Key Drilling Technologies for Complex Fracture-Cavity Formation in Jingyan-Qianwei Area
-
摘要: 井研–犍为地区地质条件复杂、裂缝溶洞发育，钻井过程中存在井眼失稳、井漏和卡钻等技术难点。为此，综合考虑地层三压力剖面和区域溶洞发育情况，优化了井身结构；根据陆相地层的地质特征，采用钾基聚合物防塌钻井液钻进，防止泥岩水化膨胀，保持井壁稳定；根据钻井过程中出现漏失的类型，采用常规桥接堵漏浆封堵裂缝性漏失，采用多功能固结承压堵漏技术解决恶性漏失，采用随钻封隔器解决漏层多、上喷下漏等复杂情况。通过上述研究形成的井研–犍为地区缝洞型复杂地层钻井关键技术，在井研–犍为地区的PR1井进行了现场试验，试验结果表明，采用该技术可以解决地层垮塌和严重井漏等问题，保证钻井安全。Abstract: The Jingyan-Qianwei Area, characterized by complex geological conditions and developed fractures and karst caves, has technical difficulties such as wellbore instability, lost circulation, and drill pipe sticking. In order to solve the problems, the formation three-pressure profiles and the development of karst caves in the area were comprehensively considered to optimize the casing program. According to the geological characteristics of continental formations, an anti-collapse drilling fluid with potassium-based polymers was used to prevent the mudstone from hydration swelling and keep wellbore stability. Based on the types of lost circulation that occurred during drilling, three plugging methods were developed, namely plugging fracture-induced lost circulation with the conventional bridge plugging slurry, resolving severe lost circulation with multi-functional and pressure-bearing consolidation plugging slurry, and handling complicated situations such as multiple loss formations and upper blowout and lower loss with a packer while drilling. Through the research above, key drilling technologies for complex fracture-cavity formation in Jingyan-Qianwei Area were developed. The technologies have been tested in well PR1 in Jingyan-Qianwei Area, the results showed that the technologies can be used to solve problems such as formation collapse and severe lost circulation and keep safe drilling.
-
-
![]()
图 1 固结材料凝固前后的状态
Figure 1. States of the consolidation material before and after solidification
表 1 前期完钻井井身结构
Table 1 Casing programs of wells completed in the early phase
井号 一开 二开 三开完钻 深度/m 层位 深度/m 层位 深度/m 层位 JS1井 540.00 雷口坡组 2 518.00 茅口组 4 202.00 灯影组 JY1井 506.00 须家河组 2 797.00 五峰组 3 940.00 灯影组 JY2井 745.00 须家河组 3 375.00 筇竹寺组 4 000.00 灯影组 JSH1井 717.00 雷口坡组 3 436.00 麦地坪组 4 221.00 陡山沱组 JS103井 504.00 须家河组 3 042.50 陡坡寺组 3 824.00 灯影组
下载: 导出CSV
表 2 地层三压力剖面预测
Table 2 Prediction of formation three-pressure profiles
层位 埋深/m 地层孔隙压力系数 地层破裂压力系数 地层坍塌压力系数 蓬莱镇组—沙溪庙组 870.00 1.00～1.10 1.00～1.10 凉高山组—须家河组 1 665.00 1.00～1.20 1.86～3.90 1.00～1.10 雷口坡组—飞仙关组 2 880.00 1.10～1.30 1.68～3.50 1.00～1.10 沙湾组、峨眉山组玄武岩 3 145.00 1.20～1.40 1.80～2.70 1.00～1.40 茅口组—梁山组 3 570.00 1.20～1.40 1.70～2.50 1.00～1.10 沧浪铺组—麦地坪组 3 990.00 1.20～1.45 2.50～3.20 1.00～1.40 灯影组 4 430.00 1.00～1.20 1.79～3.31 1.00～1.10
下载: 导出CSV
-
[1] 刘伟,何龙,胡大梁,等. 川南海相深层页岩气钻井关键技术[J]. 石油钻探技术,2019,47(6):9–14. LIU Wei, HE Long, HU Daliang, et al. Key technologies for deep marine shale gas drilling in southern Sichuan[J]. Petroleum Drilling Techniques, 2019, 47(6): 9–14.
[2] 常雨琪,孙玮,李泽奇,等. 川东南深层震旦系灯影组油气勘探前景[J]. 成都理工大学学报(自然科学版),2019,46(2):142–152. CHANG Yuqi, SUN Wei, LI Zeqi, et al. Oil and gas exploration prospects of the deep buried Dengying Formation in the southeastern Sichuan Basin, China[J]. Journal of Chengdu University of Technology, 2019, 46(2): 142–152.
[3] 马新华,徐春春,李国辉, 等. 四川盆地二叠系火成岩分布及含气性[J]. 石油勘探与开发,2019,46(2):216–225. doi: 10.1016/S1876-3804(19)60003-0 MA Xinhua, XU Chunchun, LI Guohui, et al. Distribution and gas-bearing properties of Permian igneous rocks in Sichuan Basin, SW China[J]. Petroleum Exploration and Development, 2019, 46(2): 216–225. doi: 10.1016/S1876-3804(19)60003-0
[4] 马鸿彦,郑邦贤,陈景旺,等. 杨税务潜山超深超高温井安全优快钻井技术[J]. 石油钻采工艺,2020,42(5):573–577. MA Hongyan, ZHENG Bangxian, CHEN Jingwang, et al. Optimized, safe and fast drilling technologies used in the ultra deep and high temperature wells in Yangshuiwu buried hill[J]. Oil Drilling & Production Technology, 2020, 42(5): 573–577.
[5] 王建龙,于志强,苑卓,等. 四川盆地泸州区块深层页岩气水平井钻井关键技术[J]. 石油钻探技术,2021,49(6):17–22. WANG Jianlong, YU Zhiqiang, YUAN Zhuo, et al. Key technologies for deep shale gas horizontal well drilling in Luzhou Block of Sichuan Basin[J]. Petroleum Drilling Techniques, 2021, 49(6): 17–22.
[6] 李磊,杨进,刘宝生,等. 渤海渤中区域深井井身结构优化[J]. 石油钻采工艺,2020,42(5):569–572. LI Lei, YANG Jin, LIU Baosheng, et al. Casing program optimization of deep wells in the central Bohai Area[J]. Oil Drilling & Production Technology, 2020, 42(5): 569–572.
[7] 史配铭,李晓明,倪华峰,等. 苏里格气田水平井井身结构优化及钻井配套技术[J]. 石油钻探技术,2021,49(6):29–36. SHI Peiming, LI Xiaoming, NI Huafeng, et al. Casing program optimization and drilling matching technologies for horizontal wells in Sulige Gas Field[J]. Petroleum Drilling Techniques, 2021, 49(6): 29–36.
[8] 谭天宇,邱爱民,汤继华,等. 吉兰泰油田吉华1区块超浅层水平井钻井关键技术[J]. 石油钻探技术,2021,49(6):37–41. TAN Tianyu, QIU Aimin, TANG Jihua, et al. Key drilling technologies for ultra-shallow horizontal wells in the Jihua-1 Block of Jilantai Oilfield[J]. Petroleum Drilling Techniques, 2021, 49(6): 37–41.
[9] 王志远,黄维安,范宇,等. 长宁区块强封堵油基钻井液技术研究及应[J]. 石油钻探技术,2021,49(5):31–38. WANG Zhiyuan, HUANG Weian, FAN Yu, et al. Technical research and application of oil base drilling fluid with strong plugging property in Changning Block[J]. Petroleum Drilling Techniques, 2021, 49(5): 31–38.
[10] 张雄,余进,毛俊,等. 准噶尔盆地玛东油田水平井高性能油基钻井液技术[J]. 石油钻探技术,2020,48(6):21–27. ZHANG Xiong, YU Jin, MAO Jun, et al. High-performance oil-based drilling fluid technology for horizontal wells in the Madong Oilfield, Junggar Basin[J]. Petroleum Drilling Techniques, 2020, 48(6): 21–27.
[11] 李钟,罗石琼,罗恒荣,等. 多元协同防塌钻井液技术在临盘油田探井的应用[J]. 断块油气田,2019,26(1):97–100. LI Zhong, LUO Shiqiong, LUO Hengrong, et al. Application of multivariate synergistic anti-caving drilling fluid technology in exploratory wells of Linpan Oilfield [J]. Fault-Block Oil & Gas Field, 2019, 26(1): 97–100.
[12] 李建山. 杭锦旗区块防塌防漏钻井液技术[J]. 钻井液与完井液,2019,36(3):308–314. LI Jianshan. Drilling fluid technology for borehole wall stabilization and mud loss control in Block Hangjinqi[J]. Drilling Fluid & Completion Fluid, 2019, 36(3): 308–314.
[13] 袁国栋,王鸿远,陈宗琦,等. 塔里木盆地满深1井超深井钻井关键技术[J]. 石油钻探技术,2020,48(4):21–27. YUAN Guodong, WANG Hongyuan, CHEN Zongqi, et al. Key drilling technologies for the ultra-deep well Manshen 1 in the Tarim Basin[J]. Petroleum Drilling Techniques, 2020, 48(4): 21–27.
[14] 陈修平,高雷雨,刘景涛,等. 顺北油气田却尔却克组井壁失稳机理及应对措施[J]. 钻井液与完井液,2021,38(1):35–41. CHEN Xiuping, GAO Leiyu, LIU Jingtao,et al. Mechanisms of borehole wall destabilization in Que’er’Que’ke formation in Shunbei oil and gas field and measures dealing with the borehole wall collapse[J]. Drilling Fluid & Completion Fluid, 2021, 38(1): 35–41.
[15] 张志磊,胡百中,卞维坤,等. 昭通页岩气示范区井漏防治技术与实践[J]. 钻井液与完井液,2020,37(1):38–45. ZHANG Zhilei, HU Baizhong, BIAN Weikun, et al. Mud loss control techniques and practices in Zhaotong Demonstration Zone of shale gas drilling[J]. Drilling Fluid & Completion Fluid, 2020, 37(1): 38–45.
[16] 胡大梁,郭治良,李果,等. 川南威荣气田深层页岩气水平井钻头优选及应用[J]. 石油地质与工程,2019,33(5):103–106. HU Daliang, GUO Zhiliang, LI Guo, et al. Bit optimization and application fo deep shale gas wells in Weirong Gas Field of southern Sichuan Basin[J]. Petroleum Geology and Engineering, 2019, 33(5): 103–106.
[17] 胡大梁,欧彪,郭治良,等. 川西二叠系超深风险井永胜1井钻井关键技术[J]. 断块油气田,2019,26(4):524–528. HU Daliang, OU Biao, GUO Zhiliang, et al. Key drilling technology of Permian ultra-deep risk exploration Well YS1 in western Sichuan[J]. Fault-Block Oil & Gas Filed, 2019, 26(4): 524–528.
[18] 左星,罗超,张春林,等. 四川盆地裂缝储层钻井井漏安全起钻技术认识与探讨[J]. 天然气勘探与开发,2019,42(1):108–113. ZUO Xing, LUO Chao, ZHANG Chunlin, et al. Safe tripping-out technology against lost circulation in fractured reservoirs, Sichuan basin[J]. Natural Gas Exploration and Development, 2019, 42(1): 108–113.
[19] 王军,范翔宇,贺立勤,等. 喷漏同存条件下堵漏压井技术:以四川盆地九龙山构造龙探1井为例[J]. 天然气工业,2019,39(1):106–112. WANG Jun, FAN Xiangyu, HE Liqin, et al. Well killing and plugging technology under the coexistence of blowout and circulation loss: a case study on Well Longtan 1 in the Jiulongshan Structure, Sichuan Basin[J]. Natural Gas Industry, 2019, 39(1): 106–112.
[20] 田军,刘文堂,李旭东,等. 快速滤失固结堵漏材料ZYSD的研制及应用[J]. 石油钻探技术,2018,46(1):49–54. TIAN Jun, LIU Wentang, LI Xudong, et al. Development and application of rapid filtration and consolidation lost circulation material ZYSD[J]. Petroleum Drilling Techniques, 2018, 46(1): 49–54.
[21] 詹俊阳,刘四海,刘金华,等. 高强度耐高温化学固结堵漏剂HDL–1的研制及应用[J]. 石油钻探技术,2014,42(2):69–74. ZHAN Junyang, LIU Sihai, LIU Jinhua, et al. Development and application of chemical consolidation plugging agent HDL–1[J]. Petroleum Drilling Techniques, 2014, 42(2): 69–74.
[22] 方俊伟,贾晓斌,刘文堂,等. ZYSD 高失水固结堵漏技术在顺北5-9 井中的应用[J]. 钻井液与完井液,2021,38(1):74–78. FANG Junwei, JIA Xiaobin, LIU Wentang, et al. Control mud losses in Well Shunbei-5-9 with ZYSD high fluid loss solidifying slurry[J]. Drilling Fluid & Completion Fluid, 2021, 38(1): 74–78.
-
