Application and Research on Methods for 3D Space Rock Drillability Prediction
-
摘要: 在已钻井资料较少的情况下，合理、高效、低成本地预测岩石可钻性在地层空间的分布对钻井工作十分重要。分析了单一测井、录井及地震资料预测方法的不足，提出了预测三维空间岩石可钻性的新方法，即利用测井约束地震反演技术对三维地震数据进行反演，生成全频带高分辨率的岩石纵波速度体，通过室内微钻头岩心可钻性试验，建立了考虑岩石声波时差与密度属性的可钻性预测模型，并据此开发了三维岩石可钻性预测软件。在吐哈盆地某区块两口井进行的实例分析表明，可钻性平均误差约10%，研究区块牙轮钻头对应的岩石可钻性级值约2.8~6.3，PDC钻头对应的岩石可钻性级值约2.0~5.0；软件三维显示结果表明，局部地层存在异常高可钻性级值带，与钻井资料显示该地层存在砾岩层结论相符。该区块PDC钻头的三维空间地层岩石可钻性整体优于牙轮钻头对应的可钻性。研究表明：建立的岩石可钻性预测模型同时考虑了岩石声波与密度属性，能合理预测岩石可钻性，反映不同类型钻头的可钻性差异；新方法能较真实地反映出岩石可钻性的三维空间分布情况，可为制定钻井提速方案提供参考。Abstract: In the initial stages of exploration,when drilling data is scarce,it’s particularly important to predict the drillability of the target formation in a proper,efficient and low-cost manner.In this paper,common drillability prediction methods using logging,mud logging and seismic data were evaluated and determined to be inadequate.So,to meet the need for effective predicability of formation drillability,a new 3D prediction method was presented,in which a model considering both rock acoustic and density properties was constructed by combining the micro-bit drillability test and full-band and high-resolution P wave velocity cube which was generated by awell log-constrained seismic inversion technique.Prediction software was developed to create a 3D visualization of the distribution of drillability.Case studies of two wells in one block of the Tuha Basin was presented.The average error of drillability was about 10%,and drillability grade of a roller bit was 2.8-6.3 while drillability grade of a PDC bit is 2.0-5.0.The 3D visualization result indicated that an abnormally high drillability area existed in the local formation,which was in accordance with the existence of conglomerate layer shown in drilling record.The overall drillability performance of PDC bits was superior to that of the roller bits.The results showed that the model considering both rock acoustic and density properties could predict rock drillability reasonably and reveal drillability differences for different bits.The method proposed could describe the spatial distribution of rock drillability in an objective manner,providing references to speeding up drilling.
-
Keywords:
- rock drillability /
- prediction /
- core test /
- well logging /
- seismic data
-
-
[1] 尹宏锦.地层宏观可钻性与实用原理[J].石油大学学报:自然科学版,1988,12(3):277-286. Yin Hongjin.Formation macro-drillability and the principle of its application[J].Journal of the University of Petroleum,China:Edition of Natural Science,1988,12(3):277-286. [2] Pennebaker E S.An engineering interpretation of seismic data[R].SPE 2165,1968.
[3] 刘明轶.利用声波测井数据分析地层可钻性[J].内蒙古石油化工,2012,38(24):56-57. Liu Mingyi.Analysis of formation driuability using acoustic data[J].Inner Mongolia Petrochemical Industry,2012,38(24):56-57. [4] 张亚旭,高小燕.基于测井资料的岩石可钻性研究[J].信息系统工程,2011(9):97-98. Zhang Yaxu,Gao Xiaoyan.Study of rock drilability based on well logging data[J].China CIO News,2011(9):97-98. [5] 田军,陈德光,王志忠,等.利用测井资料预测地层岩石可钻性[J].石油钻采工艺,1994,16(3):1-4,20. Tian Jun,Chen Deguang,Wang Zhizhong,et al.Predicing rock drillability by logging data[J].Oil Drilling Production Technology,1994,16(3):1-4,20. [6] 梁启明,邹德永,张华卫,等.利用测井资料综合预测岩石可钻性的试验研究[J].石油钻探技术,2006,34(1):17-19. Liang Qiming,Zou Deyong,Zhang Huawei,et al.Predicting rock drillability by well logging:an experimental research[J].Petroleum Drilling Techniques,2006,34(1):17-19. [7] 路保平,张传进,鲍洪志.利用多测井参数求取岩石可钻性[J].石油钻探技术,1998,26(3):4-6. Lu Baoping,Zhang Chuanjin,Bao Hongzhi.Achieving rock drillability with multi-logging parameters[J].Petroleum Drilling Techniques,1998,26(3):4-6. [8] 李祖奎,李春城,袁永嵩,等.利用声波测井资料预测地层可钻性及钻速的试验研究[J].焦作工学院学报,1999,18(3):178-181. Li Zukui,Li Chuncheng,Yuan Yongsong,et al.An experimental study on the prediction of formation drillability and rate of penetration by sonic log data[J].Journal of Jiaozuo Institute of Technology,1999,18(3):178-181. [9] 詹俊峰,高德利,刘希圣.地层抗钻强度与钻头磨损实用评估方法[J].石油钻采工艺,1997,19(6):16-23. Zhan Junfeng,Gao Deli,Liu Xisheng.An applicable method for estimation of formation drilling strength and bit wear[J].Oil Drilling Production Technology,1997,19(6):16-23. [10] 董振国,刘玉华,张伯文.新疆麦盖提地区岩石可钻性分析及应用[J].石油钻探技术,1997,25(4):1-2. Dong Zhenguo,Liu Yuhua,Zhang Bowen.Rock drillability analysis and applications at Maigaiti Area in Xinjiang[J].Petroleum Drilling Techniques,1997,25(4):1-2. [11] 范翔宇,夏宏泉,郑雷清,等.利用地震层速度预测地层可钻性和钻速的新方法[J].钻采工艺,2007,30(1):4-6. Fan Xiangyu,Xia Hongquan,Zheng Leiqing,et al.New method of using seismic velocity to predict layer drillability and drilling rate[J].Drilling Production Technology,2007,30(1):4-6. [12] 张志杰,单清林,周雪,等.砾岩层可钻性研究[J].断块油气田,2013,20(4):502-504. Zhang Zhijie,Shan Qinglin,Zhou Xue,et al.Research on drillability in conglomerate formation[J].Fault-Block Oil Gas Field,2013,20(4):502-504. [13] 安鸿伟,李正文,李仁甫,等.稀疏脉冲波阻抗反演在YX油田开发中的应用[J].石油物探,2002,41(1):56-60. An Hongwei,Li Zhengwen,Li Renfu,et al.Application of sparse impulse impedance inversion in YX Oilfield[J].Geophysical Prospecting for Petroleum,2002,41(1):56-60. [14] 赵军,蔡亚西,林元华.声波测井资料在岩石可钻性及钻头选型中的应用[J].测井技术,2001,25(4):305-307. Zhao Jun,Cai Yaxi,Lin Yuanhua.Application of sonic logs to rock drillability and bit selection[J].Well Logging Technology,2001,25(4):305-307. [15] 王忠福,孟金城,张志邦.声波时差测井在岩石可钻性预测中的应用[J].大庆石油地质与开发,2006,25(3):94-96. Wang Zhongfu,Meng Jincheng,Zhang Zhibang.Application of acoustic travel time logging in rock drillability prediction[J].Petroleum Geology Oilfield Development in Daqing,2006,25(3):94-96.
