gas injection model for horizontal wells during gas drilling[J].Journal of Daqing Petroleum Institute,2009,33(3):69-71,74. [11] 袁兆广,周开吉,孟英峰,等.气体钻大斜度水平井最小注气量计算方法研究[J].天然气工业,2007,27(4):65-68. Yuan Zhaoguang,Zhou Kaiji,Meng Yingfeng,et al.Calculating the minimum gas volume used in high-angle horizontal wells during gas drilling[J].Natural Gas Industry,2007,27(4):65-68. [12] 张雅春,刘强,向军文,等.空气定向钻井设计计算方法[J].吉林大学学报:地球科学版,2009,39(2):294-299. Zhang Yachun,Liu Qiang,Xiang Junwen,et al.Design calculations for air directional drilling[J].Journal of Jilin University:Earth Science Edition,2009,39(2):294-299. [13] 柳贡慧,宋廷远,李军.气体钻水平井气体携岩能力分析[J].石油钻探技术,2009,37(5):26-29. Liu Gonghui,Song Tingyuan,Li Jun.Analysis of cuttings transportation during drilling gas horizontal wells[J].Petroleum Drilling Techniques,2009,37(5):26-29. [14] 孟英峰,练章华,梁红,等.气体钻水平井的携岩CFD数值模拟研究[J].天然气工业,2005,25(7):50-52. Meng Yingfeng,Lian Zhanghua,Liang Hong,et al.CFD numerical simulation research on cuttings-carried capability in gas horizontal drilling[J].Natural Gas Industry,2005,25(7):50-52. [15] 万里平,孟英峰,魏纳,等.气体钻水平井井径扩大环空流动特征的数值模拟[J].应用力学学报,2011,28(5):543-546. Wan Liping,Meng Yingfeng,Wei Na,et al.Numerical simulation on the annulus diameter expansion in gas drilling horizontal well[J].Chinese Journal of Applied Mechanics,2011,28(5):543-546. [16] 沈忠厚,王海柱,李根生.超临界CO2钻井水平井段携岩能力数值模拟[J].石油勘探与开发,2011,38(2):233-236. Shen Zhonghou,Wang Haizhu,Li Gensheng.Numerical simulation of the cutting-carrying ability of supercritical carbon dioxide drilling at horizontal section[J].Petroleum Exploration and Development,2011,38(2):233-236. [17] 霍洪俊,王瑞和,倪红坚,等.超临界二氧化碳在水平井钻井中的携岩规律研究[J].石油钻探技术,2014,42(2):12-17. Huo Hongjun,Wang Ruihe,Ni Hongjian,et al.Cuttings carrying pattern of supercritical carbon dioxide in horizontal wells[J].Petroleum Drilling Techniques,2014,42(2):12-17. [18] 宋先知,李根生,王梦抒,等.连续油管钻水平井岩屑运移规律数值模拟[J].石油钻探技术,2014,42(2):28-32. Song Xianzhi,Li Gensheng,Wang Mengshu,et al.Numerical simulation on cuttings carrying regularity for horizontal wells drilled with coiled tubing[J].Petroleum Drilling Techniques,2014,42(2):28-32. [19] 邵帅,孟庆双,孙晓峰,等.非直井气体钻井岩屑起动的临界流速[J].断块油气田,2013,20(6):803-805. Shao Shuai, Meng Qingshuang, Sun Xiaofeng, et al.Starting velocity of cutting particles in gas drilling of horizontal or highly deviated well[J].Fault-Block Oil Gas Field,2013,20(6):803-805. [20] 韩春雨,龙刚,纪海鹏.气体钻井岩屑颗粒动力学分析[J].重庆科技学院学报:自然科学版,2008,10(6):31-33,39. Han Chunyu,Long Gang,Ji Haipeng.Dynamics analysis of cutting on gas drilling[J].Journal of Chongqing University of Science and Technology:Natural Sciences Edition,2008,10(6):31-33,39. [21] 郭建华.气体钻井环空气固两相流动数值模拟研究[D].成都:西南石油大学,2006. Guo Jianhua.Numerical simulation of gas-liquid two-phase flow in annulus during gas drilling[D].Chengdu:Southwest Petroleum University,2006. [22] 李皋,李诚,孟英峰,等.一种水平段气体钻井用井眼净化工具:中国,201410029002.3[P].2014-05-07. Li Gao,Li Cheng,Meng Yingfeng,et al.A hole cleaning tool for gas drilling horizontal wells:CN,201410029002.3[P].2014-05-07. -
