New Technology for Stuck Drill Pipe Using Mud Loss-Proof Emulsified Acid Implemented in a Ultra-Deep Horizontal Well in the Yuanba Gas Field
-
摘要: 元坝气田水平井在钻进长兴组地层时常发生卡钻事故,采用常规泡酸易井漏且无法解卡.为解决该问题,在深入分析卡钻原因的基础上,研究了超深水平井防漏型乳化酸解卡技术.其基本思路是:利用乳化酸的缓速原理使酸液返至卡点位置,配合使用惰性堵漏材料来减缓形成漏失通道后的漏失速度,增长酸液与基岩的反应时间从而达到解卡的目的.通过室内试验形成了一套防漏型乳化酸配方,试验表明,该乳化酸与长兴组岩屑以及滤饼的酸溶率能分别达到50%和40%;酸液中的堵漏材料能有效提高封堵效果,封堵率达到99%;同时,乳化酸具有较好的缓速酸性能,破乳温度可达到140 ℃.该乳化酸在YB205-1井长兴组地层压差卡钻中进行了试用,成功解决了卡钻问题.研究表明,防漏型乳化酸能解决高渗碳酸盐岩超深水平井中的压差卡钻问题.Abstract: Stuck drill pipe during the drilling of horizontal wells has become a common problem in the Changxing Formation of the Yuanba Gas Field. Conventional foamed acids are prone to lost circulation and cannot eliminate the risk of stuck drillpipe. In order to solve the problem of stuck drillpipes during horizontal drilling, a new technology using mud loss-proof emulsified acid was tried in an ultra-deep horizontal well after being developed by means of an in-depth analysis of the cause. For the basic stuck drillpipe freeing principle, it is important to recognize that acid fluids can return to stuck point by retarding of emulsified acids and inert circulation lost materials can be used to reduce mud loss rate so as to increase time of reaction between acid fluids and base rock to release stuck drillpipe. A mud loss-proof emulsified acid formula has been developed through laboratory tests. Test results show that the emulsified acid can achieve an acid solubility of 50% in cuttings and 40% in mud cakes of the Changxing Formation;circulation lost materials of acid fluid system can effectively improve plugging effects with a plugging ratio up to 99%. Further, the emulsified acid system achieved good retarded acid performance and its demulsification temperature can be as high as 140degrees. The emulsified acid has been successfully used in drillpipe stuck due to differential pressure in the Changxing Formation in Well YB205-1. According to research results, mud loss-proof emulsified acid can solve differential pressure which causes drillpipe to get stuck in ultra-deep horizontal wells in highly permeable carbonate rocks.
-
-
[1] 张金成,张东清,张新军,等.元坝地区超深井钻井提速难点与技术对策[J].石油钻探技术,2011,39(6):6-10. Zhang Jincheng,Zhang Dongqing,Zhang Xinjun,et al.Difficulties of improving rate of penetration and its technical solutions in Yuanba Area[J].Petroleum Drilling Techniques,2011,39(6):6-10. [2] 葛鹏飞,马庆涛,张栋.元坝地区超深井井身结构优化及应用[J].石油钻探技术,2013,41(4):83-86. Ge Pengfei,Ma Qingtao,Zhang Dong.Optimization and application of ultra-deep well casing program in Yuanba Area[J].Petroleum Drilling Techniques,2013,41(4):83-86. [3] 高红贤,冯明刚,王建波,等.元坝气田长兴组气藏含水饱和度计算[J].断块油气田,2014,21(3):348-351. Gao Hongxian,Feng Minggang,Wang Jianbo,et al.Calculation on water saturation of Changxing Formation reservoir in Yuanba Gas Field[J].Fault-Block Oil Gas Field,2014,21(3):348-351. [4] 蒲洪江,张林海,侯跃全,等.元坝气田大尺寸非标准尾管固井技术[J].石油钻探技术,2014,42(4):64-68. Pu Hongjiang,Zhang Linhai,Hou Yuequan,et al.Large size nonstandard liner cementing technique in Yuanba Gas Field[J].Petroleum Drilling Techniques,2014,42(4):64-68. [5] 王庆波,刘若冰,魏祥峰,等.陆相页岩气成藏地质条件及富集高产主控因素分析:以元坝地区为例[J].断块油气田,2013,20(6):698-703. Wang Qingbo,Liu Ruobing,Wei Xiangfeng,et al.Geologic condition of shale gas accumulation in continental facies and main controlling factors of enrichment and high production:taking Yuanba District as an example[J].Fault-Block Oil and Gas Field,2013,20(6):698-703. [6] 瞿佳,严思明,许建华.胶乳防腐水泥浆在元坝地区的应用[J].石油钻探技术,2013,41(3):94-98. Qu Jia,Yan Siming,Xu Jianhua.Application of corrosion resistant latex cement slurry in Yuanba Area[J].Petroleum Drilling Techniques,2013,41(3):94-98. [7] 闫光庆,刘匡晓,郭瑞昌,等.元坝272H井超深硬地层侧钻技术[J].石油钻探技术,2013,41(1):113-117. Yan Guangqing,Liu Kuangxiao,Guo Ruichang,et al.Ultra-deep sidetracking in Well Yuanba 272H[J].Petroleum Drilling Techniques,2013,41(1):113-117. [8] 张坤,李明华,万永生,等.有效解除水平井段压差卡钻技术:在磨溪地区钻井中的应用[J].天然气工业,2007,27(7):56-58. Zhang Kun,Li Minghua,Wan Yongsheng,et al.Techniques used to remove pressure sticking in horizontal wells and its actual application in Moxi Gas Field[J].Natural Gas Industry,2007,27(7):56-58. [9] 刘炜,陶高杰,张斌,等.新型抗高温乳化酸的研制及性能评价[J].精细石油化工进展,2012,13(7):8-10. Liu Wei,Tao Gaojie,Zhang Bin,et al.Development and evaluation of new emulsified acid with high temperature-resistance[J].Advances in Fine Petrochemicals,2012,13(7):8-10. [10] 刘德胜,胡欣峰,王文勇,等.酸化解卡方法解除伊朗TBK-8井卡钻事故[J].钻井液与完井液,2006,23(6):77-78. Liu Desheng,Hu Xinfeng,Wang Wenyong,et al.Acidification backing off technology in Iron TBK-8 Well[J].Drilling Fluid Completion Fluid,2006,23(6):77-78. [11] 戴建全.裂缝性碳酸盐岩地层解卡酸液体系研究与应用[J].石油钻采工艺,2010,32(增刊1):146-148. Dai Jianquan.Application and research on unfreezing acid system for fractured carbonate formation[J].Oil Drilling Production Technology,2010,32(supplement 1):146-148. [12] 侯士东,张雅欣,张长春,等.H203H井传输测井复杂卡钻处理[J].石油钻采工艺,2010,32(5):110-112. Hou Shidong,Zhang Yaxin,Zhang Changchun,et al.Complex sticking treatment in logging transfer of Well H203H[J].Oil Drilling Production Technology,2010,32(5):110-112. -
