控压钻井液动节流压力控制系统仿真分析与试验研究

金业权; 孙泽秋; 刘刚

doi:10.3969/j.issn.1001-0890.2013.02.021

控压钻井液动节流压力控制系统仿真分析与试验研究

doi: 10.3969/j.issn.1001-0890.2013.02.021

1.
中国石油大学(华东)石油工程学院, 山东青岛 266580;
2.
中国石化石油工程技术研究院德州大陆架石油工程技术有限公司, 山东德州 253005

详细信息

作者简介:
金业权(1968-),男,湖北黄冈人,1992年毕业于江汉石油学院钻井工程专业,2006年获武汉大学岩土工程专业博士学位,副教授,硕士生导师,主要从事油气井力学、信息与控制以及井控风险评价方面的研究。联系方式15063018525,jinyequan156@126.com。

中图分类号: TE249
计量
- 文章访问数: 3060
- HTML全文浏览量: 25
- PDF下载量: 3940
- 被引次数: 0
出版历程
- 收稿日期: 2012-10-11
- 修回日期: 2013-02-26
- 刊出日期: 2013-04-19

Simulation Analysis and Experimental Study of Managed Pressure Drilling Hydraulic Throttle Pressure Control System

1.
School of Petroleum Engineering, China University of Petroleum(Huadong), Qingdao, Shandong, 266580, China;
2.
Shelfoil Petroleum Equipment & Services Co. Ltd., Sinopec Research Institute of Petroleum Engineering, Dezhou, Shandong, 253005, China

摘要

摘要: 针对传统控制方式难以实现节流压力精确控制的问题,提出了一种基于"PLC+高速开关阀"的液动节流压力控制方法。在完成系统方案设计的基础上,建立了系统的数学模型及传递函数;根据劳斯判据,得出系统四阶系数大于0,利用Matlab仿真得出该系统的幅值裕度大于0,相位裕角大于45°。现场实测数据与理论计算数据对比分析可知,曲线形状相似,平均相对误差4.0%,说明该系统的稳定性良好,能满足现场对控压钻井的工程要求。该控制系统弥补了现有控制系统的不足,为精细控压钻井提供了新的技术支持。
- 控压钻井 /
- 精细控压钻井 /
- 节流控制 /
- 系统仿真 /
- 压力控制
Abstract: : Since the traditional "PID + Proportion Servo Valve" throttle pressure control system has difficulty in precise control of the throttle pressure,a hydrodynamic throttle pressure control system has been developed based on the "PLC + High-Speed Switch Valve" hydrodynamic throttle pressure control system.On the basis of the system design,the mathematic model and transfer function of the system were built.According to the Routh Criterion that the system four order coefficient was greater than zero,through the simulation of Matlab draw system amplitude margin was greater than zero and phase margin angle greater than 45 degrees.Comparison of the measured data and the calculated data showed that the curves were similar in shape with average relative error of 4.0%,indicating the system was good in stability well and could meet the requirements of pressure control.The control system has made up for the deficiency of the existing control system to meet the "stable,fast,and provide new technical support" for accurate managed pressure drilling.
- managed pressure drilling /
- precise managed pressure /
- throttle control /
- system simulation /
- pressure control

HTML全文

参考文献(14)

周英操,杨雄文,方世良,等.PCDS-I精细控压钻井系统研制与现场试验[J].石油钻探技术,2011,39(4):7-12. Zhou Yingcao,Yang Xiongwen,Fang Shiliang,et al.Development and field test of PCDS-I precise managed pressure drilling system[J].Petroleum Drilling Techniques,2011,39(4):7-12.

金业权,刘刚,孙泽秋.控压钻井中节流阀开度与节流压力的关系研究[J].石油机械,2012,40(10):11-14. Jin Yequan,Liu Gang,Sun Zeqiu.The relationship research between throttle valve opening and throttle pressure of managed pressure drilling[J].China Petroleum Machinery,2012,40(10):11-14.

金业权,孙泽秋,刘刚.控压钻井井口回压控制系统,中国:201220190225.4.2012-12-05. Jin Yequan,Sun Zeqiu,Liu Gang.Pressure control drilling wellhead back pressure control system,China:201220190225.4[P].2012-12-05.

石希天,肖铁,徐金凤,等.精细控压钻井技术在塔中地区的应用及评价[J].钻采工艺,2010,33(5):32-34. Shi Xitian,Xiao Tie,Xu Jinfeng,et al.Application of precise managed pressure drilling technology in central Tarim Area[J].Drilling Production Technology,2010,33(5):32-34.

金业权,孙泽秋,方传新,等.精细控压钻井技术的研究进展与应用分析[J].中国石油和化工标准与质量,2012,32(2):49-50. Jin Yequan,Sun Zeqiu,Fang Chuanxin,et al.Precise managed pressure drilling technology research and progress application[J].China Petroleum and Chemical Standard and Quality,2012,32(2):49-50.

李宗清,燕修良,陈永明,等.三参数自动控压钻井系统的研制与试验[J].石油钻探技术,2012,40(6):99-103. Li Zongqing,Yan Xiuliang,Chen Yongming,et al.Development and test of three-parameter automatic pressure control drilling system[J].Petroleum Drilling Techniques,2012,40(6):99-103.

宋荣荣,孙宝江,王志远,等.控压钻井气侵后井口回压的影响因素分析[J].石油钻探技术,2011,39(4):19-24. Song Rongrong,Sun Baojiang,Wang Zhiyuan,et al.Analysis of the influence factors of wellhead back pressure in managed pressure drilling after gas invasion[J].Petroleum Drilling Techniques,2011,39(4):19-24.

王果,樊洪海,刘刚.井底常压控制压力钻井设计计算[J].石油勘探与开发,2011,38(1):103-108. Wang Guo,Fan Honghai,Liu Gang.Design and calculation of a MPD model with constant bottom hole pressure[J].Petroleum Exploration and Development,2011,38(1):103-108.

金业权,刘刚,方传新,等.欠平衡钻井方式地层适应性研究[J].新疆石油地质,2011,32(5):550-551. Jin Yequan,Liu Gang,Fang Chuanxin,et al.The formation adaptability of underbalanced drilling process[J].Xinjiang Petroleum Geology,2011,32(5):550-551.

王果,刘刚.钻井试验装置钻压伺服控制系统的设计与仿真[J].石油机械,2006,34(6):50-52. Wang Guo,Liu Gang.Design and simulation of bit servo-control system in drilling test unit[J].China Petroleum Machinery,2006,34(6):50-52.

任伟建,刘世聪,康朝海,等.油田钻井设备监控系统设计[J].化工自动化及仪表,2011,38(3):318-322. Ren Weijian,Liu Shicong,Kang Chaohai,et al.Monitoring system for oil drilling units[J].Control and Instruments in Chemical Industry,2011,38(3):318-322.

刘忠,廖亦凡.高速开关阀先导控制的液压缸位置控制系统建模与仿真研究[J].中国机械工程,2006,17(7):745-748. Liu Zhong,Liao Yifan.Modeling and simulation of hydraulic cylinder position control system based on high-speed on-off valve pilot control[J].China Mechanical Engineering,2006,17(7):745-748.

贺娟,袁颂岳.基于DSP的高速开关阀控液压缸位置控制系统研究[J].中国机械工程,2010,21(24):2929-2931. He Juan,Yuan Songyue.High-speed on/off valve hydraulic position control system based on DSP[J].China Mechanical Engineering,2010,21(24):2929-2931.

杨雄文,周英操,方世良,等.控压钻井分级智能控制系统设计与室内试验[J].石油钻探技术,2011,39(4):13-18. Yang Xiongwen,Zhou Yingcao,Fang Shiliang,et al.Design and laboratory test of hierarchical intelligent control system for managed pressure drilling[J].Petroleum Drilling Techniques,2011,39(4):13-18.
