井眼轨迹的主法线角及其方程

刘修善

刘修善. 井眼轨迹的主法线角及其方程[J]. 石油钻探技术, 2019, 47(3): 103-106. DOI: 10.11911/syztjs.2019052
引用本文: 刘修善. 井眼轨迹的主法线角及其方程[J]. 石油钻探技术, 2019, 47(3): 103-106. DOI: 10.11911/syztjs.2019052
LIU Xiushan. Principal Normal Angle of Borehole Trajectory and Its Equation[J]. Petroleum Drilling Techniques, 2019, 47(3): 103-106. DOI: 10.11911/syztjs.2019052
Citation: LIU Xiushan. Principal Normal Angle of Borehole Trajectory and Its Equation[J]. Petroleum Drilling Techniques, 2019, 47(3): 103-106. DOI: 10.11911/syztjs.2019052

井眼轨迹的主法线角及其方程

基金项目: 国家科技重大专项“海相碳酸盐岩超深油气井关键工程技术”(编号:2017ZX05005-005)资助
详细信息
    作者简介:

    刘修善(1962—),男,黑龙江牡丹江人,1984年毕业于大庆石油学院钻井工程专业,1998年获中国石油勘探开发研究院油气井工程专业博士学位,中国石化集团公司高级专家,教授级高级工程师,主要从事导向钻井工艺、井下信息测量与控制等方面的研究工作。系本刊副主编。E-mail:liuxs.sripe@sinopec.com

  • 中图分类号: TE21

Principal Normal Angle of Borehole Trajectory and Its Equation

  • 摘要:

    针对井眼轨迹挠曲特性及其变化规律的表征问题,提出了井眼轨迹主法线角的概念及定义,厘清了井眼轨迹弯曲方向与导向钻具定向方向的本质区别。在此基础上,建立了井眼轨迹主法线角的通用方程,并结合常用井眼轨迹模型给出了主法线角的具体计算方法及公式;揭示了不同挠曲参数间的关系,创建了用特性曲线表征井眼轨迹挠曲形态的方法。研究表明:井眼轨迹的主法线角不同于导向钻具的工具面角,基于直角坐标系和极坐标系耦合的特性曲线可表征多组挠曲参数及其相互关系。研究结果厘清了现有理论与技术中的一些模糊认识,发展了井眼轨迹挠曲形态的表征方法。

    Abstract:

    Based on the deflection behavior and the characteristics of borehole trajectories, a concept and definition of the principal normal angle of a borehole trajectory was proposed in this paper, and the essential difference between the deflection direction of borehole trajectory and the directional orientation of steering tool was clarified. On this basis, the general equation of the principal normal angle of borehole trajectory was established, and the specific calculation method and formula of the principal normal angle were provided in combination with common borehole trajectory models. The relationships among different deflection parameters were revealed, and the method of characterizing the deflection morphology of a borehole trajectory was established using their characteristic curves. The studies show that the principal normal angle of a borehole trajectory is different from the tool face angle of steering tool. Further, the Cartesian coordinate- polar coordinate coupling based characteristic curve can be used to characterize multiple sets of deflection parameters and their relationships. The research results clarified some fuzzy understandings on the existing theories and techniques, and developed a characterization method for the deflection behavior of borehole trajectories.

  • 图  1   井眼轨迹的基本向量和主法线角

    Figure  1.   Basic vector and principal normal angle of borehole trajectory

    图  2   导向钻具的定向方向和工具面角

    Figure  2.   Orientation direction and tool face angle of steering tool

    图  3   主法线角对井斜的影响规律

    Figure  3.   Influence rules of principal normal angle on hole inclination

    图  4   井眼轨迹的挠曲特性曲线

    Figure  4.   Deflection characteristic curve of borehole trajectory

  • [1] 韩志勇. 定向钻井设计与计算[M]. 2版. 东营: 中国石油大学出版社, 2007: 254-255.

    HAN Zhiyong. Design and calculation of directional drilling[M]. 2nd ed. Dongying: China University of Petroleum Press, 2007: 254-255.

    [2] 刘修善. 井眼轨道几何学[M]. 北京: 石油工业出版社, 2006: 74.

    LIU Xiushan. Geometry of wellbore trajectory[M]. Beijing: Petroleum Industry Press, 2006: 74.

    [3] 刘修善. 导向钻具定向造斜方程及井眼轨迹控制机制[J]. 石油勘探与开发, 2017, 44(5): 788–793.

    LIU Xiushan. Directional deflection equations for steerable drilling tools and the control mechanism of wellbore trajectory[J]. Petroleum Exploration and Development, 2017, 44(5): 788–793.

    [4]

    LIU Xiushan. New technique calculates borehole curvature, torsion[J]. Oil & Gas Journal, 2006, 104(40): 41–49.

    [5]

    GUO Boyun, MISKA STEFAN, LEE R L. Constant-curvature method to plan 3D directional wells[R]. SPE 23576, 1991.

    [6]

    SCHUH F J. Trajectory equations for constant tool face angle deflections[R]. SPE 23853, 1992.
