地质导向中二维储层界面预测方法研究

王谦; 李国利; 李震; 苏波; 洪英霖

doi:10.11911/syztjs.201503017

地质导向中二维储层界面预测方法研究

1.
中国石油测井有限公司, 陕西西安 710077;
2.
中国石油塔里木油田分公司, 新疆库尔勒 841000

基金项目:

国家科技重大专项"复杂储层油气测井解释理论方法与处理技术"(编号:2011ZX05020-008)部分研究内容.

详细信息

作者简介:
王谦(1982—),男,山西大同人,2007年毕业于中国石油大学(华东)应用物理学专业,2010年获中国石油大学(华东)物理学硕士学位,工程师,现主要从事测井资料解释评价与随钻地质导向工作.

中图分类号: P631.8
计量
- 文章访问数: 4133
- HTML全文浏览量: 62
- PDF下载量: 4297
出版历程
- 收稿日期: 2014-11-14
- 修回日期: 2015-05-11
- 刊出日期: 1899-12-31

A Method to Predict 2D Reservoir Interfaces in Geosteering

1.
CNPC Logging Co., Ltd., Xi’an, Shaanxi, 710077, China;
2.
PetroChina Tarim Oilfield Company, Korla, Xinjiang, 841000, China

摘要

摘要: 目前常用的钻前地质导向模型建立在地震资料精细处理的基础上,分辨率较低,需要建立一种新的储层界面预测方法.以测井资料为基础,建立了地层视倾角的计算方法,通过平移、创建虚拟井等方式确定水平井钻进方向上的地层边界信息,构建地层边界模型,推导了地层边界的数学关系.应用地层视倾角预测模型和不同井位分布下的地层边界数学模型进行了现场预测,结果表明,目的层视倾角为0.70°,完井计算地层视倾角为0.53°,误差较小;储层边界预测结果与实测结果误差为0.1~3.6 m,预测结果受地层变化情况的影响较大.研究表明,地层边界深度是水平位移的函数,下倾地层边界深度与水平位移呈线性正相关,与建模井的井距呈线性反相关,而上倾地层变化规律与之相反;对于地层厚度逐渐变化的地层,数学建模预测结果比视厚度预测结果更为准确.研究结果为水平井地质导向提供了一种直观量化的指导方法.
- 地质导向 /
- 倾角 /
- 储层界面 /
- 水平井 /
- 测井资料
Abstract: Current pre-drilling geosteering models are often built through fine seismic data processing, with low resolution. So, it is necessary to develop a high accuracy method to predict a reservoir interface. Based on logging data, a calculation method of apparent formation dip was proposed. A reservoir boundary model was constructed and the mathematical relationship of reservoir boundary was deduced by means of translation and virtual wells to determine the reservoir information on horizontal well direction. The prediction model of apparent formation dip and the mathematical model of reservoir boundary under different location distributions have been used in oil fields. The results showed that the apparent formation dip of target stratum predicted on site was 0.70°, and the apparent formation dip calculated upon well completion was 0.53°, indicating a minor error. The predicted result with the mathematical model of reservoir boundary had an error of 0.1-3.6 m with the measured result, which was significantly affected by formation changes. The research suggested that the depth of formation boundary was a function of horizontal displacement. For the downdip formation, there was a linear positive correlation between the boundary depth and the horizontal displacement. Further, there was a linear negative correlation between the boundary depth and the distance from modeled well. For the updip formation, the changes were opposite. For the formation in which thickness changed gradually, the mathematical model provided more accurate prediction results than the apparent thickness method. The reservoir interface prediction results could provide direct and quantitative guidance for horizontal well geosteering.
- geosteering /
- dip /
- reservoir interface /
- horizontal well /
- logging data

HTML全文

参考文献(17)

[1]	苏义脑.地质导向钻井技术概况及其在我国的研究进展[J].石油勘探与开发,2005,32(1):92-95. Su Yinao.Geosteering drilling technology and its development in China[J].Petroleum Exploration and Development,2005,32(1):92-95.
[2]	张辛耘,王敬农,郭彦军.随钻测井技术进展和发展趋势[J].测井技术,2006,30(1):10-15. Zhang Xinyun,Wang Jingnong,Guo Yanjun.Advances and trends in logging while drilling technology[J].Well Logging Technology,2006,30(1):10-15.
[3]	秦绪英,肖立志,索佰峰.随钻测井技术最新进展及其应用[J].勘探地球物理进展,2003,26(4):313-322. Qin Xuying,Xiao Lizhi,Suo Baifeng.The development of logging-while-drilling and its application[J].Progress in Exploration Geophysics,2003,26(4):313-322.
[4]	向长生,王智锋,亢武臣.随钻自然伽马地层边界模型分析[J].石油钻采工艺,2013,35(1):112-114. Xiang Changsheng,Wang Zhifeng,Kang Wuchen.Modeling and analysis of formation boundaries based on LWD natural gamma[J].Oil Drilling Production Technology,2013,35(1):112-114.
[5]	亢武臣,林楠,聂同建.地质导向矢量角及在地层边界探测中的作用[J].录井工程,2013,24(2):41-43,57. Kang Wuchen,Lin Nan,Nie Tongjian.Geosteering vectorial angle and its role in detecting formation boundary[J].Mud Logging Engineering,2013,24(2):41-43,57.
[6]	史晓锋.水平井中随钻电阻率测量仪定位和预测地层界面的方法[J].测井技术,2006,30(2):119-121. Shi Xiaofeng.Methods for orientation of formation layerings and formation boundary prediction with LWD resistivity logs in HZ wells[J].Well Logging Technology,2006,30(2):119-121.
[7]	卢志远.水平井储层界面预测方法研究[D].东营:中国石油大学(华东)地球资源与信息学院,2009. Lu Zhiyuan.Research on prediction of reservoir interface in horizontal well[D].Dongying:China University of Petroleum(Huadong),College of Geo-Resources and Information,2009.
[8]	郝以岭,杜志强.OnTrak随钻测井资料在冀东油田地质导向中的应用[J].测井技术,2009,33(2):148-152,156. Hao Yiling,Du Zhiqiang.Application of geosteering service based on OnTrak MWD/LWD platform in Jidong Oilfield[J].Well Logging Technology,2009,33(2):148-152,156.
[9]	吴意明,熊书权,李楚吟,等.探边工具AziTrak在开发井地质导向中的应用[J].测井技术,2013,37(5):547-551. Wu Yiming,Xiong Shuquan,Li Chuyin,et al.Application of AziTrak tool to geosteering of horizontal well development[J]. Well Logging Technology,2013,37(5):547-551.
[10]	刘维永,周晶,赵春明.储层边界识别技术在渤海海域油田水平井高效开发中的应用[J].石油地质与工程,2011,25(1):63-66,144. Liu Weiyong,Zhou Jing,Zhao Chunming.The application of reservior boundary identification in highly efficient development of horizontal wells in Bohai Oilfield[J].Petroleum Geology and Engineering,2011,25(1):63-66,144.
[11]	冯凯,查朝阳,钟德盈.反演技术和频谱成像技术在储层预测中的综合应用[J].石油物探,2006,45(3):262-266. Feng Kai,Zha Chaoyang,Zhong Deying.Integrated application between inversion and spectral image technology in the reservoir prediction[J].Geophysical Prospecting for Petroleum,2006,45(3):262-266.
[12]	印兴耀,叶端南,张广智.基于核空间的模糊聚类方法在储层预测中的应用[J].中国石油大学学报:自然科学版,2012,36(1):53-59. Yin Xingyao,Ye Duannan,Zhang Guangzhi.Application of kernel fuzzy C-means method to reservoir prediction[J].Journal of China University of Petroleum:Edition of Natural Science,2012,36(1):53-59.
[13]	周明晖.储层地质模型的建立及动态实时跟踪研究[D].东营:中国石油大学(华东)地球资源与信息学院,2009. Zhou Minghui.Study on reservoir geologic modeling and dynamic real-time tracking[D].Dongying:China University of Petroleum(Huadong),College of Gro-Resources and Information,2009.
[14]	秦宗超,刘迎贵,邢维奇,等.水平井地质导向技术在复杂河流相油田中的应用:以曹妃甸11-1油田为例[J].石油勘探与开发,2006,33(3):378-382. Qin Zongchao,Liu Yinggui,Xing Weiqi,et al.Application of geo-steering technique of horizontal well in complex fluvial reservoir:a case from Caofeidian Oilfield[J].Petroleum Exploration and Development,2006,33(3):378-382.
[15]	吴则鑫.水平井地质导向技术在苏里格气田苏53区块的应用[J].天然气地球科学,2013,24(4):859-863. Wu Zexin.Application of geologic steering technique of horizontal well in complex thin layer and low permeability gas reservoir:a case from a district in Sulige Gas Field[J].Natural Gas Geoscience,2013,24(4):859-863.
[16]	刘岩松,衡万富,刘斌,等.水平井地质导向方法[J].石油钻采工艺,2007,29(增刊1):4-6. Liu Yansong,Heng Wanfu,Liu Bin,et al.Discussion on geosteering methods of horizontal wells[J].Oil Drilling Production Technology,2007,29(supplement 1):4-6.
[17]	夏宏泉,陈平,石晓兵,等.水平井钻头上下倾钻进方向及位置的实时确定[J].西南石油学院学报,2003,25(4):22-26. Xia Hongquan,Chen Ping,Shi Xiaobing,et al.Method to real-time determine the bit up-down drilling direction and the position in target oil-gas formation[J].Journal of Southwest Petroleum Institute,2003,25(4):22-26.
