Key Technology on Ball-Activated Sleeve for Open Hole Staged Fracturing
-
摘要: 投球式滑套为裸眼分段压裂管柱中建立压裂级数和压裂过流通道的关键部件，但目前国内尚未开展滑套球座与其匹配的憋压球的密封能力、滑套球座的可钻性与耐冲蚀性方面的研究。通过滑套球座的结构设计、憋压球的材料优选及球座与憋压球密封能力的有限元分析与试验，研究了滑套球座与憋压球之间的密封技术；通过滑套球座材料优选和相关试验，研究了滑套球座的可钻性；通过滑套球座表面硬化处理探讨及冲蚀和密封试验，研究了其耐冲蚀性能。8井次共72段的现场试验表明，滑套设计合理，性能可靠，解决了投球式滑套高承压密封及完井管柱的全通径问题。Abstract: Ball-activated sleeve plays an important role in open hole staged fracturing,which may determine number of fracturing stages and flow channels.However,studies have not been initiated in China on sealability between ball and ball seat,drillability and erosion resistance of ball seat.In this paper,finite element analysis and experiment were conducted in respect to structural design of ball seat,selection of ball materials,and sealability between ball and ball seat,so as to find appropriate sealing techniques.Optimization of ball materials and relevant tests were made to identify the drillability of ball seat.Additionally,surface hardening of ball seat was discussed,together with corrosion and sealing experiments,to analyze the corrosion resistance of the ball seat.This ball-activated sleeve technique was applied in 8 wells in 72 fracturing stages,proving that it was reasonable and reliable,and could be effectively used for sealing under high pressure and entire drifting of completion string.
-
Keywords:
- staged fracturing /
- sliding sleeve /
- ball seat /
- erosion /
- sealing
-
-
[1] 朱正喜,李永革.水平井裸眼完井分段压裂技术研究[J].石油矿场机械,2011,40(11):44-47. Zhu Zhengxi,Li Yongge.Study of multistage fracturing of horizontal bare hole wells[J].Oil Field Equipment,2011,40(11):44-47. [2] 郭建春,赵志红,赵金洲,等.水平井投球分段压裂技术及现场应用[J].石油钻采工艺,2009,31(6):86-88,95. Guo Jianchun,Zhao Zhihong,Zhao Jinzhou,et al.Horizontal well ball staged fracturing technique and field application[J].Oil Drilling Production Technology,2009,31(6):86-88,95. [3] 陈作,王振铎,曾华国.水平井分段压裂工艺技术现状及展望[J].天然气工业,2007,27(9):78-80. Chen Zuo,Wang Zhenduo,Zeng Huaguo.Status quo and prospect of staged fracturing technique in horizontal wells[J].Natural Gas Industry,2007,27(9):78-80. [4] 董建华,郭宁,孙渤,等.水平井分段压裂技术在低渗油田开发中的应用[J].特种油气藏,2011,18(5):117-119. Dong Jianhua,Guo Ning,Sun Bo,et al.Application of horizontal well multistage fracturing in low permeability oilfield development[J].Special Oil Gas Reservoirs,2011,18(5):117-119. [5] 许国林,李博,王洪潮,等.ø140型裸眼分段压裂套管外封隔器的研制[J].石油机械,2011,39(7):54-55,58. Xu Guolin,Li Bo,Wang Hongchao,et al.Research on ø140 external casing packer for open hole staged fracturing[J].China Petroleum Machinery,2011,39(7):54-55,58. [6] 李民.水平井裸眼封隔器完井分段压裂技术研究:the 1st World Congress of Hydraulic Fracturing ＆ Acidizing,西安,8月26-28日,2010[C]. Li Min.Study of the horizontal well open hole packer well completion partition fracturing technology:the 1st World Congress of Hydraulic Fracturing ＆ Acidizing,Xi’an,August 26-28,2010[C]. [7] 秦金立,戴文潮,万学峰,等.无线射频识别技术在多级滑套压裂工具中的应用探讨[J].石油钻探技术,2013,41(3):123-126. Qin Jinli,Dai Wenchao,Wan Xuefeng,et al.Application of radio frequency identification in multistage fracturing sleeve tools[J].Petroleum Drilling Techniques,2013,41(3):123-126. [8] 姚辉前,杨同玉,秦金立,等.水平井分段压裂管柱堵塞分析及对策[J].石油机械,2013,41(6):77-80. Yao Huiqian,Yang Tongyu,Qin Jinli,et al.Analysis of horizontal staged fracture string blockage and solution[J].China Petroleum Machinery,2013,41(6):77-80. [9] 王军祥,李凌,葛世荣,等.表面处理碳纤维对增强尼龙复合材料性能影响[J].中国矿业大学学报,2002,31(2):158-161. Wang Junxiang,Li Ling,Ge Shirong,et al.Effect of treated carbon fiber on properties of filled polyamide 1010 composites[J].Journal of China University of Mining ＆ Technology,2002,31(2):158-161. [10] 宋艳江,王晓东,王伟,等.碳纤维增强热塑性聚酰亚胺及其复合材料[J].材料科学与工程学报,2007,25(3):363-366. Song Yanjiang,Wang Xiaodong,Wang Wei,et al.Carbon fiber reinforced TPI/CF composites[J].Journal of Materials Science ＆ Engineering, 2007,25(3):363-366. [11] 李芝华.碳纤维复合材料及其应用[J].工程塑料应用,1998,26(3):12-14. Li Zhihua.Carbon fiber composites and their applications[J].Engineering Plastics Application,1998,26(3):12-14. [12] 李建卫,陈美玲,高宏.改性纳米SiC粉体强化灰铸铁耐磨性能的研究[J].铸造,2007,56(1):68-70. Li Jianwei,Chen Meiling,Gao Hong.Research on the wear resistance of surface modified SiC nano-powders reinforced gray cast iron[J].Foundry,2007,56(1):68-70. [13] 克劳斯 G.钢的热处理原理[M].李崇谟,谢希文,刘纫馥,译.北京:冶金工业出版社,1987:267-270. Krauss Georage.Principles of heat treatment of steel[M].Translated by Li Chongmo,Xie Xiwen and Liu Renfu.Beijing:Metallurgical Industry Press,1987:267-270. -
