The Technology of Classified Combination of Deep Profile Control in the Bohai Oilfield
-
摘要: 为了提高海上油田的开发效果,基于调剖决策的压力指数计算、调剖体系优选室内试验及调剖参数设计,进行了分级组合深部调剖技术研究.室内试验表明,采取先低强度(终冻强度0.05 MPa)后高强度(终冻强度0.07 MPa)连续相的顺序注入,比采取先高强度后低强度连续相的顺序注入时的采收率提高3.1百分点;采取先大粒径(初始粒径0.5~3.0 μm)分散相、后小粒径(初始粒径50~500 nm)分散相的顺序注入,比采取先小粒径分散相、后大粒径分散相的顺序注入时的采收率提高4.1百分点.膨胀后分散相颗粒与地层孔喉的最佳直径比为1时封堵率最高,且要求初始颗粒粒径小于1/7倍孔喉直径,膨胀后的最小粒径大于1/3倍孔喉直径.结合渤海油田的现场实例对该技术的应用效果进行分析,预测进行分级组合深部调剖后,含水率下降5.0%,2个井组增油3.4×104 m3以上.研究结果表明,在应用区块整体调剖决策参数确定目标调剖井的基础上,根据地层物性优选出合适的调剖体系,并对调剖体系进行优化组合设计,可以达到最佳的调剖效果.Abstract: Based on calculation of the pressure index for profile control decision-making, laboratory experiments for selecting profile control agents, and design of profile control parameters, the particle grading combination for deep profile control technology was studied. Laboratory experiments showed that injection of high-intensity(final frozen strength 0.07 MPa)profile control agent in continuous phase after injection of low-intensity(final frozen strength 0.05 MPa)agents provided a recovery efficiency 3.1% higher than that by reverse injection sequence, and injection of profile control agent with small particle size(initial particle size 0.5-3.0 μm)in dispersed phase after that with large particle size(initial particle size 50-500 nm)contributed a recovery efficiency 4.1% higher than that by reverse injection sequence. Highest plugging rate was obtained when the ratio of dispersed phase particle size after expansion to the size of pore throat inside formation was 1, and it was required that initial particle size was less than 1/7 of pore throat diameter, and minimum size of particles after expansion greater than 1/3 of pore throat diameter. The application of the technique in the Bohai Oilfield was analyzed, water cut declined by 5.0% and oil increased 3.4×104 m3 in two clusters of wells through particle size grading and combination for controlling deep profile. The research results showed that, if the target well is determined using the parameters for overall profile control, appropriate profile control agent is selected according to the reservoir property, optimized combination of profile control system is conducted, the best effect of profile control can be achieved.
-
-
[1] 张光焰,荆波,李瞬灵,等.埕岛油田馆陶组油藏调剖技术初探[J].中国海上油气,2007,19(2):116-118. Zhang Guangyan,Jing Bo,Li Shunling,et al.A preliminary discussion on profile control technology for Guantao Formation reservoir in Chengdao Oilfield[J].China Offshore Oil and Gas,2007,19(2):116-118. [2] 何风华,刘德正,樊玉生,等.高膨微粒调剖工艺先导性试验与效果评价[J].石油钻采工艺,2013,35(5):107-110. He Fenghua,Liu Dezheng,Fan Yusheng,et al.Pilot test and effect evaluation of high-swelling particles profile control process[J].Oil Drilling Production Technology,2013,35(5):107-110. [3] 孔柏岭,刘文华,皇海权,等.聚合物驱前区块整体调剖技术的矿场应用[J].大庆石油地质与开发,2010,29(1):105-109. Kong Bailing,Liu Wenhua,Huang Haiquan,et al.Field application of block-wide overall profile controlling technique before polymer flooding[J].Petroleum Geology Oilfield Development in Daqing,2010,29(1):105-109. [4] 陈渊,孙玉青,温栋良,等.聚合物纳米微球调驱性能室内评价及现场试验[J].石油钻探技术,2012,40(4):102-106. Chen Yuan,Sun Yuqing,Wen Dongliang,et al.Evaluation and application on profile control of polymer nano-microspheres[J].Petroleum Drilling Techniques,2012,40(4):102-106. [5] 杨文军,赵光,刘奎,等.耐温耐盐深部调剖体系研究[J].断块油气田,2011,18(2):257-260. Yang Wenjun,Zhao Guang,Liu Kui,et al.Experimental study on deep thermophilic and halotolerant profile control agents[J].Fault-Block Oil Gas Field,2011,18(2):257-260. [6] 田鑫,任芳祥,韩树柏,等.可动微凝胶调剖体系室内评价[J].断块油气田,2011,18(1):126-129. Tian Xin,Ren Fangxiang,Han Shubai,et al.Laboratory evaluation of profile control system for soft micro-gel[J].Fault-Block Oil Gas Field,2011,18(1):126-129. [7] 贾晓飞,雷光伦,尹金焕,等.孔喉尺度弹性调驱微球与储层匹配关系理论研究[J].石油钻探技术,2011,39(4):87-89. Jia Xiaofei,Lei Guanglun,Yin Jinhuan,et al.The relationship between pore-scale elastic microsphere and formation matching[J].Petroleum Drilling Techniques,2011,39(4):87-89. [8] 伍嘉,蒲万芬,董钟骏,等.新型微凝胶深部调驱体系研究进展[J].石油钻探技术,2012,40(3):107-111. Wu Jia,Pu Wanfen,Dong Zhongjun,et al.Advances of the new deep oil displacement and profile control agent micro-gel[J].Petroleum Drilling Techniques,2012,40(3):107-111. [9] 郭太现,苏彦春.渤海油田稠油油藏开发现状和技术发展方向[J].中国海上油气,2013,25(4):26-30. Guo Taixian,Su Yanchun.Current status and technical development direction in heavy oil reservoir development in Bohai Oilfield[J].China Offshore Oil and Gas,2013,25(4):26-30. [10] 赵晓非,于庆龙,晏凤,等.有机铬弱凝胶深部调剖体系的研究及性能评价[J].特种油气藏,2013,20(3):114-117. Zhao Xiaofei,Yu Qinglong,Yan Feng,et al.Organic chromium of weak gel deep profile control system research and its performance evaluation[J].Special Oil Gas Reservoirs,2013,20(3):114-117. [11] 雷光伦,陈月明,李爱芬.聚合物驱深度调剖技术研究[J].油气地质与采收率,2001,8(3):54-57. Lei Guanglun,Chen Yueming,Li Aifen.Research of depth profile control technology in polymer flooding[J].Petroleum Geology and Recovery Efficiency,2001,8(3):54-57. [12] 由庆,于海洋,王业飞,等.国内油田深部调剖技术的研究进展[J].断块油气田,2009,16(4):68-71. You Qing,Yu Haiyang,Wang Yefei,et al.Technologies of in-depth profile control in China[J].Fault-Block Oil Gas Field,2009,16(4):68-71. [13] 赵福麟,周洪涛,林伟民,等.注水井井口压降曲线在粘土调剖中的应用[J].石油钻采工艺,1994,16(2):73-76. Zhao Fulin,Zhou Hongtao,Lin Weimin,et al.Applications of surface pressure drawdown curves of injection wells in profile modification using clay[J].Oil Drilling Production Technology,1994,16(2):73-76. [14] Abrams A.Mud design to minimize rock impairment due to particle invasion[J].JPT,1977,29(3):586-593.
[15] 赵福麟.压力指数决策技术及其应用进展[J].中国石油大学学报:自然科学版,2011,35(1):82-88. Zhao Fulin.Pressure index decision-making technique and its application progresses[J].Journal of China University of Petroleum:Edition of Natural Science,2011,35(1):82-88. -
