The Technology of Long Cable Snubbing Fishing through Coiled Tubing in Horizontal Shale Gas Wells
-
摘要: 为解决页岩气水平井泵送桥塞射孔联作时长电缆落井不易打捞的问题，研究了连续油管带压打捞长电缆技术。采用CCL磁性定位器探测鱼顶位置，然后下入"低速螺杆+外钩"的井下工具组合打捞落鱼，利用低速螺杆转动外钩捕获电缆，落鱼起至井口后利用电缆防喷器夹持电缆，打开井口防喷管，分段起出电缆。涪陵地区某井利用该技术成功打捞出了81.00 m长的电缆及通井工具串，取得了良好的现场应用效果。连续油管带压打捞长电缆技术解决了电缆在水平井井下位置不易精准定位、连续油管不能旋转和长电缆无法完全起至防喷管内等难点，为页岩气水平井打捞长电缆提供了一种不污染地层、安全可靠和灵活高效的方法。Abstract: In order to solve the problem of fishing the long cable lost in shale gas horizontal wells,a method of coiled tubing snubbing fishing was developed.In this method,the first step is to use the CCL to detect the depth of the fish top.Later,the RIH-downhole tool combination of low-speed screw motor works with the external grapple to recover the fish.The low speed screw motor rotates to drive the external grapple to catch the cable.After pulling out of the hole (POOH) and transporting the fish to the wellhead,a cable blowout preventer is used to seal the cable.Then the process is to open the wellhead preventer to pull the cable out of the hole in stages.This method resolves many difficulties,including the downhole precise positioning of cable,coiled tubing rotation,and long cable pulled up into the lubricator.This technology once was used to recover 81.00 m long cable+drifting string successfully in a well of the Fuling Area,and good results were attained by the field application. The success of long cable snubbing fishing through coiled tubing has provided a safe,reliable,flexible and efficient method for fishing of long cable in shale gas horizontal wells.
-
Keywords:
- shale gas /
- horizontal well /
- operation under pressure /
- fishing /
- cable /
- coiled tubing
-
-
[1] 薛承瑾.页岩气压裂技术现状及发展建议[J].石油钻探技术,2011,39(3):24-29. XUE Chengjin.Technical advance and development proposals of shale gas fracturing[J].Petroleum Drilling Techniques,2011,39(3):24-29. [2] 路保平.中国石化页岩气工程技术进步及展望[J].石油钻探技术,2013,41(5):1-8. LU Baoping.Sinopec engineering technical advance and its developing tendency in shale gas[J].Petroleum Drilling Techniques,2013,41(5):1-8. [3] 贾长贵,路保平,蒋廷学,等.DY2HF深层页岩气水平井分段压裂技术[J].石油钻探技术,2014,42(2):85-90. JIA Changgui,LU Baoping,JIANG Tingxue,et al.Multi-stage horizontal well fracturing technology in deep shale gas well DY2HF[J].Petroleum Drilling Techniques,2014,42(2):85-90. [4] 刘祖林,杨保军,曾雨辰.页岩气水平井泵送桥塞射孔联作常见问题及对策[J].石油钻采工艺,2014,36(3):75-78. LIU Zulin,YANG Baojun,ZENG Yuchen.Common problems of pumping bridge plug and clustering perforation for horizontal shale gas well and countermeasures[J].Oil Drilling Production Technology,2014,36(3):75-78. [5] 吴春国,任中启,刘爱军,等.钻井测井电缆打捞技术[J].石油钻探技术,2003,31(3):54-56. WU Chunguo,REN Zhongqi,LIU Aijun,et al.Techniques of fishing logging cable[J].Petroleum Drilling Techniques,2003,31(3):54-56. [6] 曹学军,周赟,傅伟,等.连续油管带压作业技术在特殊复杂井况中的应用[J].天然气勘探与开发,2012,35(2):50-52,56. CAO Xuejun,ZHOU Yun,FU Wei,et al.Application of pressure operation technology of coiled tubing in special complex well condition[J].Natural Gas Exploration and Development,2012,35(2):50-52,56. [7] 王伟佳,熊江勇,张国锋,等.页岩气井连续油管辅助压裂试气技术[J].石油钻探技术,2015,43(5):88-93. WANG Weijia,XIONG Jiangyong,ZHANG Guofeng,et al.Auxiliary fracturing and testing of gas in shale gas well with coiled tubing[J].Petroleum Drilling Techniques,2015,43(5):88-93. [8] 吕选鹏,周承富,陈辉,等.连续油管技术在页岩气勘探开发中应用前景[J].石油矿场机械,2012,41(2):67-70. LYU Xuanpeng,ZHOU Chengfu,CHEN Hui,et al.Coiled tubing technology prospect in exploration and development of shale gas[J].Oil Field Equipment,2012,41(2):67-70. [9] 吴永兴,朱培珂,熊伟.连续油管打捞工艺在水平井的应用问题及措施[J].石油矿场机械,2016,45(7):80-83. WU Yongxing,ZHU Peike,XIONG Wei.Coiled tubing fishing process application problems and measures in horizontal well[J].Oil Field Equipment,2016,45(7):80-83. [10] 石孝志,苏贵杰,王忠胜,等.连续油管打捞技术在川渝地区的应用[J].天然气工业,2008,28(8):58-60. SHI Xiaozhi,SU Guijie,WANG Zhongsheng,et al.Application of coiled tubing fishing technology in Sichuan and Chongqing Area[J].Natural Gas Industry,2008,28(8):58-60. [11] 刘成.吐哈油田连续油管技术的应用[J].石油矿场机械,2001,30(3):45-47. LIU Cheng.Application of coiled tubing in Tuha Oilfield[J].Oil Field Equipment,2001,30(3):45-47. -
