Theoretical Study and Experimental Tests of Rock Breaking Depth under Particle Impacting
-
摘要: 为了准确分析粒子冲击钻井过程中粒子对岩石的冲击作用机理，指导施工参数的优选，需要对粒子冲击破岩的深度进行理论计算。基于动态球形空腔膨胀理论，推导了粒子冲击破岩过程中粒子所受阻力与初始入射速度的关系，结合粒子运动微分方程建立了粒子冲击破岩深度的计算模型，并给出定解条件和求解方法。根据计算实例，对粒子冲击破岩深度与粒子初始入射速度的响应关系和破岩深度与破岩时间的响应关系进行了研究。粒子冲击破岩室内试验结果表明，理论计算结果与试验结果基本吻合，表明该理论模型准确可行，可用于粒子冲击破岩过程的理论分析。研究表明，无因次破岩深度随粒子初始入射速度增大呈线性增加、随破岩时间增长呈对数增加的规律。研究结果可为粒子冲击钻井技术的实际应用提供理论支撑。Abstract: To accurately analyze the mechanism of impacts of particles on rocks during partical impact drilling and to optimize hydraulic parameters, it is necessary to perform theoretical calculations of particle impacting depth. Based on dynamic spherical expansion theory, correlation between resistance and intial incident velocity was derived. From differential equations of particle motion, the calculation model for the particle impacting depth was established. In addition, definite solution conditions and relevant algorithm were clarified. Based on actual calculation, the correlation between impact depth and incident velocity and that between the impact depth and time were studied. Experimental results showed theoreticalresults match well with experimental one. So the theoretical model can be used in theoretical analyses of particle impacting processes. Research results demonstrated that the dimensionless rock breaking depth would increase linearly with the the initial incident velocity and would increase logarithmically with time. Relevant research conclusions may provide necessary theoretical support for the application of particle impact drilling techniques.
-
Keywords:
- particle /
- impact /
- rock breaking depth /
- cavity expansion /
- theoretical model /
- experimental test
-
-
[1] 赵健,韩烈祥,徐依吉,等.粒子冲击钻井技术理论与现场试验[J].天然气工业,2014,34(8):102-107. ZHAO Jian,HAN Liexiang,XU Yiji,et al.A theoretical study and field test of the particle impact drilling technology[J].Natural Gas Industry,2014,34(8):102-107. [2] 徐依吉,赵健,毛炳坤,等.冲击钻井粒子注入系统研究[J].石油钻采工艺,2012,34(1):1-5. XU Yiji,ZHAO Jian,MAO Bingkun,et al.Research on particle injection system in percussion drilling[J].Oil Drilling Production Technology,2012,34(1):1-5. [3] 王明波,王瑞和,陈炜卿.单个磨料颗粒冲击岩石过程的数值模拟研究[J].石油钻探技术,2009,37(5):34-38. WANG Mingbo,WANG Ruihe,CHEN Weiqing.Numerical simulation study of rock breaking mechanism and process under abrasive water jet[J].Petroleum Drilling Techniques,2009,37(5):34-38. [4] 颜廷俊,姜美旭,张扬,等.基于ANSYS-LSDYNA的围压下粒子冲击破岩规律[J].断块油气田,2012,19(2):240-243. YAN Tingjun,JIANG Meixu,ZHANG Yang,et al.Study on rock breaking for particle impacting with confining pressure based on ANSYS-LSDYNA[J].Fault-Block Oil Gas Field,2012,19(2):240-243. [5] 况雨春,朱志镨,蒋海军,等.单粒子冲击破岩实验与数值模拟[J].石油学报,2012,33(6):1059-1063. KUANG Yuchun,ZHU Zhipu,JIANG Haijun,et al.The experimental study and numerical simulation of single-particle impacting rock[J].Acta Petrolei Sinica,2012,33(6):1059-1063. [6] 伍开松,荣明,李德龙,等.双粒子联合冲击破岩仿真研究[J].岩土力学,2009,30:19-23. WU Kaisong,RONG Ming,LI Delong,et al.Simulation study of impacting breaking rock by double particle[J].Rock and Soil Mechanics,2009,30:19-23. [7] 赵健,石超,徐依吉,等.钢粒间干涉对冲击破岩效果的影响[J].高压物理学报,2016,30(2):163-169. ZHAO Jian,SHI Chao,XU Yiji,et al.Numerical and experimental analysis of rock breaking effect by steel shot impacting intervention[J].Chinese Journal of High Pressure Physics,2016,30(2):163-169. [8] TIBBITTS G A,GALLOWAY G G.Particle drilling alters standard rock-cutting approach[J].World Oil,2008,229(6):37-44.
[9] XU Y,KEER L M,LUK V K.Elastic-cracked model for penetration into unreinforced concrete targets with ogival nose projectiles[J].International Journal of Solids Structures,1997,34(12):1479-1491.
[10] SATAPATHY S.Dynamic spherical cavity expansion in brittle ceramics[J].International Journal of Solids and Structures,2001,38(32/33):5833-5845.
[11] CHOCRONA S,ANDERSON C E Jr,WALKERB J D,et al.A unified model for long-rod penetration in multiple metallic plates[J].International Journal of Impact Engineering,2003,28(4):391-411.
[12] 周辉,文鹤鸣.动态柱形空穴膨胀模型及其在侵彻问题中的应用[J].高压物理学报,2006,20(1):67-78. ZHOU H,WEN H M.Dynamic cylindrical cavity expansion model and its application to penetration problems[J].Chinese Journal of High Pressure Physics,2006,20(1):67-78. [13] HE T,WEN H M,GUO X J.A spherical cavity expansion model for penetration of ogival-nosed projectiles into concrete targets with shear-dilatancy[J].Acta Mechanica Sinica,2011,27(6):1001-1012.
[14] FORRESTAL M J,LUK V K.Dynamic spherical cavity-expansion in a compressible elastic-plastic solid[J].Journal of Applied Mechanics,1988,55(2):275-279.
[15] LUK V K,FORRESTAL M J.Penetration into semi-infinite reinforced-concrete targets with spherical and ogival nose projectiles[J].International Journal of Impact Engineering,1987,6(4):291-301.
[16] FORRESTAL M J.Penetration into dry porous rock[J].International Journal of Solids and Structures,1986,22(12):1485-1500.
[17] 尹放林,王明洋,钱七虎.弹体垂直侵彻深度工程计算模型[J].爆炸与冲击,1997,17(4):333-339. YIN Fanglin,WANG Mingyang,QIAN Qihu.An engineering computing model for penetration depth of projectile normal into target[J].Explosion and Shock Waves,1997,17(4):333-339. -
