Fixed-Point Water Shutoff Technology in Horizontal Wells Based on Modified Cyanogen Coagulation
-
摘要: 为有效封堵出水点明确的高含水水平井，特别是筛管完井水平井，借鉴水坝裂缝处理和防水工程中的堵漏方法，提出了基于小剂量改性氰凝的水平井定点堵水技术。通过对浆液黏度、发泡反应进行化学改性，研制了化学自膨胀-改性氰凝，使其可注入和反应时间可控，并考察了固化体的抗压强度、耐压性及其影响因素；同时，研发了配套的活塞推进输送和架桥驻留工艺。试验得出，研制的化学自膨胀-改性氰凝可在20~90℃下延迟可控反应，抗压强度12 MPa以上，耐压达到20 MPa。该技术在3口井进行了现场试验，在国内首次实现了L形筛管完井水平井定点堵水。研究结果表明，基于改性氰凝的水平井定点堵水技术可解决水平井长井段定点堵水难题，为治理水平井出水提供了新的技术手段。Abstract: :In order to conduct water shutoff effectively in high water cut horizontal wells with known water points,especially for wells completed with screens,the fixed-point water shutoff technology for horizontal wells with low-dose modified cyanogen coagulation was proposed by drawing on the experience of leakage prevention in dam crack treatment and waterproofing engineering.Through the chemical modification of viscosity and foaming reaction of the slurry,a modified chemical self-swelling cyanogen coagulation was developed,so as to make it injectable and obtain a controllable reaction time.The compressive strength,pressure resistance and influencing factors of the solidified body were investigated;meanwhile,the matched piston forwarding and bridging residence process were developed.Test results demonstrated that the modified self-swelling cyanogen coagulation as a plugging agent could delay the controllable reaction at 20-90℃,its compressive strength is over 12 MPa,and its pressure resistance is up to 20 MPa.Field tests were conducted in 3 wells,including the first fixed-point water shutoff in horizontal well completed with L-type screen pipe in China.The results demonstrated that the fixed-point water shutoff technology based on modified cyanogen coagulation in horizontal wells could solve the fixed-point plugging problems in extended reach horizontal wells.They could also provide new technical means for water producing treatment in horizontal wells.
-
-
[1] ZHAO Xianzheng,JIN Fengming,WANG Quan,et al.Buried-hill play,Jizhong Subbasin,Bohai Bay Basin:a review and future prospectivity[J].AAPG Bulletin,2015,99(1):1-26.
[2] 闫海俊,谢刚,巨登峰,等.冀中地区高含水水平井治理工艺模式[J].断块油气田,2016, 23(5):648-651,654. YAN Haijun,XIE Gang,JU Dengfeng,et al.Technologies of chemical plugging for high water-cut horizontal wells in Jizhong District[J].Fault-Block Oil Gas Field,2016,23(5):648-651,654. [3] 李宜坤,胡频,冯积累,等.水平井堵水的背景,现状及发展趋势[J].石油天然气学报,2005,27(5):757-760. LI Yikun,HU Pin,FENG Jilei,et al.Background,current situation and trend of development for water shutoff in horizontal wells[J].Journal of Oil and Gas Technology,2005,27(5):757-760. [4] 魏发林,刘玉章,李宜坤,等.割缝衬管水平井堵水技术现状及发展趋势[J].石油钻采工艺,2007,29(1):40-43. WEI Falin,LIU Yuzhang,LI Yikun,et al.Developing trend and current situation of water plugging technology for slotted pipe horizontal wells[J].Oil Drilling Production Technology,2007,29(1):40-43. [5] 葛红江,苟景锋,雷齐玲,等.水平井化学堵水配套药剂研究[J].油田化学,2009,26(4):387-390,397. GE Hongjiang,GOU Jingfeng,LEI Qiling,et al.Chemicals for water shutoff in horizontal wells[J].Oilfield Chemistry,2009,26(4):387-390,397. [6] 闫海俊,巨登峰,谢刚,等.二次交联泡沫冻胶体系评价与应用[J].断块油气田,2013,20(2):252-254. YAN Haijun,JU Dengfeng,XIE Gang,et al.Evaluation and application of gelled foam with secondary cross-linking[J].Fault-Block Oil Gas Field,2013,20(2):252-254. [7] 杜勇.边底水油藏水平井ACP定位控水技术的研究与应用[J].钻采工艺,2015,38(5):44-46. DU Yong.Research and application of ACP positioning water control technology in edge-bottom water reservoir horizontal well[J].Drilling Production Technology,2015,38(5):44-46. [8] 周赵川,陈立群,高尚,等.CESP水平井环空化学封堵工艺在渤海油田的应用[J].断块油气田,2013,20(3):400-402. ZHOU Zhaochuan,CHEN Liqun,GAO Shang,et al.Application of annulus chemical plugging for horizontal well with CESP screen pipe in Bohai Oilfield[J].Fault-Block Oil Gas Field,2013,20(3):400-402. [9] 天津大学化工系高分子教研室.氰凝灌浆材料的研制与应用[J].化学通报,1978(3):11-13. High Polymer Teaching and Research Department of Chemical Engineering,Tianjin University.Development and application of urethane precondensate grouting[J].Chemistry,1978(3):11-13. [10] 刘双平,郝健,张顺军.油田堵水、封窜用改性氰凝材料[J].油田化学,1999,16(4):314-316,371. LIU Shuangping,HAO Jian,ZHANG Shunjun,et al.Modified urethane precondensates OTPT and WTPT as gelling materials for water shutoff/profile modification agents[J].Oilfield Chemistry,1999,16(4):314-316,371. [11] 步玉环,王瑞和,穆海朋.纤维水泥抗压强度模型[J].天然气工业,2007,27(9):56-58, 61. BU Yuhuan,WANG Ruihe,MU Haipeng.Compressive strength model for fiber cement[J].Natural Gas Industry,2007,27(9):56-58,61. [12] 范振忠,王犇.改性氰凝堵水剂的室内评价[J].科学技术与工程,2011,11(29):7260-7262. FAN Zhenzhong,WANG Ben.The indoor evaluation of modification of cyanogen coagulation[J].Science Technology and Engineering,2011,11(29):7260-7262. [13] 刘学鹏,张明昌,冯明慧,等.复合空心微珠低密度水泥浆的研究与应用[J].石油钻采工艺,2014,36(6):39-41. LIU Xuepeng,ZHANG Mingchang,FENG Minghui,et al.Research and application of composite hollow microbead low density cement slurry[J].Oil Drilling Production Technology,2014,36(6):39-41. [14] 许晶玮,庞浩,颜永斌,等.以甘蔗渣为原料的聚氨酯合成反应动力学[J].高分子材料科学与工程,2007,23(6):50-52,56. XU Jingwei,PANG Hao,YAN Yongbin,et al. Kinetic study of the reaction between liquefied product of bagasse and isocyanate[J]. Polymer Materials Science Engineering,2007,23(6):50-52,56. [15] 李清忠,杨万有,吴恩成,等.三次加密井管外窜槽检测及治理技术[J].石油钻采工艺,2006,28(1):79-81. LI Qingzhong,YANG Wanyou,WU Encheng,et al.Detection and treatment for outside casing channel infill well[J].Oil Drilling Production Technology,2006,28(1):79-81. [16] 包贵全.煤层气钻井工程中几个重点技术问题的探讨[J].探矿工程(岩土钻掘工程),2007,34(12):4-8. BAO Guiquan.Study on some focal technical problems of drilling engineering for coal bed methane[J].Exploration Engineering (Rock Soil Drilling and Tunneling),2007,34(12):4-8. -
